Front and Back View — Small Form Factor
10
1 optical drive
3 USB 2.0 connectors (2)
5 diagnostic lights (4)
7 power button, power light
9 headphone connector
11 cover release latch
13 power connector
15 expansion card slots (2)
1
9
15
3
2
8 7
14
2 optical drive eject button
4 network connectivity light
6 drive activity light
8 microphone connector
10 Media Card Reader (optional)
12 padlock ring
14 back panel connectors
4
5
6
11
12
13
