Lorex LNR6100 Series Quick Connection Manual

Package Contents:
4K NVR USB Mouse
Remote Control Power Adapter
Ethernet Cable HDMI Cable
Quick Start Guides
Need Help?
Visit us online for up-to-date software and
complete instruction manuals
1
Visit lorextechnology.com
Search for the model number
2
of your product
Click on your product in the
3
search results
4
Click on the Downloads tab
Information in this document is subject to change without notice. As our products are subject
to continuous improvement, FLIR Systems, Inc. and our subsidiaries reserve the right to modify
product design, specifications and prices, without notice and without incurring any obligation.
E&OE © 2017 FLIR Systems, Inc. All rights reserved.
Quick Connection Guide
Connecting Your System
1
IP Cameras*
Ethernet Extension Cable*
NOTE: It may take up to 1
minute for cameras to start
up and transmit video to
your NVR.
Recommended:
Connect cameras to a PoE switch* or router*
OR
Connect cameras
on your network. See "Adding Cameras from
to the NVR. the LAN" on reverse for more details.
8-channel configuration shown. 4 channel will have the respective number of video inputs. For camera
compatibility information, visit lorextechnology.com/compatibility.
* Not included / sold separately.
2 3
Router* Monitor*
For PoE switch
installations only
!
The NVR is set to 1080p
output by default. To optimize
picture quality, set the NVR's
video output to match the
resolution of your monitor.
OR
VGA* HDMI
Supports Supports
up to 1080p up to 4K
LNR6100 Series
4K Network Video Surveillance Recorder
4 5
Mouse Power

Beeping

If the system is beeping after startup, the
Ethernet cable may not be connected or the
system may not be connected to the network.
To stop the beeping:
1. Connect an Ethernet cable from the system
to your router.
OR
2. Right click and click Disable Beep.

Firmware Update

This system features automatic firmware
upgrades for enhanced functionality. It is
required to upgrade your system to the latest
firmware version.
If a firmware upgrade is available:
1. After startup, a notification will appear
asking you to upgrade the firmware. Click OK
to upgrade.
2. The system will download and install the
firmware upgrade. Wait for the firmware
update to complete. The system may restart
during the firmware upgrade process.
DO NOT power off or disconnect the power
cable during firmware installation.
LNR6100_QCG_EN_R1
