Newland NLS-HR3290 User Manual

Cordless 2d barcode scanner
Hide thumbs Also See for NLS-HR3290:
Table of Contents

Advertisement

Quick Links

NLS-HR3290
Cordless 2D Barcode Scanner
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NLS-HR3290 and is the answer not in the manual?

Questions and answers

Related Manuals for Newland NLS-HR3290

Summary of Contents for Newland NLS-HR3290

  • Page 1 NLS-HR3290 Cordless 2D Barcode Scanner User Guide...
  • Page 2 All pictures in this manual are for reference only and actual product may differ. Regarding to the product modification and update, Fujian Newland Auto-ID Tech. Co., Ltd. reserves the right to make changes to any software or hardware to improve reliability, function, or design at any time without notice. The information contained herein is subject to change without prior notice.

  • Page 3: Revision History

    Revision History Version Description Date V1.0.0 Initial release. September 1, 2016 1. Changed the range of Decode Session Timeout to 100ms - 3,600,000ms in Chapter 2. 2. Added the Host Acknowledgment and Keep/Delete Stored Data after Batch Transmission features in Chapter 4. 3.

  • Page 4: Table Of Contents

    Table of Contents Revision History ............................- 3 - Preface ................................1 Introduction ............................1 Chapter Description ..........................1 Explanation of Icons ..........................2 Chapter 1 Getting Started ..........................3 Introduction ............................3 Features of the HR32 ..........................3 Unpacking .............................. 3 Scanner ..............................
  • Page 5 Factory Defaults ........................... 18 Pairing Settings ............................ 19 Pair Scanner with Cradle ....................... 19 Pair Cradle with Zigbee Router ..................... 19 Search Paired Scanners........................ 19 Operating Mode Options ........................20 Power-Off Timeout ..........................21 Illumination ............................22 Aiming ..............................23 Beep ..............................
  • Page 6 Chapter 3 Inquiry Commands ........................41 Introduction ............................41 Obtain Scanner Information ......................... 41 Obtain Cradle Information ........................41 Obtain FLASH Information ........................42 Chapter 4 Communication Settings ......................43 Introduction ............................43 Wireless Communication ........................43 Host Acknowledgment ......................... 44 Keep/Delete Stored Data after Batch Transmission ................
  • Page 7 Disable All Symbologies ........................ 58 Enable All Symbologies ......................... 58 Enable 1D Symbologies ........................ 59 Disable 1D Symbologies ....................... 59 Enable 2D Symbologies ........................ 59 Disable 2D Symbologies ....................... 59 Video Reverse ..........................60 Code 128 ............................. 61 Restore Factory Defaults ....................... 61 Enable/Disable Code 128 ......................
  • Page 8 Add-On Code Required ......................... 75 Transmit System Character “0” ..................... 75 UPC-E Extension ........................... 76 UPC-A ..............................77 Restore Factory Defaults ....................... 77 Enable/Disable UPC-A ........................77 Transmit Check Digit ........................77 Add-On Code ..........................78 Add-On Code Required ......................... 79 Transmit Preamble Character .......................
  • Page 9 Restore Factory Defaults ....................... 94 Enable/Disable Codabar........................ 94 Set Length Range for Codabar ..................... 95 Check Digit Verification ........................96 Start/Stop Character ........................97 Code 93..............................98 Restore Factory Defaults ....................... 98 Enable/Disable Code 93 ........................ 98 Set Length Range for Code 93 ...................... 99 Check Digit Verification ........................
  • Page 10 Enable/Disable AIM-128 ......................113 Set Length Range for AIM-128 ....................114 Industrial 25 ............................115 Restore Factory Defaults ......................115 Enable/Disable Industrial 25 ......................115 Set Length Range for Industrial 25....................116 Check Digit Verification ........................ 117 Standard 25 ............................118 Restore Factory Defaults ......................
  • Page 11 Mirror Image ..........................134 Chinese Sensible Code ........................135 Restore Factory Defaults ......................135 Enable/Disable Chinese Sensible Code ..................135 Set Length Range for Chinese Sensible Code ................135 Chapter 6 Prefix & Suffix ..........................136 Introduction ............................136 General Settings ..........................137 Enable/Disable All Prefix/Suffix ....................
  • Page 12 Send Commands ......................... 155 Move Commands ........................158 Search Commands ........................160 Miscellaneous Commands ......................163 Chapter 9 Batch Programming ........................167 Introduction ............................167 Create a Batch Command ......................... 168 Create a Batch Barcode ........................169 Use Batch Barcode ..........................170 Appendix ...............................

  • Page 13: Preface

    Preface Introduction This manual provides detailed instructions for setting up and using the NLS-HR3290 series cordless 2D barcode scanner (hereinafter referred to as “HR32 cordless scanner” or “the scanner”). Chapter Description  Chapter 1, Getting Started Gives a general description of HR32 cordless scanner.

  • Page 14: Explanation Of Icons

    Explanation of Icons This icon indicates something relevant to this manual. This icon indicates this information requires extra attention from the reader. This icon indicates handy tips that can help you use or configure the scanner with ease. This icon indicates practical examples that can help you to acquaint yourself with operations.

  • Page 15: Chapter 1 Getting Started

    The HR32 cordless scanner reads a 1D or 2D barcode by capturing its image. Adopting the advanced technology independently developed by Newland Auto-ID Tech, it provides users with three scan modes, including Manual Mode, Sense Mode and Continuous Mode, tailored to different scanning needs.

  • Page 16: Scanner

    Scanner Decode/Transmission LED: Green: Barcode decoded successfully. Battery is fully charged. Blue: Zigbee is available. Red: Data transmission failed. Device is charging. Purple: Firmware update is in progress. There is data in FLASH memory. Fig. 1-1...

  • Page 17: Cd32 Cradle

    CD32 Cradle Buttons: P: Batch Transmission M: Pair/Search LEDs: Zigbee LED (blue): Zigbee is available. Battery LEDs (green): Indicate battery level (four levels) Fig. 1-2 Fig. 1-3...

  • Page 18: Communication Mode

    Communication Mode Communication modes: synchronous mode (default), asynchronous mode and batch mode.  Synchronous Mode: If Zigbee is available, scanned data will be transferred to the cradle immediately after a good read; if Zigbee is unavailable, the transmission of decoded data cannot be accomplished.

  • Page 19: Usb/Rs-232 Port

    USB/RS-232 Port CD32 cradle must be connected to a Host in actual application, such as PC, POS or any intelligent terminal with USB or RS-232 port, via a communication cable, either USB or RS-232 cable. USB port on the Host RS-232 RS-232 port on the Host Note: Please check the port on the Host and purchase the right cable.

  • Page 20: Using Usb Cable

    Using USB Cable Fig. 1-6 Connect the CD32 cradle to a Host through a USB cable with RJ45 and USB connectors: Plug the RJ45 connector into the data port (see Fig.1-3) on the cradle. Plug the USB connector into the USB port on the Host. Plug the supplied power adapter into the power port (see Fig.1-3) on the cradle.

  • Page 21: Using Rs-232 Cable

    Using RS-232 Cable Fig. 1-7 Connect the CD32 cradle to a Host through an RS-232 cable with RJ45 and RS-232 connectors: Plug the RJ45 connector into the data port (see Fig.1-3) on the cradle. Plug the RS-232 connector into the RS-232 port on the Host. Plug the supplied power adapter into the power port (see Fig.1-3) on the cradle.

  • Page 22: Power On, Sleep, Power Off, Reboot

    Power On, Sleep, Power Off, Reboot Powering on the scanner Hold down the trigger on the scanner for 1 second or longer. Entering the sleep mode If no operation is performed on the scanner for 5 seconds, it will automatically enter the sleep mode. (Applicable to the Manual mode only) Powering off the scanner Scan the Power Off barcode.

