INSTALLATION AND SERVICE MANUAL
For Installation of Legend recessed step light LED.
Model.
LE-40591,LE-40601,LE-40611,LE-40621 and LE-40671
Product drawing (dimensions)
260
LE-40591
260
LE-40621
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-2 standard.
Technical amendments and modifications techniques reserved.
