SCxxxT_ES_EN_FR_IT_PT_ver1
USER'S AND INSTALLATION MANUAL
Dear buyer, we thank you for purchase of our product.
Prior to installation and first use of the electric water heater, please carefully read these
instructions.
This water heater has been manufactured in compliance with the relevant standards and tested
by the relevant authorities as indicated by the Safety Certificate and the Electromagnetic Compatibility
Certificate. The technical characteristics of the product are listed on the label affixed between the inlet
and outlet pipes. The installation must be carried out by qualified staff. All repairs and maintenance
work within the water heater, e.g. lime removal or inspection/replacement of the protective anticorrosion
anode, must be carried out by the authorised maintenance service provider.
Technical Information:
MODEL
CAPACITY
ELECTRICAL CHARACTERISTICS:
VOLTAGE (V)
FREQUENCY (Hz)
POWER (W)
CLASS
PROTECTION
DEGREE
REGULATION
THERMOSTAT
TEMPERATURE
KIND OF
REGULATION
THERMOSTAT
KIND OF SAFETY
THERMOSTAT
EXTERNAL
TEMPERATURE
REGULATION
KIND OF
HEATING
ELEMENT
KIND OF
HEATING
ELEMENT
HYDRAULIC CHARACTERISTICS:
ENAMELLED TANK
MAGNESIUM
ANODE
NOMINAL
PRESSURE
SAFETY VALVE
PRESSURE
APARICI – SCxxxT
INSTALLATION MANUAL
SC030T
30
230
50/60
2000
(1200W + 800W)
I
IPX4
75
(ºC)
PTC SENSOR
BULB
YES
YES -
ELECTRONIC
IN DIRECT
CONTACT
WITH WATER
YES
YES
7.5 bar
8.5 bar
SC050T
SC080T
50
230
50/60
50/60
2000
2000
(1200W + 800W)
(1200W + 800W)
I
IPX4
IPX4
75
PTC SENSOR
PTC SENSOR
BULB
BULB
YES
YES
YES -
YES -
ELECTRONIC
ELECTRONIC
IN DIRECT
IN DIRECT
CONTACT WITH
CONTACT
WATER
WITH WATER
YES
YES
YES
YES
7.5 bar
7.5 bar
8.5 bar
8.5 bar
10
SC100T
80
100
230
230
50/60
2000
(1200W + 800W)
I
I
IPX4
75
75
PTC SENSOR
BULB
YES
YES -
ELECTRONIC
IN DIRECT
CONTACT
WITH WATER
YES
YES
7.5 bar
8.5 bar
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aparici SC T Series
Summary of Contents for Aparici SC T Series
- Page 1 SCxxxT_ES_EN_FR_IT_PT_ver1 USER'S AND INSTALLATION MANUAL APARICI – SCxxxT Dear buyer, we thank you for purchase of our product. Prior to installation and first use of the electric water heater, please carefully read these instructions. This water heater has been manufactured in compliance with the relevant standards and tested by the relevant authorities as indicated by the Safety Certificate and the Electromagnetic Compatibility Certificate.
- Page 2 G1/2’ CONNECTIONS 1090 fig.-1 – Model APARICI SCxxxT 1.- BUILDING-IN. The water heater shall be built-in as close as possible to the outlets in order to reduce the heat loses. The building place must be chosen considering the maximum reductions of 90º elbows in water connections and, at the same time, make easy the substitution of the heating element.
- Page 3 SCxxxT_ES_EN_FR_IT_PT_ver1 Fig. 2 Model APARICI SCxxxT In every case the distance between water heater maintenance cover and the closer wall must be minimum 60 It has to be fitted to the wall using appropriate rag bolts with minimum diameter of 8 mm. The wall with feeble charging ability must be on the spot where the water heater shall be hanged suitably reinforced.
- Page 4 According to this the sole necessary operation from electrical point of view is to plug the water heater to a socked. If the flexible cord is damaged, it must be substituted by an especial plug cord APARICI reference 91027.
- Page 5 Fig. – 5 6.- INSTALLATION RECOMMENDATIONS In order to have a correct operation of the APARICI electric water heater, please take into account the below considerations: 1. Water pressure at electric water heater inlet must be between 1.5 and 5 bar. Also all considerations explained at point 3) of this manual must be taken into account.
- Page 6 SCxxxT_ES_EN_FR_IT_PT_ver1 Fig. – 6 1) The"1" refers to the water heater power switch button and mode button. n the shutdown state, long press this button for 3 seconds, the system boot, the display light, and vice versa. At boot mode: press this button, then switch between "single tank mode", “double tank mode”...
- Page 7 SCxxxT_ES_EN_FR_IT_PT_ver1 4.- TROUBLE SHOOTING When the water heater fails, automatically the heating element stops working and the display shows the corresponding fault code. At that moment, if you press any button, there is not answer from the water heater. Only disconnect the power, call to after sales service to solve the problem and repair the water heater and connect it again makes that the fault code will be eliminated.