  • Page 23: Dimensions Of Scanner (Unit: Mm)

    Dimensions of Scanner (unit: mm) Side View Fig. 1-8 Front View Fig. 1-9 Top View Fig. 1-10...

  • Page 24: Dimensions Of Cd32 Cradle (Unit: Mm)

    Dimensions of CD32 Cradle (unit: mm) Fig. 1-11...

  • Page 25: Scanning Instructions

    Scanning Instructions When the scanner is in the Manual scan mode, you can follow the steps below to scan a barcode: Press and hold the trigger. Then the scanner will project a red aiming beam. Aim the red beam across the center of barcode, as shown in Fig.1-12. Release the trigger when the red beam goes off.
  • Page 26 Scan Angle The scanner is designed to function within a certain range of scan angles. Any unreasonable deviation may cause decoding failure. Scan angles of the scanner:  Pitch: ± 55° , 0° Roll and 0° Skew (Fig. 1-13)  Roll: 360°...

  • Page 27: Chapter 2 System Settings

    Enter Setup Chapter 2 System Settings Introduction There are two ways to configure the scanner: barcode programming and command programming. Barcode Programming The scanner can be configured through scanning programming barcodes. In the following sections, we will explain the available options and features and provide the barcodes to program them. This programming method is most straightforward.

  • Page 28: Programming Barcode/Command/Function

    Enter Setup Programming Barcode/Command/Function The figure above is an example that shows you the programming barcode and command for the Exit Setup function: 1. The Exit Setup barcode 2. The Exit Setup command 3. The function/feature that can be enabled by using the programming barcode or command listed above.

  • Page 29: Use Of Programming Barcodes

    Enter Setup Use of Programming Barcodes Scanning the Enter Setup barcode can enable the scanner to enter the setup mode. Then you can scan a number of programming barcodes to configure your scanner. To exit the setup mode, scan the Exit Setup barcode.

  • Page 30: Factory Defaults

    Enter Setup Factory Defaults Scanning the Reset Scanner barcode/the Reset Cradle barcode can restore the scanner/cradle to the factory default settings. You may need to reset your scanner/cradle when: 1. scanner/cradle is not properly configured so that the scanner fails to decode barcodes or to communicate with cradle;...

  • Page 31: Pairing Settings

    Enter Setup Pairing Settings Pair Scanner with Cradle A cradle with its DIP switch (see Fig. 1-3) in the “C” position works as a normal cradle. The scanner and cradle must be paired for communication to occur. A cradle can be paired with multiple scanners.

  • Page 32: Operating Mode Options

    Enter Setup Operating Mode Options Power Off Reboot Scanner Reboot Cradle ** Exit Setup...

  • Page 33: Power-Off Timeout

    Enter Setup Power-Off Timeout Power-off timeout specifies the amount of time the scanner remains in sleep mode before it powers off automatically. Scan the barcode below to set this parameter. ** 5 Minutes 10 Minutes 20 Minutes 30 Minutes 60 Minutes Disable Auto Power Off ** Exit Setup...

  • Page 34: Illumination

    Enter Setup Illumination A couple of illumination options are provided to improve the lighting conditions during every image capture:  Normal: Illumination LEDs are turned on only when scanner is reading barcode.  Always ON: Illumination LEDs keep ON after scanner is powered on. ...

  • Page 35: Aiming

    Enter Setup Aiming When scanning/capturing image, the scanner projects an aiming pattern which allows positioning the target barcode within its field of view and thus makes decoding easier.  Normal: The scanner projects an aiming pattern only during barcode scanning/capture. ...

  • Page 36: Beep

    Enter Setup Beep Good Read Beep Scan the appropriate barcode below to enable or disable the emission of beep when a non-programming barcode is decoded. ** Good Read Beep On Good Read Beep Off Good Read Beep Type Type 1 ** Type 3 Type 2 ** Exit Setup...

  • Page 37: Good Read Beep Volume

    Enter Setup Good Read Beep Volume ** Loud Medium Startup Beep ** Startup Beep On Startup Beep Off ** Exit Setup...

  • Page 38: Transmit Ngr Message

    Enter Setup Transmit NGR Message Scan a barcode below to select whether or not to transmit a user-defined NGR (Not Good Read) message when a barcode is not decoded. Transmit NGR Message ** Do Not Transmit NGR Message Edit NGR Message To edit an NGR message, scan the Edit NGR Message barcode and the numeric barcodes corresponding to the ASCII values (decimal) of desired character(s) and then scan the Save barcode.

  • Page 39: Scan Mode

    Enter Setup Scan Mode Manual Mode A trigger pull activates a decode session. The decode session continues until the barcode is decoded or you release the trigger or decode session timeout expires. ** Manual Mode Decode Session Timeout This parameter sets the maximum time decode session continues during a scan attempt. It is programmable in 1ms increments from 100ms to 3,600,000ms.

  • Page 40: Level Trigger/Pulse Trigger

    Enter Setup Level Trigger/Pulse Trigger Level Trigger: During a scan attempt, the decode session ends once the Trigger is released. Pulse Trigger: During a scan attempt, the release of the Trigger does not affect the decode session. ** Level Trigger Pulse Trigger Auto Sleep Auto Sleep allows the scanner in the Manual Mode to automatically enter the sleep or low power mode if...
  • Page 41 Enter Setup The parameter below specifies how long the scanner remains idle (no operation or communication occurs) before it is put into sleep mode. It is programmable in 1ms increments from 0ms to 65,535ms. The default setting is 500ms. Time Period from Idle to Sleep Set the Time Period from Idle to Sleep to 500ms: 1.

  • Page 42: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. To enable/disable the Timeout between Decodes (Same Barcode), scan the appropriate barcode below. Enable Timeout between Decodes: Do not allow the scanner to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 43: Sense Mode

    Enter Setup Sense Mode The scanner waits for the image stabilization timeout to expire before activating a decode session every time it detects a change in ambient illumination. Decode session continues until the barcode is decoded or the decode session timeout expires. In the Sense mode, a trigger pull can also activate a decode session.

  • Page 44: Image Stabilization Timeout

    Enter Setup Image Stabilization Timeout This parameter defines the amount of time that the scanner waits for the image to stabilize to a point that it can be decoded with more accuracy. It is programmable in 1ms increments from 0ms to 1,600ms. The default setting is 500ms.

  • Page 45: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. To enable/disable the Timeout between Decodes (Same Barcode), scan the appropriate barcode below. Enable Timeout between Decodes: Do not allow the scanner to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 46: Sensitivity

    Enter Setup Sensitivity Sensitivity specifies the degree of acuteness of the scanner’s response to changes in ambient illumination. The higher the sensitivity, the lower requirement in illumination change to trigger the scanner. You can select an appropriate degree of sensitivity that fits the ambient environment. Medium Sensitivity Low Sensitivity High Sensitivity...

  • Page 47: Continuous Mode

    Enter Setup Continuous Mode If the Continuous mode is enabled, the scanner automatically starts one decode session after another. To suspend/resume barcode reading, simply press the trigger. Continuous Mode Decode Session Timeout This parameter sets the maximum time decode session continues during a scan attempt. It is programmable in 1ms increments from 100ms to 3,600,000ms.

  • Page 48: Timeout Between Decodes

    Enter Setup Timeout between Decodes This parameter sets the timeout between decode sessions. When a decode session ends, next session will not happen until the timeout between decodes expires. It is programmable in 1ms increments from 0ms to 65,535ms. The default setting is 1,000ms. Timeout between Decodes Set the Timeout between Decodes to 1,500ms: 1.

