Electronic Service
Manuals
This electronic document is provided as a service to our customers.
We do not create the contents of the information contained in this docu-
ment. Should you have detailed questions pertaining to the information
contained in this document, you may contact Michco, or the manufac-
turer which provided the original information in this electronic deliver-
able. Michco's only part in this electronic deliverable was the electronic
assembly process. By providing this manual on line we are not guaran-
teeing parts availability.
You may contact Michco through the following methods:
Phone (517) 484-9312 or (800) 331-3339
2011 N. High St. -- Lansing, Michigan -- 48906
Fax: (517) 484-9836
Email: CustServe@Michco.com
Web site: www.Michco.Com
Parts Web site: www.FloorMachineParts.Com
Order Parts on Line at:
www.FloorMachineParts.Com
Directly to Parts & Service:
By Email:
Shop@Michco.com
By Fax: (517) 702-2041
By Voice: Use numbers above.
Serving the Cleaning Industry Since 1922
Notice: All copyrighted material remains property of original owners, all trademarks are property of respective owners.
Manuals are subject to Manufacturer's reproduction limitations. Originals or reproductions were provided by manufacturers
through a request. We make no warranty as to the correctness of information provided in this document and you assume
all risk. By placing these manuals on line we are not declaring our corporation to be an manufacturer authorized dealer or
provider, please check our web site for authorized manufacturers we represent.
Advertisement
Table of Contents
Related Manuals for Windsor Saber SX28
Summary of Contents for Windsor Saber SX28
- Page 1 Electronic Service Manuals This electronic document is provided as a service to our customers. We do not create the contents of the information contained in this docu- ment. Should you have detailed questions pertaining to the information contained in this document, you may contact Michco, or the manufac- turer which provided the original information in this electronic deliver- able.
- Page 2 WALK BEHIND SCRUBBER Operating Instructions MODELS: SX28 SX34 SX34SP IPX4 Read these instructions before using the machine 98739 11/08/01...
- Page 3 Copyright 1995 Windsor Industries, Printed in USA YOUR DEALER Name: __________________________________________________________________________________________________ Address: _______________________________________________________________________________________________ For the name and address of your dealer contact: Windsor Industries Phone Number: _________________________________________________________________________________________ OVERVIEW The Saber SX is a battery powered, self-propelled, hard floor scrubber intended for commercial use.
-
Page 4: Table Of Contents
TABLE OF CONTENTS MAINTENANCE (cont.) Machine Data Log/Overview......2 Table of Contents ..........3 Squeegee Blades..........4-6 HOW TO USE THIS MANUAL Adjusting Squeegee........4-6 Adjusting Squeegee Pitch.......4-6 Adjusting Rear Deflection.......4-6 How to use this Manual........1-1 Replace/Rotate Rear Squeegee Blade……..4-7 Removing Squeegee Assembly. -
Page 5: How To Use This Manual
They are Parts may be ordered from authorized Windsor listed in this general order: dealers. When placing an order for parts, the machine model and machine serial number are Batteries important. -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an battery powered appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. WARNING: To reduce the risk of fire, electric shock, or injury: Use only indoors. Do not use outdoors or expose to rain. Use only as described in this manual. -
Page 7: Hazard Intensity Level
WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use Windsor approved replacement parts. WARNING Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and open flame away. Keep solution tank in raised position when charging. -
Page 8: Safety Label Location
SAFETY LABEL LOCATION NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible, promptly replace them. SAFETY DECAL 81494 CAUTION Explosive Gas is Given Off By Batteries During Charge. 1. Keep Battery Compartment Cover Open. -
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS ITEM DIMENSION/CAPACITY Nominal power 2.88 kW Rated Voltage 36VDC Rated Amperage 80 Amps Batteries 6 X 6 Volt 250-305 AH @ 20 hr rate Scrub Brush Motors 2 X .75 hp (0.56 kW) Vacuum Motor .75 hp (0.56 Kw) standard, second motor optional Propelling Motor .75 hp (0.56 Kw) - Page 10 TECHNICAL SPECIFICATIONS ITEM MEASURE Height 47 in. (119 cm) maximum Length with 28 in. (71 cm) disk scrub head 67 in. (170 cm) Length with 34 in. (86 cm) disk scrub head 69 in. (175 cm) Length with 34 in. (86 cm) cylindrical scrub head 69.5 in.
-
Page 11: How The Machine Works
HOW THE MACHINE WORKS The Saber SX is a battery powered, self- or turn the motors off and raise the deck. The propelled, hard floor scrubber intended for brush pressure switch controls the down pressure commercial use. The appliance applies a on the scrub deck. -
Page 12: Components
COMPONENTS 1. Control Panel 2. Control Tower 3. Front Cover 4. Recovery Tank 5. Recovery Tank Drain Hose 6. Scrub Head 7. Scrub Brush Access Cover (Disk) 8. Scrub Brush Idler Door (Cylindrical) 9. Solution Tank 10. Solution Tank Cover 11. -
Page 13: Controls
CONTROLS 1. Solution Control Knob 2. One Touch Switch 3. Vacuum/Squeegee Switch 4. Brush Pressure Indicator/Switch 5. Brush Circuit Breaker Indicator 6. Recovery Tank Full Indicator 7. Key Switch 8. Speed Control Knob 9. Battery Charge Level Indicator 10. Recycle Switch (Optional) 11. - Page 14 CONTROLS 3. VACUUM/SQUEEGEE SWITCH 1. SOLUTION CONTROL KNOB Controls the vacuum motor, and squeegee Controls solution flow to scrub deck. position (if equipped with Auto Squeegee Lift To increase flow, rotate knob clockwise. Option). To decrease flow, rotate knob To start vacuum motor, press the switch. If counterclockwise.
