Summary of Contents for Arctus Fenja 20
- Page 1 User's Manual Arctus Fenja 20...
- Page 2 Index Important Safe Guards Ambient Environment For Operating Components Diagrams Operating Introduction Functions of Control Panel & Key Pads Operation of Key Pads Automatic Defrosting Water Full Processions Of Abnormal Compressor ...
-
Page 3: Important Safeguards
Important Safe Guards ！ Do not install and use the unit before carefully reading this instruction guide. Please retain this manual for product warranty and future reference. 1）Please be sure your electricity is correct 2） To protect against electrical shock, do not place it in near window or in bathroom. -
Page 4: Ambient Environment For Operating
11）Never pull the socket by using damp hands. 12）Always switch off at the socket before unplugging to avoid electric shock or arcing. 13）Switch off and unplug the unit, empty the water reservoir when not using the unit for a long time. 14）Do not pull power wire by force because it will cause damage to power wire. -
Page 5: Components Diagrams
Components Diagrams Air deflector Control panel... -
Page 6: Operating Introduction
Operating Introduction Functions of Control Panel & Key Pads 1. POWER: Switch on/off the power. 2. Press “HUMID” to select the desired RH, like 40%RH, 60%RH, 80%RH or continuous mode. 3. Press “Speed” to select the fan running at low or high speed . 4. -
Page 7: Automatic Defrosting
1）Press “HUMID” once, the 40%RH is selected. Press “HUMID” for the 2 time, the 60%RH is selected. Press “HUMID” for the 3rd time, the 80%RH is selected. Press “HUMID” for the 4th time, the continuous mode is selected. The circle is repeated like this…… 2 ）... -
Page 8: Protection Of Water Full
1）When room temperature dropped down to 16℃ or lower, which detected by temperature sensor to generate compressor works 25 minutes on dehumidifying then cut off, fan blower keeps running 7 minutes to defrost in a cycle. 2）When defrost，Symbol of defrost displayed, and the symbol of dehumidification goes out. -
Page 9: Failures Of Humidity & Temperature Sensor
Failures Of Humidity & Temperature Sensor 1. When the connect wire of humidity and temperature sensor breaks off, the symbol of continuous dehumidification ”CON” will wink. The appliance comes into continuous dehumidifying mode. 1） When the temperature sensor malfunctions, the appliance will turn to continuous dehumidification mode and not under control of humidity setting. -
Page 11: Maintenance And Cleaning
Maintenance & Cleaning ◆ For its casing is made of plastic, do not place it in direct sunlight. ◆ Remove the water tank with care. ◆ Only use a soft clean cloth for all cleaning purpose. Do not use gasoline, paint thinner or other chemicals to clean the unit. -
Page 12: Specification
Specification Model Arctus Fenja 20 Power Rated 220-240VAC/50Hz Moisture removal 20 L/D (30℃ RH80%) Dehumidifying Power 345W (30℃ RH80%) Max Power Dissipation 400W (35℃ RH90%) Dehumidifying Air Volume L:115m H:140 m Refrigerant R134a 150g Capacity of Water Tank 3.8L Unit Dimension:...