  • Page 49: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. To enable/disable the Timeout between Decodes (Same Barcode), scan the appropriate barcode below. Enable Timeout between Decodes: Do not allow the scanner to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 50: Decode Area

    Enter Setup Decode Area Whole Area Decoding When this option is enabled, the scanner attempts to decode barcode(s) within its field of view, from the center to the periphery, and transmits the barcode that has been first decoded. ** Whole Area Decoding Specific Area Decoding The scanner attempts to read barcode(s) within a specified decoding area and transmits the barcode that has been first decoded.
  • Page 51 Enter Setup You can define the decoding area using the Top of Decoding Area, Bottom of Decoding Area, Left of Decoding Area and Right of Decoding Area barcodes as well as numeric barcode(s) that represent(s) a desired percentage (0-100). Barcode 1 Barcode 2 100% Top of Decoding Area...
  • Page 52 Enter Setup 2. Scan the Specific Area Decoding barcode. 3. Scan the Top of Decoding Area barcode. 4. Scan the numeric barcodes “2” and “0”. (See the Digit Barcodes in Appendix) 5. Scan the Save barcode. (See the Save/Cancel Barcodes in Appendix) 6.

  • Page 53: Chapter 3 Inquiry Commands

    Enter Setup Chapter 3 Inquiry Commands Introduction This chapter provides programming barcodes you may need to obtain device information. Obtain Scanner Information You can scan the barcode below to inquire the scanner information (such as model number, serial number, manufacture date and firmware version). The result will be sent to the Host. Inquire All Information About Scanner Obtain Cradle Information You can scan the barcode below to inquire the cradle information (such as model number, serial number,...

  • Page 54: Obtain Flash Information

    Enter Setup Obtain FLASH Information To inquire the number of the barcodes stored in flash memory or empty the memory, scan the appropriate barcode below. Inquire the Number of Barcodes in Flash Memory Delete All Barcodes in Flash Memory ** Exit Setup...

  • Page 55: Chapter 4 Communication Settings

    Enter Setup Chapter 4 Communication Settings Introduction Three types of wireless communication between scanner and cradle: synchronous, asynchronous and batch modes. Two types of wired communication between cradle and the Host: RS-232 and USB. Wireless Communication Wireless communication modes include Synchronous (default), Asynchronous and Batch modes. ...

  • Page 56: Host Acknowledgment

    Enter Setup Host Acknowledgment Some applications require that the host device validate incoming barcode data and provide acknowledgment to the scanner. When Host Acknowledgment is turned on, the scanner waits for this acknowledgment after each scan. If scanned data is deemed valid, the host device returns 0x06 and the green LED on the scanner flashes thrice along with the Validation Passed beep;...

  • Page 57: Rs-232 Interface

    Enter Setup RS-232 Interface Baud Rate When the CD32 cradle is connected to the Host via serial port, you need to set communication parameters (including baud rate, parity check, data bit and stop bit) to match the host device. Baud rate is the number of bits of data transmitted per second. Set the cradle’s baud rate to match the Host requirements.

  • Page 58: Parity Check

    Enter Setup Parity Check By default, the None option is enabled. ** None Even Stop Bit By default, the 1 Stop Bit option is enabled. ** 1 Stop Bit 2 Stop Bits ** Exit Setup...

  • Page 59: Hareware Flow Control

    Enter Setup Hareware Flow Control By default, the hardware flow control is disabled. ** Disable Hardware Flow Control Enable Hardware Flow Control Before enabling hardware flow control, make sure that RTS/CTS signal line is contained in RS-232 cable. Without the signal line, RS-232 communication errors will occur.

  • Page 60: Usb Interface

    Enter Setup USB Interface Two communication options are provided when the cradle is connected to the Host via USB interface: USB HID-KBW and USB COM Port Emulation USB HID-KBW ** USB HID-KBW Examine KBW Connection By default, the scanner examines whether KBW connection is available before data transmission by sending the Caps Lock key to the host device first.

  • Page 61: Usb Country Keyboard Types

    Enter Setup USB Country Keyboard Types Keyboard layouts vary from country to country. The default setting is U.S. keyboard. ** U.S. Japanese Denmark Finland France Turkey F Italy Norway ** Exit Setup...
  • Page 62 Enter Setup Spain Turkey Q Germany Belgium Russia Sweden Portugal ** Exit Setup...

  • Page 63: Inter-Keystroke Delay

    Enter Setup Inter-Keystroke Delay This parameter specifies the delay between emulated keystrokes. ** No Delay 40ms 20ms 60ms 80ms ** Exit Setup...

  • Page 64: Convert Case

    Enter Setup Convert Case Scan the appropriate barcode below to convert barcode data to your desired case. ** No Case Conversion Convert All to Lower Case Convert All to Upper Case Invert Upper and Lower Case Characters When the Invert Upper and Lower Case Characters feature is enabled, barcode data “AbC”...

  • Page 65: Emulate Alt+Keypad

    Enter Setup Emulate ALT+Keypad This feature allows any ASCII character (0x00 - 0xFF) to be sent over the numeric keypad no matter which keyboard type is selected. Since sending a character involves multiple keystroke emulations, this method appears less efficient. The following options are available: ...

  • Page 66: Function Key Mapping

    Enter Setup Function Key Mapping When Function Key Mapping is enabled, function characters (0x00 - 0x1F) are sent as ASCII sequences over the keypad. For more information, see ASCII Function Key Mapping Table in Appendix. Enable Function Key Mapping ** Disable Function Key Mapping Example: Barcode data 0x16 Enable Function Key Mapping Ctrl+V...

  • Page 67: Emulate Numeric Keypad

    Enter Setup Emulate Numeric Keypad When this feature is disabled, sending barcode data is emulated as keystroke(s) on main keyboard. To enable this feature, scan the Emulate Numeric Keypad barcode. Sending a number (0-9) is emulated as keystroke(s) on numeric keypad, whereas sending other character like “+”, “_”, “*” , “/” and “.” is still emulated as keystrokes on main keyboard.

  • Page 68: Usb Com Port Emulation

    Enter Setup USB COM Port Emulation To use this feature, a driver is required. USB COM Port Emulation USB HID-POS Introduction The USB HID-POS interface is recommended for new application programs. It can send up to 56 characters in a single USB report and appears more efficient than keyboard emulation. Features: ...

  • Page 69: Acquire Scanned Data

    Output data (1-62) VID/PID USB uses VID (Vendor ID) and PID (Product ID) to identify and locate a device. The VID is assigned by USB Implementers Forum. Newland’s vendor ID is 1EAB (Hex). A PID is assigned to each interface. Product Interface...

  • Page 70: Chapter 5 Symbologies

    Enter Setup Chapter 5 Symbologies Introduction Every symbology (barcode type) has its own unique attributes. This chapter provides programming barcodes for configuring the scanner so that it can identify various barcode symbologies. The more symbologies you enable, the slower your scanner decodes. It is recommended to disable those that are rarely used to improve the performance of the scanner.

  • Page 71: Enable 1D Symbologies

    Enter Setup Enable 1D Symbologies Enable 1D Symbologies Disable 1D Symbologies Disable 1D Symbologies Enable 2D Symbologies Enable 2D Symbologies Disable 2D Symbologies Disable 2D Symbologies ** Exit Setup...

  • Page 72: Video Reverse

    Enter Setup Video Reverse The Video Reverse feature only applies to 2D barcodes. Regular barcode: Dark image on a bright background. Inverse barcode: Bright image on a dark background. The examples of regular barcode and inverse barcode are shown below. Regular Barcode Inverse Barcode Video Reverse is used to allow the scanner to read barcodes that are inverted.

  • Page 73: Code 128

    Enter Setup Code 128 Restore Factory Defaults Restore the Factory Defaults of Code 128 Enable/Disable Code 128 ** Enable Code 128 Disable Code 128 If the scanner fails to identify Code 128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 128 barcode.