- Page 15 CONTROLS 7. KEY SWITCH 11. PUMP SWITCH (OPTIONAL) Controls the power for machine functions. Controls the pump to operate a scrub wand. To turn machine on, rotate key clockwise. To start pump, press the switch. To turn machine off, rotate key To stop pump, press the switch.
- Page 16 CONTROLS 19. SQUEEGEE PITCH ADJUSTMENT KNOB 16. CIRCUIT BREAKERS Adjusts the deflection at the ends of the Interrupt the flow of power in the event of an squeegee. electrical overload. When a circuit breaker is To increase squeegee blade deflection at the tripped, reset it by pressing the exposed ends, turn knob counterclockwise.
-
Page 17: Machine Operation
MACHINE OPERATION 4. Fill the solution tank with clean water, leaving PRE-RUN MACHINE INSPECTION enough room for the required amount of Do a pre-run inspection to find possible problems cleaning solution. The solution tank capacity that could cause poor performance or lost time filled to 2”... -
Page 18: Emptying & Cleaning Tanks
MACHINE OPERATION A second scrubbing with the squeegee down and TO BEGIN SCRUBBING again the solution and brushes on will further loosen CAUTION soil. The additional application of solution will further assist the difficult cleaning job. When operating the machine around people, pay close attention for unexpected movement. -
Page 19: Maintenance
MAINTENANCE 3. Wipe off the top of the batteries at least once a BATTERIES week. The batteries provide the power to operate the 4. Test battery condition with a hydrometer at least machine. The batteries require regular maintenance once a week. to keep them operating at peak efficiency. -
Page 20: Changing Batteries
MAINTENANCE TO CHARGE THE BATTERIES 7. Plug the charger connector into the battery connector. Connect the charger AC plug to a CAUTION wall outlet. The charger gauge should indicate When servicing machine, avoid contact with that the batteries are charging. battery acid. -
Page 21: Scrub Brushes
MAINTENANCE SCRUB BRUSHES Blue Pads (Scrubbing) are used for heavy-duty scrubbing and light stripping. The blue pads remove less finish than brown stripping pads, yet will remove NOTE: All original equipment brushes are equipped black marks, stains and dirt. with “Perform Alert©”. This feature will tell the operator when it is time to replace the scrub Brown Pads (Stripping) are used for easy and brushes. -
Page 22: Cylindrical Scrub System
MAINTENANCE CYLINDRICAL SCRUB SYSTEM SCRUB BRUSH REMOVAL The dual cylindrical scrub head is designed to The scrub brushes are removed from the sides of eliminate debris that may be caught in the squeegee the machine. The front is removed from the right while scrubbing. -
Page 23: Scrub Deck Adjustment
MAINTENANCE CYLINDRICAL SCRUB LEVELING THE SCRUB HEAD SCRUB DECK ADJUSTMENT Leveling the cylindrical head is accomplished by Scrub deck adjustment consists of two types of adjusting the scrub head lift linkage. The upper lift adjustments. The first is to insure the individual linkage can be adjusted by loosening the jam nuts at brushes make the same width pattern end to end. -
Page 24: Squeegee Blades
MAINTENANCE SQUEEGEE BLADES FOR SAFETY: Before leaving or servicing machine; stop on level surface, turn off machine There are three sets of front and rear squeegee and remove key. blades available. There are three different notch patterns and three different colors for varying floor 3. - Page 25 MAINTENANCE TO REPLACE OR ROTATE REAR TO REMOVE SQUEEGEE ASSEMBLY SQUEEGEE BLADES 1. With the squeegee in the up position, turn off the key switch and set the parking brake. 1. With the squeegee in the up position, turn off the key switch and set the parking brake.
-
Page 26: Service Schedule
MAINTENANCE SERVICE SCHEDULE MAINTENANCE DAILY WEEKLY MONTHLY ANNUALLY Before Check battery acid level starting Check vac hose connections the work Clean the squeegee blades period Inspect brushes or pads for debris: wire string, wear Inspect vac fan shut off float screen End of Drain &... - Page 27 MACHINE TROUBLESHOOTING PROBLEM CAUSE SOLUTION Poor or no water pick-up Squeegee out of Adjust squeegee adjustment Debris caught on squeegee Remove debris Worn squeegee blades Rotate or replace squeegee blades Vacuum hose clogged Clear obstruction from hose Vacuum hose disconnected Reconnect vacuum hose from squeegee or recovery tank...
- Page 28 MACHINE TROUBLESHOOTING PROBLEM CAUSE SOLUTION Little or no solution flow to the Solution tank empty Fill solution tank floor Solution flow turned off or Turn on or increase flow set too low setting Solution strainer plugged Clean solution strainer Solution hoses obstructed Clear obstruction from hose Solution solenoid valve...
