Polygroup TG76M2T20D08 Assembly Instructions

NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com
TREE A SS E MBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting into
the assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Remove the protective cap from the upper section(s) and insert into the lower section(s). Continue until the tree top is inserted.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Connect the plug(s) securely to the extension cord(s) as per the color labels indicated in Fig. B and insert the adapter into the
wall outlet. Your entire tree should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or broken,
loose or missing bulbs. Connecting the plugs or replace the bad bulbs promptly in order to maintain the performance and life
expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out
one to the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TG76M2T20D08
1-888-919-0070
OR
Polygroup®!
Tree top
Section 2
Section 1
Side view
Carefully follow the instructions below on how to quickly and
Insert Red Label
Plugs Into Red
Labeled Extension Cord
Control box
Insert Green
Label Extension
Cord into Adapter
1
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward
and snap into place.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120V, 60Hz, 0.16A
Output: 29V DC 0.28A
Adapter
To Be Plugged
Into Wall
Outlet