  • Page 74: Set Length Range For Code 128

    Enter Setup Set Length Range for Code 128 The scanner can be configured to only decode Code 128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 75: Restore Factory Defaults

    Enter Setup EAN-8 Restore Factory Defaults Restore the Factory Defaults of EAN-8 Enable/Disable EAN-8 ** Enable EAN-8 Disable EAN-8 Transmit Check Digit EAN-8 is 8 digits in length with the last one as its check digit used to verify the integrity of the data. ** Transmit EAN-8 Check Digit Do Not Transmit EAN-8 Check Digit ** Exit Setup...

  • Page 76: Add-On Code

    Enter Setup Add-On Code An EAN-8 barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is an EAN-8 barcode while the part circled by red dotted line is add-on code.

  • Page 77: Add-On Code Required

    Enter Setup Add-On Code Required EAN-8 Add-On Code Required: The scanner only decodes EAN-8 barcodes that contain add-on codes. EAN-8 Add-On Code Not Required: The scanner decodes a mix of EAN-8 barcodes with and without add-on codes. EAN-8 Add-On Code Required ** EAN-8 Add-On Code Not Required EAN-8 Extension Disable EAN-8 Zero Extend: Transmit EAN-8 barcodes as is.

  • Page 78: Restore Factory Defaults

    Enter Setup EAN-13 Restore Factory Defaults ** Restore the Factory Defaults of EAN-13 Enable/Disable EAN-13 ** Enable EAN-13 Disable EAN-13 Transmit Check Digit ** Transmit EAN-13 Check Digit Do Not Transmit EAN-13 Check Digit ** Exit Setup...

  • Page 79: Add-On Code

    Enter Setup Add-On Code An EAN-13 barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is an EAN-13 barcode while the part circled by red dotted line is add-on code.

  • Page 80: Add-On Code Required

    Enter Setup Add-On Code Required EAN-13 Add-On Code Required: The scanner only decodes EAN-13 barcodes that contain add-on codes. EAN-13 Add-On Code Not Required: The scanner decodes a mix of EAN-13 barcodes with and without add-on codes. EAN-13 Add-On Code Required ** EAN-13 Add-On Code Not Required ** Exit Setup...

  • Page 81: Ean-13 Beginning With 290 Add-On Code Required

    Enter Setup EAN-13 Beginning with 290 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “290”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “290” must have a 2-digit or 5-digit add-on code.

  • Page 82: Ean-13 Beginning With 414/419 Add-On Code Required

    Enter Setup EAN-13 Beginning with 414/419 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with a “414” or “419”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with a “414” or “419” must have a 2-digit or 5-digit add-on code.

  • Page 83: Ean-13 Beginning With 977 Add-On Code Required

    Enter Setup EAN-13 Beginning with 977 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “977”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “977” must have a 2-digit or 5-digit add-on code.

  • Page 84: Ean-13 Beginning With 979 Add-On Code Required

    Enter Setup EAN-13 Beginning with 979 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “979”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “979” must have a 2-digit or 5-digit add-on code.

  • Page 85: Upc-E

    Enter Setup UPC-E Restore Factory Defaults ** Restore the Factory Defaults of UPC-E Enable/Disable UPC-E ** Enable UPC-E Disable UPC-E If the scanner fails to identify UPC-E barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UPC-E barcode. Transmit Check Digit UPC-E is 8 digits in length with the last one as its check digit used to verify the integrity of the data.

  • Page 86: Add-On Code

    Enter Setup Add-On Code A UPC-E barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is a UPC-E barcode while the part circled by red dotted line is add-on code.

  • Page 87: Add-On Code Required

    Enter Setup Add-On Code Required UPC-E Add-On Code Required: The scanner only decodes UPC-E barcodes that contain add-on codes. UPC-E Add-On Code Not Required: The scanner decodes a mix of UPC-E barcodes with and without add-on codes. UPC-E Add-On Code Required ** UPC-E Add-On Code Not Required Transmit System Character “0”...

  • Page 88: Upc-E Extension

    Enter Setup UPC-E Extension Disable UPC-E Extend: Transmit UPC-E barcodes as is. Enable UPC-E Extend: Extend UPC-E barcodes to make them compatible in length to UPC-A. ** Disable UPC-E Extend Enable UPC-E Extend ** Exit Setup...

  • Page 89: Upc-A

    Enter Setup UPC-A Restore Factory Defaults Restore the Factory Defaults of UPC-A Enable/Disable UPC-A ** Enable UPC-A Disable UPC-A If the scanner fails to identify UPC-A barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UPC-A barcode. Transmit Check Digit UPC-A is 12 digits in length with the last one as its check digit used to verify the integrity of the data.

  • Page 90: Add-On Code

    Enter Setup Add-On Code A UPC-A barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is a UPC-A barcode while the part circled by red dotted line is add-on code.

  • Page 91: Add-On Code Required

    Enter Setup Add-On Code Required UPC-A Add-On Code Required: The scanner only decodes UPC-A barcodes that contain add-on codes. UPC-A Add-On Code Not Required: The scanner decodes a mix of UPC-A barcodes with and without add-on codes. UPC-A Add-On Code Required ** UPC-A Add-On Code Not Required Transmit Preamble Character Preamble characters (Country Code and System Character) can be transmitted as part of a UPC-A...

  • Page 92: Interleaved 2 Of 5

    Enter Setup Interleaved 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 ** Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 If the scanner fails to identify Interleaved 2 of 5 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Interleaved 2 of 5 barcode.

  • Page 93: Set Length Range For Interleaved 2 Of 5

    Enter Setup Set Length Range for Interleaved 2 of 5 The scanner can be configured to only decode Interleaved 2 of 5 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 94: Check Digit Verification

    Enter Setup Check Digit Verification A check digit is optional for Interleaved 2 of 5 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Interleaved 2 of 5 barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Interleaved 2 of 5 barcodes to verify that the data complies with the check digit algorithm.

  • Page 95: Febraban

    Enter Setup Febraban Disable/Enable Febraban ** Disable Febraban Enable Febraban, Do Not Expand Enable Febraban, Expand ** Exit Setup...
  • Page 96 Enter Setup ITF-14 ITF-14 is a special kind of Interleaved 2 of 5 with a length of 14 characters and the last character as the check character. Restore the Factory Defaults of ITF-14 ** Disable ITF-14 Enable ITF-14 But Do Not Transmit Check Digit Enable ITF-14 and Transmit Check Digit It is advisable not to enable ITF-14 and Interleaved 2 of 5 at the same time.
  • Page 97 Enter Setup ITF-6 ITF-6 is a special kind of Interleaved 2 of 5 with a length of 6 characters and the last character as the check character. Restore the Factory Defaults of ITF-6 ** Disable ITF-6 Enable ITF-6 But Do Not Transmit Check Digit Enable ITF-6 and Transmit Check Digit It is advisable not to enable ITF-6 and Interleaved 2 of 5 at the same time.

  • Page 98: Matrix 2 Of 5

    Enter Setup Matrix 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Matrix 2 of 5 Enable/Disable Matrix 2 of 5 Enable Matrix 2 of 5 ** Disable Matrix 2 of 5 If the scanner fails to identify Matrix 2 of 5 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Matrix 2 of 5 barcode.

  • Page 99: Set Length Range For Matrix 2 Of 5

    Enter Setup Set Length Range for Matrix 2 of 5 The scanner can be configured to only decode Matrix 2 of 5 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 100: Check Digit Verification

    Enter Setup Check Digit Verification A check digit is optional for Matrix 2 of 5 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Matrix 2 of 5 barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Matrix 2 of 5 barcodes to verify that the data complies with the check digit algorithm.

  • Page 101: Code 39

    Enter Setup Code 39 Restore Factory Defaults Restore the Factory Defaults of Code 39 Enable/Disable Code 39 ** Enable Code 39 Disable Code 39 If the scanner fails to identify Code 39 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 39 barcode.

