- Page 1 SX-STV10 SERVICE MANUAL SPEAKER SYSTEM SPECIFICATIONS • Design and specifications are subject to change without notice S/M Code No. 09-99A-336-3N1...
- Page 2 MECHANICAL EXPLODED VIEW 1/1 MECHANICAL PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION 1 8Z-YS5-005-010 CABI,FR 2 8Z-YS5-001-010 PANEL,FR 3 8Z-YS5-002-010 PANEL,REAR 4 8Z-YS5-003-010 PANEL,DUCT 5 8Z-YS5-601-010 SPKR,W 160 8OHM 75W 6 8Z-NSY-003-010 CORD,BUSH 7 8Z-YS5-602-010 CORD,DIN5PIN COLOR NAME TABLE Basic color symbol Color Basic color symbol...
- Page 3 SPEAKER DISASSEMBLY INSTRUCTIONS Type.1 Type.4 Insert a flat-bladed screwdriver into the position indicated by the TOOLS arrows and remove the panel. Remove the screws of each speaker 1 Plastic head hammer unit andthen remove the speaker units. 2 (-) flat head screwdriver 3 Cut chisel Type.2 How to Remove the PANEL, FR...
- Page 4 ACCESSORIES/PACKAGE LIST REF. NO PART NO. KANRI DESCRIPTION 1 8Z-YS5-901-010 IB,Y (E,S,R,G,A,PE) BASS 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 920074...
