Murata LLA219C70G475ME01 Series Reference Sheet page 5

Fig 1 Package Chip
Fig.2 Dimension of Reel
Fig3 Taping Diagram
JEMCAP-00644A
2.0±0.5
φ 21±0.8
Top Tape : Thickness 0.06
(*LLA18 /LLA215/LLA315 type: Thickness 0.05)
Feeding Hole : As specified in 2.2
Base Tape : As specified in 2.2
5
(in mm)
Chip
10±1.5
16.5 max.
Hole for Chip : As specified in 2.2
Package
LLA Type