  • Page 102: Set Length Range For Code 39

    Enter Setup Set Length Range for Code 39 The scanner can be configured to only decode Code 39 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 103: Check Digit Verification

    Enter Setup Check Digit Verification A check digit is optional for Code 39 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Code 39 barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Code 39 barcodes to verify that the data complies with the check digit algorithm.

  • Page 104: Enable/Disable Code 39 Full Ascii

    Enter Setup Enable/Disable Code 39 Full ASCII The scanner can be configured to identify all ASCII characters by scanning the appropriate barcode below. Disable Code 39 Full ASCII ** Enable Code 39 Full ASCII Enable/Disable Code 32 Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable Code 32.

  • Page 105: Transmit Code 32 Check Digit

    Enter Setup Transmit Code 32 Check Digit Code 32 must be enabled for this parameter to function. ** Do Not Transmit Code 32 Check Digit Transmit Code 32 Check Digit Transmit Code 32 Start/Stop Character Code 32 must be enabled for this parameter to function. ** Do Not Transmit Code 32 Start/Stop Character Transmit Code 32 Start/Stop Character ** Exit Setup...

  • Page 106: Codabar

    Enter Setup Codabar Restore Factory Defaults Restore the Factory Defaults of Codabar Enable/Disable Codabar ** Enable Codabar Disable Codabar If the scanner fails to identify Codabar barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Codabar barcode. ** Exit Setup...

  • Page 107: Set Length Range For Codabar

    Enter Setup Set Length Range for Codabar The scanner can be configured to only decode Codabar barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. Set the Minimum Length (Default: 1) Set the Maximum Length (Default: 127) Maximum length of a 1D barcode should not exceed 127 bytes.

  • Page 108: Check Digit Verification

    Enter Setup Check Digit Verification A check digit is optional for Codabar and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Codabar barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Codabar barcodes to verify that the data complies with the check digit algorithm.

  • Page 109: Start/Stop Character

    Enter Setup Start/Stop Character You can set the start/stop characters and choose whether or not to transmit the start/stop characters by scanning the appropriate barcode below. Transmit Start/Stop Character ** Do Not Transmit Start/Stop Character ** ABCD/ABCD as the Start/Stop Character Start/Stop Character in Uppercase ABCD/TN*E as the Start/Stop Character Start/Stop Character in Lowercase...

  • Page 110: Code 93

    Enter Setup Code 93 Restore Factory Defaults Restore the Factory Defaults of Code 93 Enable/Disable Code 93 ** Enable Code 93】 Disable Code 93 If the scanner fails to identify Code 93 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 93 barcode.

  • Page 111: Set Length Range For Code 93

    Enter Setup Set Length Range for Code 93 The scanner can be configured to only decode Code 93 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 112: Check Digit Verification

    Enter Setup Check Digit Verification Check digits are optional for Code 93 and can be added as the last two digits, which are calculated values used to verify the integrity of the data. Disable: The scanner transmits Code 93 barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Code 93 barcodes to verify that the data complies with the check digit algorithm.

  • Page 113: Ucc/Ean-128

    Enter Setup UCC/EAN-128 Restore Factory Defaults Restore the Factory Defaults of UCC/EAN-128 Enable/Disable UCC/EAN-128 ** Enable UCC/EAN-128 Disable UCC/EAN-128 If the scanner fails to identify UCC/EAN-128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UCC/EAN-128 barcode. ** Exit Setup...

  • Page 114: Set Length Range For Ucc/Ean-128

    Enter Setup Set Length Range for UCC/EAN-128 The scanner can be configured to only decode UCC/EAN-128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. Set the Minimum Length (Default: 1) Set the Maximum Length (Default: 127) Maximum length of a 1D barcode should not exceed 127 bytes.

  • Page 115: Gs1 Databar

    Enter Setup GS1 Databar Restore Factory Defaults Restore the Factory Defaults of GS1 Databar Enable/Disable GS1 Databar ** Enable GS1 Databar Disable GS1 Databar If the scanner fails to identify GS1 Databar barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable GS1 Databar barcode.

  • Page 116: Code 11

    Enter Setup Code 11 Restore Factory Defaults Restore the Factory Defaults of Code 11 Enable/Disable Code 11 ** Enable Code 11 Disable Code 11 If the scanner fails to identify Code 11 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 11 barcode.

  • Page 117: Set Length Range For Code 11

    Enter Setup Set Length Range for Code 11 The scanner can be configured to only decode Code 11 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 118: Check Digit Verification

    Enter Setup Check Digit Verification Check digits are optional for Code 11 and can be added as the last one or two digits, which are calculated values used to verify the integrity of the data. If the Disable option is enabled, the scanner transmits Code 11 barcodes as is. One Check Digit, MOD11 (Len<=10) Disable Two Check Digits, MOD11/MOD11(Len>10)

  • Page 119: Isbn

    Enter Setup ISBN Restore Factory Defaults Restore the Factory Defaults of ISBN Enable/Disable ISBN Enable ISBN ** Disable ISBN If the scanner fails to identify ISBN barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable ISBN barcode. Set ISBN Format ** ISBN-13 ISBN-10...

  • Page 120: Add-On Code

    Enter Setup Add-On Code An ISBN barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code ** Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code ** Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of ISBN barcodes with and without 2-digit/5-digit add-on codes.

  • Page 121: Add-On Code Required

    Enter Setup Add-On Code Required ISBN Add-On Code Required: The scanner only decodes ISBN barcodes that contain add-on codes. ISBN Add-On Code Not Required: The scanner decodes a mix of ISBN barcodes with and without add-on codes. ISBN Add-On Code Required ** ISBN Add-On Code Not Required ** Exit Setup...

  • Page 122: Issn

    Enter Setup ISSN Restore Factory Defaults Restore the Factory Defaults of ISSN Enable/Disable ISSN Enable ISSN ** Disable ISSN If the scanner fails to identify ISSN barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable ISSN barcode. ** Exit Setup...

  • Page 123: Add-On Code

    Enter Setup Add-On Code An ISSN barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code ** Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code ** Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of ISSN barcodes with and without 2-digit/5-digit add-on codes.

  • Page 124: Add-On Code Required

    Enter Setup Add-On Code Required ISSN Add-On Code Required: The scanner only decodes ISSN barcodes that contain add-on codes. ISSN Add-On Code Not Required: The scanner decodes a mix of ISSN barcodes with and without add-on codes. ISSN Add-On Code Required ** ISSN Add-On Code Not Required ** Exit Setup...

  • Page 125: Aim-128

    Enter Setup AIM-128 Restore Factory Defaults Restore the Factory Defaults of AIM-128 Enable/Disable AIM-128 ** Enable AIM-128 Disable AIM-128 If the scanner fails to identify AIM-128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable AIM-128 barcode. ** Exit Setup...

  • Page 126: Set Length Range For Aim-128

    Enter Setup Set Length Range for AIM-128 The scanner can be configured to only decode AIM-128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. Set the Minimum Length (Default: 1) Set the Maximum Length (Default: 127) Maximum length of a 1D barcode should not exceed 127 bytes.

  • Page 127: Industrial 25

    Enter Setup Industrial 25 Restore Factory Defaults Restore the Factory Defaults of Industrial 25 Enable/Disable Industrial 25 ** Enable Industrial 25 Disable Industrial 25 If the scanner fails to identify Industrial 25 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Industrial 25 barcode.

  • Page 128: Set Length Range For Industrial 25

    Enter Setup Set Length Range for Industrial 25 The scanner can be configured to only decode Industrial 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 129: Check Digit Verification

    Enter Setup Check Digit Verification A check digit is optional for Industrial 25 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Industrial 25 barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Industrial 25 barcodes to verify that the data complies with the check digit algorithm.

  • Page 130: Standard 25

    Enter Setup Standard 25 Restore Factory Defaults Restore the Factory Defaults of Standard 25 Enable/Disable Standard 25 ** Enable Standard 25 Disable Standard 25 If the scanner fails to identify Standard 25 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Standard 25 barcode.

