3.0 Power Test

3.1. Connect power to the CyberData device and monitor the LED activity on the
device. See the following figure:
3.2. The green Link/Activity LED comes on immediately to show that there is a
good network connection, and then blinks to show network activity.
3.3. After about 23 seconds with a static IP address (or 27 seconds if the board
is set to use DHCP), the speaker should be ready.
Note If the board is set to use DHCP and there is not a DHCP server available
on the network, it will try 12 times with a three second delay between tries
and eventually fall back to the programmed static IP address (by default
10.10.10.10). This process will take approximately 80 seconds.
This concludes the power test. Go to
Configuration File
Quick Start Guide
Retrieval".
Connect power to the CyberData device
Section 4.0, "InformaCast
RTFM switch
100 Mb
(Yellow LED)
Network Link/Activity
(Green LED)
931682A
