Summary of Contents for Crestron STS
-
Page 3: Table Of Contents
Crestron ST-PK Contents STS Programming Kit: ST-PK Description...1 Kit Description...1 SmarTouch™ STS Description ...1 Software...2 Leading Specifications ...3 Setup ...4 STS Equipment ...4 Applying Power...6 Identity Code ...6 Preparing the System for Programming...7 Preparing the System for Operation ...8 Problem Solving...9 Troubleshooting...9... -
Page 5: Sts Programming Kit: St-Pk
Description Kit Description The ST-PK is the Crestron programming kit for the SmarTouch STS. The kit provides the necessary cables, adapters, and software to successfully design and upload unique touchpanel projects. Components of the kit are clearly listed, refer to “STS Equipment”... -
Page 6: Software
Features of the SmarTouch STS wireless control system include: Software NOTE: Use the provided software, VisionTools™ Pro to design user interface pages for the SmarTouch STS. The latest revision of the Crestron Database is available from the Software Downloads page (Cresdb Library) of the Crestron website (www.crestron.com). -
Page 7: Leading Specifications
VT Pro. A set of pages which make up a project can be designed for each STS application. Each touchpanel can be organized with the ideal, color-oriented control environment with custom control graphics: icons, two and three-dimensional buttons, and floor plans. -
Page 8: Setup
Setup STS Equipment The items required to program STS equipment, listed below, are provided as part of the programming kit (ST-PK). These kit items can be used time and time again to program or reprogram each system. - Page 9 STS system. The next table in this section, shown below, provides a list of all equipment that is provided with the STS system. Except for the STIRP, all products listed in the part number column ship one item per system.
-
Page 10: Applying Power
SmarTouch STS Control Processor External AC Power Packs Identity Code All Crestron expansion modules and touchpanels within the Cresnet system require a unique identity code (NET ID). These codes are recognized by a two-digit hexadecimal number from 03 to FE. Matching NET IDs between the expansion modules and touchpanels with the program is required if data is to be successfully transferred or new touchpanel screens are to be loaded. -
Page 11: Preparing The System For Programming
Preparing the System for Programming When programming, refer to figure shown below for typical connection diagram for the SmarTouch STS. Complete the following steps in the order provided to ensure proper connection of the system. Typical Connection Diagram when Programming the SmarTouch STS Touchpanel... -
Page 12: Preparing The System For Operation
Programming Kit Preparing the System for Operation When operating the SmarTouch STS refer to the figure shown below for a typical connection diagram. Complete the following steps in the order provided to ensure proper connection of the system. It is assumed that the SmarTouch STS is currently connected for programming. -
Page 13: Problem Solving
Crestron ST-PK Problem Solving Troubleshooting The table below and on the next page provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron technical support representative. SmarTouch STS Troubleshooting Project can not be uploaded to touchpanel. - Page 14 Programming Kit SmarTouch STS Troubleshooting (Continued) RF LED on ST-CP illuminates, but COM or IR LEDs do not illuminate. RF LED on ST-CP does not illuminate when trying to control A/V equipment. A/V device does not respond. A/V device does not...
-
Page 15: Further Inquiries
Further Inquiries If after reviewing this Operations Guide, you can not locate specific information, please take advantage of Crestron's award winning technical support team in your area. Dial one of the following numbers. For local support from exclusive Crestron factory-trained personnel call: Operations Guide - DOC. -
Page 16: Return And Warranty Policies
Disk drives and any other moving or rotating mechanical parts are covered for a period of one (1) year. CRESTRON warrants all its other products for a period of one year from the defects mentioned above, excluding touchscreen display components which are covered for 90 days.