  • Page 131: Set Length Range For Standard 25

    Enter Setup Set Length Range for Standard 25 The scanner can be configured to only decode Standard 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 132: Check Digit Verification

    Enter Setup Check Digit Verification A check digit is optional for Standard 25 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Standard 25 barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Standard 25 barcodes to verify that the data complies with the check digit algorithm.

  • Page 133: Plessey

    Enter Setup Plessey Restore Factory Defaults Restore the Factory Defaults of Plessey Enable/Disable Plessey Enable Plessey ** Disable Plessey If the scanner fails to identify Plessey barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Plessey barcode. ** Exit Setup...

  • Page 134: Set Length Range For Plessey

    Enter Setup Set Length Range for Plessey The scanner can be configured to only decode Plessey barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. Set the Minimum Length (Default: 1) Set the Maximum Length (Default: 127) Maximum length of a 1D barcode should not exceed 127 bytes.

  • Page 135: Check Digit Verification

    Enter Setup Check Digit Verification Check digits are optional for Plessey and can be added as the last two digits, which are calculated values used to verify the integrity of the data. Disable: The scanner transmits Plessey barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Plessey barcodes to verify that the data complies with the check digit algorithm.

  • Page 136: Msi-Plessey

    Enter Setup MSI-Plessey Restore Factory Defaults Restore the Factory Defaults of MSI-Plessey Enable/Disable MSI-Plessey Enable MSI-Plessey ** Disable MSI-Plessey If the scanner fails to identify MSI-Plessey barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable MSI-Plessey barcode. ** Exit Setup...

  • Page 137: Set Length Range For Msi-Plessey

    Enter Setup Set Length Range for MSI-Plessey The scanner can be configured to only decode MSI-Plessey barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. Set the Minimum Length (Default: 2) Set the Maximum Length (Default: 127) Maximum length of a 1D barcode should not exceed 127 bytes.

  • Page 138: Check Digit Verification

    Enter Setup Check Digit Verification Check digits are optional for MSI-Plessey and can be added as the last one or two digits, which are calculated values used to verify the integrity of the data. If the Disable option is enabled, the scanner transmits MSI-Plessey barcodes as is. Disable Two Check Digits, MOD10/MOD11 ** One Check Digit, MOD10...

  • Page 139: Pdf417

    Enter Setup PDF417 Restore Factory Defaults ** Restore the Factory Defaults of PDF417 Enable/Disable PDF417 ** Enable PDF417 Disable PDF417 If the scanner fails to identify PDF417 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable PDF417 barcode. ** Exit Setup...

  • Page 140: Set Length Range For Pdf417

    Enter Setup Set Length Range for PDF417 The scanner can be configured to only decode PDF417 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. Set the Minimum Length (Default: 1) Set the Maximum Length (Default: 1024) Maximum length of a 2D barcode should not exceed 1024 bytes.

  • Page 141: Qr Code

    Enter Setup QR Code Restore Factory Defaults Restore the Factory Defaults of QR Code Enable/Disable QR Code ** Enable QR Code Disable QR Code If the scanner fails to identify QR Code barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable QR Code barcode.

  • Page 142: Set Length Range For Qr Code

    Enter Setup Set Length Range for QR Code The scanner can be configured to only decode QR Code barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 143: Micro Qr

    Enter Setup Micro QR ** Enable Micro QR Disable Micro QR ** Exit Setup...

  • Page 144: Data Matrix

    Enter Setup Data Matrix Restore Factory Defaults Restore the Factory Defaults of Data Matrix Enable/Disable Data Matrix ** Enable Data Matrix Disable Data Matrix If the scanner fails to identify Data Matrix barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Data Matrix barcode.

  • Page 145: Set Length Range For Data Matrix

    Enter Setup Set Length Range for Data Matrix The scanner can be configured to only decode Data Matrix barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 146: Rectangular Barcode

    Enter Setup Rectangular Barcode Data Matrix has two formats: Square barcodes having the same amount of modules in length and width: 10*10, 12*12..144*144. Rectangular barcodes having different amounts of models in length and width: 6*16, 6*14... 14*22. ** Enable Rectangular Barcode Disable Rectangular Barcode Mirror Image ** Decode Mirrored DM...

  • Page 147: Chinese Sensible Code

    Enter Setup Chinese Sensible Code Restore Factory Defaults Restore the Factory Defaults of Chinese Sensible Code Enable/Disable Chinese Sensible Code Enable Chinese Sensible Code ** Disable Chinese Sensible Code Set Length Range for Chinese Sensible Code Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 148: Chapter 6 Prefix & Suffix

    Enter Setup Chapter 6 Prefix & Suffix Introduction A 1D barcode could contain digits, letters, symbols, etc. A 2D barcode could contain more data, such as Chinese characters and other multi-byte characters. However, in real applications, they do not and should not have all information we need, such as barcode type, data acquisition time and delimiter, in order to keep the barcodes short and flexible.

  • Page 149: General Settings

    Enter Setup General Settings Enable/Disable All Prefix/Suffix Disable All Prefix/Suffix: Transmit barcode data with no prefix/suffix. Enable All Prefix/Suffix: Allow user to append Code ID prefix, AIM ID prefix, custom prefix/suffix and terminating character to the barcode data before the transmission. Disable All Prefix/Suffix】...

  • Page 150: Custom Prefix

    Enter Setup Custom Prefix Enable/Disable Custom Prefix If custom prefix is enabled, you are allowed to append to the data a user-defined prefix that cannot exceed 10 characters. For example, if the custom prefix is “AB” and the barcode data is “123”, the Host will receive “AB123”.

  • Page 151: Aim Id Prefix

    Enter Setup AIM ID Prefix AIM (Automatic Identification Manufacturers) ID defines symbology identifier (For the details, see the AIM ID Table in Appendix). If AIM ID prefix is enabled, the scanner will add the symbology identifier before the scanned data after decoding. ** Disable AIM ID Prefix Enable AIM ID Prefix AIM ID is not user programmable.

  • Page 152: Restore All Default Code Ids

    Enter Setup Restore All Default Code IDs For the information of default Code IDs, see the Code ID Table in Appendix. Restore All Default Code IDs Modify Code ID See the examples below to learn how to modify a Code ID and restore the default Code IDs of all symbologies.
  • Page 153 Enter Setup Modify PDF417 Code ID Modify Data Matrix Code ID Modify QR Code ID Modify Chinese Sensible Code ID Modify Matrix 25 Code ID Modify ISSN Code ID Modify AIM-128 Code ID Modify EAN-8 Code ID Modify ITF-6 Code ID Modify EAN-13 Code ID ** Exit Setup...
  • Page 154 Enter Setup Modify Code 39 Code ID Modify UPC-E Code ID Modify Codabar Code ID Modify UPC-A Code ID Modify Code 93 Code ID Modify Interleaved 2 of 5 Code ID Modify Code 128 Code ID Modify ITF-14 Code ID Modify ISBN Code ID Modify UCC/EAN-128 Code ID ** Exit Setup...
  • Page 155 Enter Setup Modify Industrial 25 Code ID Modify Code 11 Code ID Modify Standard 25 Code ID Modify Plessey Code ID Modify MSI-Plessey Code ID Modify GS1 Databar Code ID ** Exit Setup...

  • Page 156: Custom Suffix

    Enter Setup Custom Suffix Enable/Disable Custom Suffix If custom suffix is enabled, you are allowed to append to the data a user-defined suffix that cannot exceed 10 characters. For example, if the custom suffix is “AB” and the barcode data is “123”, the Host will receive “123AB”.

