MONARCH 318LIPW2K
Transmitter
Solutions
Thank you for choosing a Transmitter Solutions product .
Please read this manual carefully before using the product.
Made in Italy. Copyright
© 2006 by
Transmitter Solutions
CONTENTS
1 - TRANSMITTER OVERVIEW
1A - General information
1B - Technical specifications
1C - Main components
1A - General information
The Transmitter Solutions Monarch - 318LIPW2K is a key chain style
mini transmitter operating at 318 MHz. It has been designed for use
with programmable telephone entry, security, and access control
systems operating with a 318 MHz frequency receiver.
The code sent by the transmitter includes a 16 bit security code which
allows up to 65,536 code combinations and 4 bits of facility code which
allows up to 16 facility codes .
The Transmitter Solutions - 318R receiver which operates with this
transmitter has a Wiegand 26 bit format output, which will operate any
type of access control system equipped to accept a 26 bit Wiegand
input. The CR 2016 lithium batteries have a shelf life of about 6 months.
The product fully complies with
Part 15 of FCC Regulations and
European Directives 99/5/CE, 89/336/CEE, 73/23/CEE.
1B - Technical specifications
Operating frequency
318 MHz
Number of keys:
2
Battery :
2 x 3V lithium batteries CR2016
Battery life:
18
÷
24 months
Number combinations :
65,536
Facility Codes :
16
Operating temperature:
-20°F÷+131°F (-20°C
Overall dimensions:
2.4"x1.4"x0.63" (61x36x16 mm)
Weight:
1 oz. (20 gr.)
1C - Main components
Red
Push-button A
LED
Battery
door
Key
ring
Push-button B
holder
Blue & White Case
the
÷+55°C)
