  • Page 1 DATA LOGGER 4670617 Software rel. 1.2.X INSTALLATION, USE AND MAINTENANCE...

  • Page 2: Table Of Contents

    This manual is an integral part of the equipment to which it refers and must accompany the equipment in case of sale or change of ownership. Keep it for any future reference; ARAG reserves the right to modify product specifications and instructions at any moment and without notice.

  • Page 3: Risks And Protections

    • RESPONSIBILITY The installer must carry out "workmanlike" installations and ensure to the end user the perfect operation of the whole system both with ARAG components only and other brands' components. ARAG always recommends using its components to install control systems.

  • Page 4: Package Content

    Fig. 4 Fig. 5 Set mounting rail in cabin and fasten it with the relevant screws ( ), in a position where VISIO can be easily seen and at hands' reach, but Fig. 5 away from any moving organs. Secure VISIO to rail and push down until locked in place.

  • Page 5: Wiring Connections

    • Use of unsuitable cables not provided by ARAG automatically voids the warranty. • ARAG is not liable for any damage to the equipment, persons or animals caused by failure to observe the above instructions. General precautions for a correct harness position •...

  • Page 6: Power Supply Connection - Ref. Cable 3 - Par. 6.1

    • Directly connect the power cable to the key-on power supply (15/54). Connection of external enabling signal To allow the external enabling signal to condition the recording, no setting is required on Visio, only the wiring connection of the signal must be carried out.

  • Page 7: Accessories

    SETTING ACCESSORIES Pendrive The pendrive may be used to exchange data. Before use, format the SD board in FAT 32 mode; make sure that the board is not protected and can be read by the system. Most pendrives with up to 2 Gb memory are compatible.

  • Page 8: Menu Structure

    SETTING MENU STRUCTURE For a correct use of the keys during setting, refer to par. 20.0 bar Max pressure 1.0 ÷ 25.0 Pressure sensor Press. zero value Not connected Sensors Air pressure Connected 20.0 bar Max. pressure 1.0 ÷ 25.0 Air pressure sens.

  • Page 9: Setup Menu

    SETTING SETUP MENU From the main page, press keys at the same time for 2 seconds to access. 10/04 13:47 Show recording Fig. 13 Setup menu Sensors Press to edit the selected menu item. Alarms Recording Fig. 14 You can view the set values by scrolling the items of the .

  • Page 10: Setup Menu > Alarms

    SETTING 11.3 Setup menu > Alarms 11.3.1 Min pressure 11.3.2 Max pressure Minimum pressure The pressure alarms (minimum or maximum) 02.0 activate when, during the spraying, the Alarms pressure detected by the sensor does not Min value Min pressure Max value 25.0 respect the set limits.

  • Page 11: Options > Set Date

    SETTING 11.5.2 Options > Set date Access the menu. Year Set the current year: wizard Year > Month > Day. 2020 The key goes to the next setting. Min value 2019 The month selection automatically defines the number of days that can be set. Max value 2099 Fig.

  • Page 12: Setup Menu > Setup Management

    11.6 Setup menu > Setup management. To be able to use the following functions it is necessary to plug a USB* pendrive in the relevant port at the bottom of Visio Data Logger. *USB pendrive not included in the kit; the USB must be formatted in FAT32 mode.

  • Page 13: Setup Menu > Diagnostics

    SETTING 11.7 Setup menu > Diagnostics This menu allows user to view some data and carry out an operation test of VISIO. Access the menu. Press the key on the side to scroll the Setup menu Diagnostics items. Options Firmware version Setup management 1.1.0...

  • Page 14: Setup Menu > User Access

    Operator: user access level and minimum parameter number (simplified menu structure). ARAGTech Technician: maximum access level; access to all control parameters. ARAGTech: for ARAG staff only (assistance). It requires an access PIN number. Fig. 40 ENTERING THE PIN NUMBER ONLY Technician users can set an access PIN number, as follows: User access Select the access mode to enter the PIN number.

  • Page 15: Use

    Before starting spraying, set the minimum recording pressure (par. 11.4.1). If Visio shows the display page (par. 12.2), press to go to the recording page. Visio automatically starts /interrupts pressure recording, according to the following conditions: • Standard recording • Pressure detected greater than minimum...

  • Page 16: Recording Page

    Visible with recording OFF ONLY. Press the key to go to the display page (short pressure) 12.2 Display page (WITH RECORDING OFF ONLY: Visio automatically quits this page if recording restarts) - It displays data of the latest recording saved. - It scrolls recordings backward / forward.

  • Page 17: Maintenance / Diagnostics / Repairs

    In some cases, recording is immediately interrupted; in these cases, stop spraying, solve the problem and resume spraying: recording automatically resumes. 10/04 13:47 In case of errors detected by VISIO, the display shows a message in the lower part. 3. 4 0. 0 An alarm symbol blinks near the sensor in question.

  • Page 18: Technical Data

    TECHNICAL DATA TECHNICAL DATA 14.1 Display Graphic .................. LCD, 128 x 64 pixels, backlit Unit of measurement ............. EU (bar) / US (psi) Real-time clock battery duration ..........18 years 14.2 Electrical features Power supply voltage ............. 9÷16 Vdc Maximum power input (with no sensors connected) ....160 mA Protection against polarity inversion ........

  • Page 19: End-Of-Life Disposal

    Dispose of the system in compliance with the established legislation in the country of use. GUARANTEE TERMS 1. ARAG s.r.l. guarantees this apparatus for a period of 360 days (1 year) from the date of sale to the client user (date of the goods delivery note).
  • Page 20 Only use genuine ARAG accessories or spare parts to make sure manufacturer guaranteed safety conditions are maintained in time. Always refer to the Internet address www.aragnet.com 42048 RUBIERA (Reggio Emilia) - ITALY Via Palladio, 5/A Tel. +39 0522 622011 Fax +39 0522 628944 http://www.aragnet.com...