  • Page 157: Terminating Character Suffix

    Enter Setup Terminating Character Suffix Enable/Disable Terminating Character Suffix A terminating character such as carriage return (CR) or carriage return/line feed pair (CRLF) can only be used to mark the end of data, which means nothing can be added after it. Disable Terminating Character Suffix ** Enable Terminating Character Suffix Set Terminating Character Suffix...
  • Page 158 Enter Setup To set a terminating character suffix, scan the Set Terminating Character Suffix barcode and the numeric barcodes representing the hexadecimal value of a desired terminating character and then scan the Save barcode. Refer to the ASCII Table in Appendix for hexadecimal values of terminating characters.

  • Page 159: Chapter 7 Ambient Illumination

    Enter Setup Chapter 7 Ambient Illumination Ambient lighting conditions may vary from one operating environment to another, such as fluorescent lit warehouses or sunlit open spaces. Fluorescent lights may flicker when using AC power source in 50-60Hz. Usually indoor illuminance is around 1,000 lux while outdoor illuminance may reach 60,000 lux or even over 100,000 lux.

  • Page 160: Chapter 8 Data Formatter

    Enter Setup Chapter 8 Data Formatter Introduction You may use the Data Formatter to modify the scanner’s output. For example, you can use the Data Formatter to insert characters at certain points in barcode data or to suppress/ replace/ send certain characters in barcode data as it is scanned.

  • Page 161: Programming With Barcodes

    Enter Setup Programming with Barcodes The following explains how to program a data format by scanning the specific barcodes. Scanning any irrelevant barcode or failing to follow the setting procedure will result in programming failure. To find the alphanumeric barcodes needed to create a data format, see the Digit Barcodes in Appendix. Step 1: Scan the Enter Setup barcode.
  • Page 162 Enter Setup Step 8: Enter formatter command Refer to the Formatter Command Type 6 in this chapter. Scan the alphanumeric barcodes that represent the command you need to edit data. For example, when a command is F141, you should scan F141.

  • Page 163: Programming With A Batch Command

    Enter Setup Programming with a Batch Command A data format can also be created by a batch command sent from the host device. Syntax: “nls0323000” + “=” + Double Quotation Mark (”) + Parameter Value + Double Quotation Mark (”) + “;” Parameter Value consists of the following elements: Data format: 0~3 (1 character).

  • Page 164: Enable Data Format

    Enter Setup Enable Data Format After enabling the Data Formatter, you may select a data format you want to use by scanning the appropriate barcode below. ** Format_0 Format_1 Format_2 Format_3 Change Data Format for a Single Scan You can switch between data formats for a single scan. The next barcode is scanned using the data format selected here, then reverts to the format you have selected above.

  • Page 165: Enable/Disable Data Formatter

    Enter Setup Enable/Disable Data Formatter When Data Formatter is disabled, the data format you have enabled becomes invalid. ** Disable Data Formatter You may wish to require the data to conform to a data format you have created. The following settings can be applied to your data format: Enable Data Formatter, Required, Keep Prefix/Suffix: Scanned data that meets your data format requirements is modified accordingly and gets outputted along with prefixes and suffixes (if prefix and...

  • Page 166: Non-Match Error Beep

    Enter Setup Enable Data Formatter, Required, Keep Prefix/Suffix Enable Data Formatter, Required, Drop Prefix/Suffix Enable Data Formatter, Not Required, Keep Prefix/Suffix Enable Data Formatter, Not Required, Drop Prefix/Suffix Non-Match Error Beep If Non-Match Error Beep is turned ON, the scanner generates an error beep when a barcode is encountered that does not match your required data format.

  • Page 167: Formatter Command Type 6

    Enter Setup Formatter Command Type 6 When working with the Data Formatter, a virtual cursor is moved along your input data string. The following commands are used to both move this cursor to different positions, and to select, replace, and insert data into the final output.
  • Page 168 Enter Setup F3 Send all characters up to a particular character Syntax=F3ssxx (ss: The particular character’s hex value; xx: The insert character’s hex value) Include in the output message all characters from the input message, starting with the character at the current cursor position and continuing to, but not including, the particular character “ss,”...
  • Page 169 Enter Setup E9 and F4 Example: Send all but the last characters, followed by 2 tabs Send all characters except for the last 8 from the barcode above, followed by 2 tabs. Command string: E908F40902 E9 is the “Send all but the last characters” command 08 is the number of characters at the end to ignore F4 is the “Insert a character multiple times”...

  • Page 170: Move Commands

    Enter Setup B3 and B4 Example: Insert the symbology name and length Send the symbology name and length before the barcode data from the barcode above. Break up these insertions with spaces. End with a carriage return. Command string: B3F42001B4F42001F10D B3 is the “Insert symbology name”...
  • Page 171 Enter Setup F5 Example: Move the cursor forward and send the data Move the cursor forward 3 characters, then send the rest of the barcode data from the barcode above. End with a carriage return. Command string: F503F10D F5 is the “Move the cursor forward a number of characters” command 03 is the number of characters to move the cursor F1 is the “Send all characters”...

  • Page 172: Search Commands

    Enter Setup Search Commands F8 Search forward for a character Syntax＝F8xx (xx: The search character’s hex value) Search the input message forward for “xx” character from the current cursor position, leaving the cursor pointing to the “xx” character. F8 Example: Send barcode data that starts after a particular character Search for the letter “D”...
  • Page 173 Enter Setup B0 Search forward for a string Syntax=B0nnnnS (nnnn: The string length (up to 9999); S: The ASCII hex value of each character in the string) Search forward for “S” string from the current cursor position, leaving cursor pointing to “S” string. For example, B0000454657374 will search forward for the first occurrence of the 4-character string “Test.”...
  • Page 174 Enter Setup E6 Search forward for a non-matching character Syntax=E6xx (xx: The search character’s hex value) Search the input message forward for the first non-“xx” character from the current cursor position, leaving the cursor pointing to the non-“xx” character. E6 Example: Remove zeros at the beginning of barcode data This example shows a barcode that has been zero filled.

  • Page 175: Miscellaneous Commands

    Enter Setup Miscellaneous Commands FB Suppress characters Syntax＝FBnnxxyy..zz (nn: The numeric value (00-15) for the number of suppressed characters; xxyy..zz: The hex value of the characters to be suppressed) Suppress all occurrences of up to 15 different characters, starting at the current cursor position, as the cursor is advanced by other commands.
  • Page 176 Enter Setup E4 Replace characters …zz Syntax＝E4nnxx (nn: The total count of the number of characters (characters to be replaced plus replacement characters; xx : The characters to be replaced, xx : The replacement characters, continuing through zz and zz Replace up to 15 characters in the output message, without moving the cursor.
  • Page 177 Enter Setup BA Replace a string with another Syntax＝BAnnNN nn: The count of replacements to be made, if nn=00 or nn>=the number of occurrences of a string to be replaced, then replace all occurrences of that string. : The length of the string to be replaced, NN >0.
  • Page 178 Enter Setup 32 is the hex value for 2 (character in the string to be replaced) 33 is the hex value for 3 (character in the string to be replaced) 03 is the length of the replacement string 41 is the hex value for A (character in the replacement string) 42 is the hex value for B (character in the replacement string) 43 is the hex value for C (character in the replacement string) F1 is the “Send all characters”...

  • Page 179: Chapter 9 Batch Programming

    Enter Setup Chapter 9 Batch Programming Introduction Batch programming enables users to integrate a batch of commands into a single batch barcode. Listed below are batch programming rules: 1. Command format: Command + “=” + Parameter Value. 2. Each command is terminated by a semicolon (;). Note that there is no space between a command and its terminator semicolon.

  • Page 180: Create A Batch Command

    Enter Setup Create a Batch Command A batch command may contain a number of individual commands each of which is terminated by a semicolon (;). Command Structure: Command (+ “=” + Parameter Value) 4 command syntaxes are described as below: 1.

