- Page 1 KVM switch and rackmount screen technology User Manual 17” / 19” LCD 1152 x 900 Native Resolution NS117 / NS119 1U LCD Console Drawer Options : - DC power Designed and manufactured by Austin Hughes UM-CV-751-NS117-Q419V2 www.austin-hughes.com...
- Page 2 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-NS117-Q419V2 www.austin-hughes.com...
-
Page 3: Table Of Contents
Contents < Part. 1 > NS117 / NS119 Package Content Structure Diagram & Dimension P.1 - 2 Installation P.3 - 4 Connection P.5 - 7 < Part. 2 > Specifi cations / OSD Product Specifi cations P.7 - 8 Keyboard / Mouse Specifi cations P.9 - 10... - Page 4 fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-NS117-Q419V2 www.austin-hughes.com...
-
Page 5: < 1.1 > Package Content
< Part 1 > < 1.1 > Package Content NS117 / NS119 NS117 or NS119 unit X 1 - CX-6A 6ft DVI-D console cable X 1 ( Alternative : CB-6A 6ft VGA console cable ) - Power cord X 1 - M6 screw, cage nut &... - Page 6 Weight 441.6 x 500 x 44 mm 590 x 808 x 140 mm 12.3 kg 16.5 kg NS117 17.4 x 19.7 x 1.73 inch 23.2 x 31.8 x 5.5 inch 27.1 lb 36 lb 441.6 x 500 x 44 mm 590 x 808 x 140 mm 12.5 kg...
-
Page 7: Installation
< 1.3 > Installation - How to install Installation Slides NS117 / NS119 Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. - Page 8 < 1.3 > Installation- How to use the drawer ■ Pull the tab on the front handle and gently slide out the drawer. ■ Flip up the LCD to a suitable angle. ■ Operate the LCD console drawer. UM-CV-751-NS117-Q419V2 www.austin-hughes.com...
- Page 9 < 1.4 > Connection to USB Server via CX-6A cable NS117 / NS119 LCD Console Drawer DVI-D AC Input 100~240V POWER CX-6A DVI-D console cable USB server DVI-D < 1.4 > Connection to external KVM via CX-6A cable LCD Console Drawer...
-
Page 10: Connection
Before attempting to connect anything to the LCD console drawer, we suggest turning off the power to all devices. Apply power to connected devices again only after the LCD console drawer is receiving power. The company is not responsible for damage caused in this way. UM-CV-751-NS117-Q419V2 www.austin-hughes.com... -
Page 11: Product Specifi Cations
< Part 2 > < 2.1 > Product Specifi cations NS117 / NS119 NS117 NS119 Panel Manufacturer Panel Size ( diagonal ) 17-inch TFT color LCD 19-inch TFT color LCD 1280 x 1024 ( Direct ) 1152 x 900 ( Direct ) - Page 12 40,000 ft Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical NS117 NS119 Specifi cation Product ( W x D x H ) 441.6 x 500 x 44 mm 441.6 x 500 x 44 mm 17.4 x 19.7 x 1.73 inch 17.4 x 19.7 x 1.73 inch...
-
Page 13: Keyboard / Mouse Specifi Cations
< 2.2 > Keyboard / Mouse Specifi cations NS117 / NS119 S keyboard integrated with touchpad S keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■... - Page 14 Audio / Display Keys * Please ask your supplier for full details Audio : Mute Display : Degauss Audio : Decrease volume Display : Decrease contrast Audio : Increase volume Display : Increase contrast UM-CV-751-NS117-Q419V2 P.10 www.austin-hughes.com...
-
Page 15: On-Screen Display Operation ( Osd )
< 2.3 > On-screen Display Operation ( OSD ) NS117 / NS119 Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust... - Page 16 H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: for volume, bass, treble, balance, AVL and mute Misc: for the language, OSD position, graphic mode, ratio, reset and timer UM-CV-751-NS117-Q419V2 P.12 www.austin-hughes.com...
- Page 17 < Part 3 > < 3.1 > Options : DC Power NS117 / NS119 Model 125V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V Input current...
- Page 18 (W x D x H) 441.6 x 620 x 44 mm 590 x 808 x 140 mm 13.3 kg 16.5 kg NS117 with KVM 17.4 x 24.4 x 1.73 inch 23.2 x 31.8 x 5.5 inch 29.2 lb 36.3 lb 441.6 x 620 x 44 mm...
- Page 19 Intentionally Left Blank UM-CV-751-NS117-Q419V2 www.austin-hughes.com...
- Page 20 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2019 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-NS117-Q419V2 www.austin-hughes.com...
