3. Components and Controls

3.1 Controls

No.
DB-15 diagnostic
1
connector
2
20
Top & Front Views
Name Descriptions
To connect to vehicle's DLC (Data Link Connector)
via diagnostic cable.
• In Off mode, press it for about 5 seconds to turn
the handset on.
• In On mode:
Power
• Press it to activate the LCD if the LCD is off.
• Press it to turn off the LCD if the LCD lights
• Press it for 3 seconds to turn it off.
Professional 909 User Manual
Rear View
up.