  • Page 181: Create A Batch Barcode

    Enter Setup Create a Batch Barcode Batch barcodes can be produced in the format of PDF417, QR Code or Data Matrix. Example: Create a batch barcode for Illumination Always On, Sense Mode, Decode Session Timeout = 2s: 1. Input the following commands: 0200010;0302010;0313000=2000;...

  • Page 182: Use Batch Barcode

    Enter Setup Use Batch Barcode To put a batch barcode into use, scan the following barcodes. (Use the example above.) Enter Setup Enable Batch Barcode Batch Barcode Exit Setup ** Exit Setup...

  • Page 183: Appendix

    Appendix Digit Barcodes After scanning numeric barcode(s), you need to scan the Save barcode to save the data.

  • Page 185: Save/Cancel Barcodes

    Save/Cancel Barcodes After reading numeric barcode(s), you need to scan the Save barcode to save the data. If you scan the wrong digit(s), you can either scan the Cancel barcode and then start the configuration all over again, or scan the Delete the Last Digit barcode and then the correct digit, or scan the Delete All Digits barcode and then the digits you want.

  • Page 186: Factory Defaults Table

    Factory Defaults Table Parameter Factory Default Remark System Settings Disabled Barcode Programming Applicable to Manual mode 5 minutes Auto Power-Off Timeout only Normal Illumination Normal Aiming Enabled Startup Beep Notification Enabled Good Read Beep Beep Type Type 3 Beep Volume Loud Do not transmit NGR (Not Good Read) Message...
  • Page 187 Parameter Factory Default Remark Decode Area Whole Area Decoding 40% top, 60% bottom, 40% left, Specify Decoding Area 60% right Communication Settings Wireless Communication Mode Synchronous Mode Only applicable to Synchronous Host Acknowledgment Disabled mode Host Acknowledgment Timeout Only applicable to Batch mode Stored Data after Batch Transmission Auto Delete USB HID-KBW...
  • Page 188 Parameter Factory Default Remark Symbologies Applicable to all Video Reverse Disabled symbologies. Code 128 Code 128 Enabled Maximum Length Minimum Length UCC/EAN-128 UCC/EAN-128 Enabled Maximum Length Minimum Length AIM-128 AIM-128 Enabled Maximum Length Minimum Length EAN-8 EAN-8 Enabled Check Digit Transmit 2-Digit Add-On Code Disabled...
  • Page 189 Parameter Factory Default Remark ISSN ISSN Disabled Disabled 2-Digit Add-On Code Disabled 5-Digit Add-On Code Not required Add-On Code ISBN Disabled ISBN ISBN-13 ISBN Format Disabled 2-Digit Add-On Code Disabled 5-Digit Add-On Code Not required Add-On Code UPC-E Enabled UPC-E Transmit Check Digit Disabled...
  • Page 190 Parameter Factory Default Remark ITF-14 Disabled ITF-14 Do not transmit Check Digit Matrix 2 of 5 Disabled Matrix 2 of 5 Enabled Check Digit Verification Do not transmit Check Digit Maximum Length Minimum Length Industrial 2 of 5 Enabled Industrial 2 of 5 Disabled Check Digit Verification Do not transmit...
  • Page 191 Parameter Factory Default Remark Codabar Codabar Enabled Check Digit Verification Disabled Check Digit Do not transmit Start/Stop Character Do not transmit Start/Stop Character Format ABCD/ABCD Maximum Length Minimum Length Code 93 Code 93 Enabled Check Digit Verification Enabled Check Digit Do not transmit Maximum Length Minimum Length...
  • Page 192 Parameter Factory Default Remark MSI-Plessey MSI-Plessey Disabled Check Digit Verification One check digit, MOD10 Check Digit Do not transmit Maximum Length Minimum Length PDF 417 PDF 417 Enabled Maximum Length 1024 Minimum Length QR Code QR Code Enabled Micro QR Enabled Maximum Length 1024...

  • Page 193: Aim Id Table

    AIM ID Table Symbology AIM ID Remark Standard EAN-13 EAN-13 EAN-13 + 2/5-Digit Add-On Code Standard EAN-8 ]E4…]E1… EAN-8 EAN-8 + 2-Digit Add-On Code ]E4…]E2… EAN-8 + 5-Digit Add-On Code Standard UPC-E UPC-E UPC-E + 2/5-Digit Add-On Code Standard UPC-A UPC-A UPC-A + 2/5-Digit Add-On Code Code 128...
  • Page 194 Symbology AIM ID Remark Standard Codabar Codabar Transmit check digit after verification Do not transmit check digit after verification Code 93 Standard Code 93 One check digit MOD11; transmit check digit Two check digits, MOD11/MOD11; transmit check digit Code 11 Do not transmit check digit after verification No check digit verification GS1-DataBar (RSS)
  • Page 195 Symbology AIM ID Remark 2005 version, ECI excluded 2005 version, ECI included QR Code 2005, ECI excluded, FNC1 is the 1st character after the start character QR Code QR Code 2005, ECI included, FNC1 is the 1st character after the start character QR Code 2005,ECI excluded,FNC1 is the 2nd character after the start character...

  • Page 196: Code Id Table

    Code ID Table Symbology Code ID Code 128 UCC/EAN-128 AIM-128 EAN-8 EAN-13 ISSN ISBN UPC-E UPC-A Interleaved 2 of 5, Febraban ITF-6 ITF-14 Matrix 2 of 5 Industrial 2 of 5 Standard 2 of 5 Code 39 Codabar Code 93 Code 11 Plessey MSI-Plessey...

  • Page 197: Ascii Table

    ASCII Table Char (Null char.) (Start of Header) (Start of Text) (End of Text) (End of Transmission) (Enquiry) (Acknowledgment) (Bell) (Backspace) (Horizontal Tab) (Line Feed) (Vertical Tab) (Form Feed) (Carriage Return) (Shift Out) (Shift In) (Data Link Escape) (XON) (Device Control 1) (Device Control 2) (XOFF) (Device Control 3) (Device Control 4)
  • Page 198 Char (Request to Send) (Unit Separator) (Space) (Exclamation Mark) " (Double Quote) (Number Sign) (Dollar Sign) (Percent) & (Ampersand) (Single Quote) (Left / Opening Parenthesis) (Right / Closing Parenthesis) (Asterisk) (Plus) (Comma) (Minus / Dash) (Dot) (Forward Slash) (Colon) (Semi-colon) <...
  • Page 199 Char > (Greater Than) (Question Mark) (AT Symbol) (Left / Opening Bracket) (Back Slash) (Right / Closing Bracket)
  • Page 200 Char (Caret / Circumflex) (Underscore) (Grave Accent) (Left/ Opening Brace) (Vertical Bar) (Right/Closing Brace) (Tilde) (Delete)

  • Page 201: Ascii Function Key Mapping Table

    ASCII Function Key Mapping Table ASCII Function ASCII Value (HEX) No Function Key Mapping Function Key Mapping NUL (Null char.) Null Ctrl+2 SOH (Start of Header) Keypad Enter Ctrl+A Caps Lock Ctrl+B STX (Start of Text) Null Ctrl+C ETX (End of Text) Null Ctrl+D EOT (End of Transmission)
  • Page 202 ASCII Function Key Mapping Table (Continued) The function key mappings of the last five characters in the previous table differ from one keyboard layout to another. Country/ Function Key Mapping Keyboard Layout United States Ctrl+[ Ctrl+\ Ctrl+] Ctrl+6 Ctrl+- Belgium Ctrl+[ Ctrl+<...

  • Page 203: Symbology Id Number

    Symbology ID Number Symbology ID Number Code 128 UCC/EAN128 EAN-8 EAN-13 UPC-E UPC-A Interleaved 2 of 5, Febraban ITF-14 ITF-6 Matrix 2 of 5 Code 39, Code 32 Codabar Code 93 AIM-128 ISSN ISBN Industrial 25 Standard 25 Plessey Code11 MSI-Plessey GS1 Databar PDF417...
