INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
WOOD BURNING APPLIANCE
MODEL(S):
ECO-ADV-WS18
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
Consumer Care 1-877-427-3316 - Prior to calling, please
have the model and serial number of the unit you are
calling about. This information can be found at the front of
the unit.
www.heatilatorecochoice.com
Owner's Manual
Installation and Operation
7056-138L • August 23, 2019
WARNING
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
•
Do not over-fire - If appliance or chimney connector
glows, you are over-firing. Over-firing will void
your warranty.
•
Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room
as appliance.
•
Alert children and adults to hazards of
high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may over-fire and generate
poisonous gases (i.e. carbon monoxide).
NOTE: To obtain a French translation of this
manual, please contact your dealer or visit
www.heatilatorecochoice.com
REMARQUE : Pour obtenir une traduction française
de ce manuel, s'il vous plaît
contacter votre revendeur ou visitez
www.heatilatorecochoice.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECOCHOICE ECO-ADV-WS18 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heatilator ECOCHOICE ECO-ADV-WS18

Summary of Contents for Heatilator ECOCHOICE ECO-ADV-WS18

  • Page 1 Owner’s Manual Installation and Operation INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. Contact your dealer with questions on installation, operation, or service. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is not followed exactly, a fire could result causing property damage, personal injury,...

  • Page 2: Sample Of Serial Number / Safety Label

    Heatilator EcoChoice WS18 Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. Congratulations! NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction A. Sample of Serial Number / Safety Label...

  • Page 3: Table Of Contents

    E. Baffle Removal ......25 F. Tube Channel Assembly Replacement ..26 Heatilator is a registered trademark of Hearth & Home Technologies. www.heatilatorecochoice.com...

  • Page 4: Warranty Policy

    HEATILATOR ECO-CHOICE WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (“HHT”), extends the following warranty for ECOCHOICE by Heatilator wood and pellet hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will be free from defects in materials and workmanship at the time of manufacture.
  • Page 5 Heatilator EcoChoice WS18 WARRANTY COVERAGE: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation.

  • Page 6: Quick Start Guide

    Heatilator EcoChoice WS18 C. Quick Start Guide NOTE: These are generic drawings and may not represent your specifi c model. 10 Pieces of Newspaper, 10-20 Pieces of Dry ITEMS NEEDED FOR FIRST FIRE: Kindling and Few Pieces of Dry Split Wood.

  • Page 7: Listing And Code Approvals

    UL1482, (UM) 84-HUD and NPFA211 in the U.S.A. and the ULC S627-00 and CAN/CSA-B365 Installation Codes in Canada. The Heatilator ECO-CHOICE Wood Appliance meets the U.S. Environmental Protection Agency’s crib wood emission limits for wood appliances sold after May 15, 2015.

  • Page 8: Mobile Home Approved

    Heatilator EcoChoice WS18 C. Mobile Home Approved WARNING • This appliance is approved for mobile home installations; when not installed in a sleeping room and when an outside combustion air inlet is provided. Fire Risk • The structural integrity of the mobile home floor, ceiling, Hearth &...

  • Page 9: User Guide

    Heatilator EcoChoice WS18 User Guide Operating Instructions WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass will cause burns. • Do not touch glass until it is cooled • NEVER allow children to touch glass •...

  • Page 10: Fire Safety

    Heatilator EcoChoice WS18 B. Fire Safety D. Combustible/Non-combustible Materials To provide reasonable fire safety, the following should be • Combustible Material given serious consideration: Material made of or surfaced with wood, compressed 1. Install at least one smoke detector on each floor of paper, plant fibers, plastics, or any material capable your home to ensure your safety.

  • Page 11: Chimney Fire

    Heatilator EcoChoice WS18 F. Chimney Fire 2. Second Stage The next stage of burning, the secondary stage, is the WARNING period when the wood gives off flammable gases which burn above the fuel with bright flames. During this stage of Fire Risk.

  • Page 12: Burn Rate Air Controls

    Heatilator EcoChoice WS18 H. Burn Rate Air Controls I. Burn Rates and Operating Efficiency • The air supply enters at the upper front of the firebox, WARNING near the top of the glass door. • This preheated air supplies the necessary fresh oxygen Risk of Fire.

  • Page 13: Building A Fire

    Heatilator EcoChoice WS18 J. Building A Fire 9. When ready to reload, It is best to set the Burn Rate Air Control in the High position before reloading. WARNING This livens up the coal bed and reduces excessive emissions (opacity/smoke).

