Denon AVR-2801 Brochure & Specs

Outstanding surround sound and affordable price, with Dolby Digital and DTS decoding
Equal Power Discrete Power Amplifier
Front 90 W + 90 W (8 ohms, 20Hz - 20kHz, 0.05% THD)
Center 90 W (8 ohms, 20Hz - 20kHz, 0.05% THD)
Surround 90 W + 90 W (8 ohms, 20Hz - 20kHz, 0.05% THD)
DDSC-Digital (Dynamic Discrete Surround Circuit-Digital)
Dolby Digital and DTS Decoder
Front (L,R) A/B Speaker Switching
96kHz, 24-bit Audio D/A Converters
6-Channel External Input For DVD-Audio and SACD
Separate Current Supplies for Circuits
Hefty Power Transformer for Stable Supply of Power
Stable Speaker Drive
Outputs for System Upgrading
(Front L/R, Center, Surround L/R, Subwoofer)
Video Select Switch
All-channel Level Control
Binding Post Speaker Terminals for All Channels
Icon-based On-Screen Display
Personal Memory Plus
Multi-function Remote Controller
N E W M O D E L
Dolby Digital and DTS A/V Receiver
AVR-2801
I N F O R M A T I O N
TENTATIVE
Frequency Synthesis Tuning
• 40-Station AM/FM Random Preset Memory Tuning
• Auto Preset Memory
Other Features
• Cinema Equalizer
• Music Surround Modes Including 5-channel Stereo
• "S" and Composite Video Switching
• Tone Control
• 2 Switched AC Outlets
Input/Output Terminals For Every A/V System
• Audio Inputs
3 Digital (Optical) Input .......... OPTICAL x 3
1 Digital (Coaxial) Input ......... COAXIAL x 1
9 Analog Inputs ..................... PHONO, CD, TUNER, DVD, VDP,
6 Analog EXT. Inputs ............. FRONT L/R, CENTER,
• Audio Outputs
6 Analog Pre Outputs ............ FRONT L/R, CENTER,
3 Analog Rec Outputs ........... VCR-1, VCR-2/V-AUX, CDR/TAPE
• Video Inputs
5 S-Video Inputs .................... DVD, VDP, TV/DBS, VCR-1,
5 Composite Inputs ............... DVD, VDP, TV/DBS, VCR-1,
• Video Outputs
3 S-Video Outputs ................. VCR-1, VCR-2/V-AUX, MONITOR
3 Composite Outputs ............. VCR-1, VCR-2/V-AUX, MONITOR
TV/DBS, VCR-1, VCR-2/V-AUX,
CDR/TAPE
SURROUND L/R, SUBWOOFER
SURROUND L/R, SUBWOOFER
VCR-2/V-AUX
VCR-2/V-AUX