  • Page 14: Correct Baffle/Blanket Placement

    Heatilator EcoChoice WS18 K. Correct Baffle/Blanket Placement INCORRECT POSITIONS WARNING Fire Risk. Firebox damage due to improper baffle placement is not covered by warranty. Operate the wood burning appliance with the baffle in the correct position only. Not doing so could result in: •...

  • Page 15: Wood Fuel

    Heatilator EcoChoice WS18 L. Wood Fuel Seasoned Wood • Cut logs to size • Split to 6 inches (152 mm) or less in diameter WARNING • Air dry to a moisture content of not more than 20% Soft wood - about nine months to dry Fire Risk.

  • Page 16: Blower Operating Instructions

    Heatilator EcoChoice WS18 M. Blower Operating Instructions NOTE: If your wood appliance is equipped with an optional blower, you should follow these guidelines: Blower Burn Rate Air Control Handle Up = Open Handle Down = Closed Snap Disc Figure 16.2 - Snap Disc Location 7.

  • Page 17: Clear Space

    Heatilator EcoChoice WS18 O. Clear Space P. Negative Pressure • Do NOT place combustible objects within 4 ft (1.2 m) of WARNING the front of appliance (Figure 17.1). • Mantel - avoid placing candles and other heat-sensitive Asphyxiation Risk. objects on mantel or hearth. Heat may damage •...

  • Page 18: Frequently Asked Questions

    Heatilator EcoChoice WS18 Q. Frequently Asked Questions ISSUES SOLUTIONS When first operated, this appliance may release an odor for the first several hours. This is Odor from appliance caused by the curing of the paint and the burning off of any oils remaining from manufacturing.

  • Page 19: Maintenance And Service

    Heatilator EcoChoice WS18 Maintenance and Service A. Quick Reference Maintenance Guide CAUTION! When properly maintained, your appliance will give you many years of trouble-free service. Contact your Injury Risk. dealer to answer questions regarding proper operation, • Allow the appliance to completely cool down before troubleshooting and service for your appliance.

  • Page 20: General Maintenance

    Heatilator EcoChoice WS18 B. General Maintenance 2. Disposal of Ashes • Frequency: When ash is within 1-3/4 in. (44mm) of 1. Creosote (Chimney) Cleaning firebox lip • Frequency: Every 2 months during heating season or • By: Homeowner as recommended by a certified chimney sweep; more frequently if chimney exceeds or is under 14-16 ft.
  • Page 21 Heatilator EcoChoice WS18 4. Glass Cleaning 6. Inspect Firebrick • Frequency: As desired • Frequency: After each ash removal • By: Homeowner • By: Homeowner Replace the firebrick if they become crumbly and/or if there CAUTION is a 1/4 inch (6.35mm) gap between the bricks.

  • Page 22: Troubleshooting Guide

    Heatilator EcoChoice WS18 Troubleshooting Guide With proper installation, operation, and maintenance your wood appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a problem and the corrective action to be taken.

  • Page 23: Service Parts Replacement

    Heatilator EcoChoice WS18 Service Parts Replacement A. Glass Replacement B. Firebrick Replacement Replace the firebrick if they become crumbly and/or if there (Replace with 5mm ceramic glass only) is a 1/4 inch (6.35mm) gap between the bricks. 1. Ensure that the fire is out and the appliance is cool to the touch.

  • Page 24: Snap Disc Replacement

    Heatilator EcoChoice WS18 C. Snap Disc Replacement D. Door Handle Assembly 1. Disconnect power supply. Locate the snap disc 1. Install washer on door handle shaft. bracket assembly at the bottom left rear corner of the 2. Slide door handle through door.

  • Page 25: Baffle Removal

    Heatilator EcoChoice WS18 E. Baffle Removal 1. Remove all ash from the firebox, and extinguish all hot Baffle Boards & Blanket even with front tube and embers before disposal into a metal container. Burn Rate resting on back tube 2. Remove the baffle protection channel by rotating it Air Control down from the front tube (Figure 25.2).

  • Page 26: Tube Channel Assembly Replacement

    Heatilator EcoChoice WS18 F. Tube Channel Assembly Replacement Removing Tube Channel Assembly 1. Remove the baffle protection channel, ceramic blanket and the 2 baffle boards. See instructions on page 25. 2. Remove the right side shield by removing 3 screws in the back using a Phillips head screw driver.

  • Page 27: Getting Started

    Heatilator EcoChoice WS18 Install Guide Getting Started A. Design and Installation Considerations B. Fire Safety Consideration must be given to: To provide reasonable fire safety, the following should be • Safety given serious consideration: • Convenience 1. Install at least one smoke detector on each floor of •...

  • Page 28: Negative Pressure

    Heatilator EcoChoice WS18 C. Negative Pressure D. Tools And Supplies Needed Before beginning the installation be sure the following tools and building supplies are available: WARNING Reciprocating saw Framing material Asphyxiation Risk. Pliers • Negative pressure can cause spillage High temp caulking material...

  • Page 29: Install Checklist

    Heatilator EcoChoice WS18 F. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjuction with, not instead of, the instructions contained in this installation manual. _________________________________________________________________________________ Customer: ______________________________________________________________________________...

  • Page 30: Dimensions And Clearances

    Heatilator EcoChoice WS18 Dimensions and Clearances A. Appliance Dimensions NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) 19-1/16 in. (484 mm) 25 in. (635mm) 9-5/16 in. 12-1/2 in. (236 mm) (317mm) 14-13/16 in. (376 mm) 13-13/16 in. 9-9/16 in.

  • Page 31: Hearth Protection Requirements

    Heatilator EcoChoice WS18 B. Hearth Protection Requirements In Canada (Figure 34.2), similar floor protection must be provided 18 inches (457mm) in front and 8 inches (203mm) FLOOR PROTECTION: It is necessary to install a Type II from the sides and rear of the appliance unless reduced by floor protector.

  • Page 32: Clearances To Combustibles (Ul And Ulc)

    Heatilator EcoChoice WS18 C. Clearances to Combustibles (UL and ULC) MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS: INCHES & (MILLIMETERS) NOTE: ALL “A”, “C” AND “F” DIMENSIONS ARE TO INSIDE DIAMETER OF FLUE COLLAR. INSTALLATION: Full Vertical OR Horizontal with 2 foot (609mm) minimum vertical Off Appliance Top...

  • Page 33: Chimney Systems

    Heatilator EcoChoice WS18 Chimney Systems A. Locating Your Appliance & Chimney • Consider the appliance location in order to avoid floor and ceiling attic joists and rafters. Location of the appliance and chimney will affect • Locate termination cap away from trees, adjacent performance.

  • Page 34: Chimney Termination Requirements

    Heatilator EcoChoice WS18 B. Chimney Termination Requirements NOTICE: Locating the appliance in a basement or in Follow manufacturer’s instructions for clearance, securing a location of considerable air movement flashing and terminating the chimney (Figure 34.1 & 34.2). can cause intermittent smoke spillage from •...

  • Page 35: Chimney Height / Rise And Run

    Heatilator EcoChoice WS18 D. Chimney Height / Rise and Run Chimney: The chimney can be new or existing, masonry or This product was designed for and tested on a 6 inch prefabricated and must meet the following minimum (152mm) chimney, 14 to 16 feet (420-480cm) high, requirements and as specified in Section 4F.
  • Page 36 Heatilator EcoChoice WS18 Thimble Listed Termination Cap Site constructed for masonry chimney installation: Storm Collar Components A minimum length of 12 inches [305mm] (longer for thicker Flashing walls) of solid insulated factory-built chimney length constructed to UL 103 Type HT 6 inch (152mm) inside diameter.

  • Page 37: Installing Chimney Components

    Heatilator EcoChoice WS18 G. Installing Chimney Components Solid Pack Chimney with Metal Supports as a Thimble Chimney Connector Single wall connector or appliance pipe. This must be at least 24 gauge mild steel or 26 gauge blue Fire Clay Flue steel.

  • Page 38: Appliance Set-Up

    Heatilator EcoChoice WS18 Appliance Set-up A. Outside Air Kit Installation 5. Floor Installation Alternative: In some instances you may not be able to install the flex pipe as show A source of air (oxygen) is necessary in order for combustion to take place. Whatever combustion air is in Figure 38.1.

  • Page 39: Blower Installation (Optional)

    Heatilator EcoChoice WS18 B. Blower Installation (Optional) C. Adjusting the Blower Speed Control 1. Align holes in mounting flange of blower with bolt holes The blower speed control for this appliance is in appliance. Blower should be positioned at bottom of adjusted at the factory, and normally does not require rear outer skin as shown in Figure 39.1.

  • Page 40: Mobile Home Installation

    Heatilator EcoChoice WS18 Mobile Home Installation You must use a Quadra-Fire Outside Air Kit Part #: Spark Arestor Cap OAK-ACC 1. An outside air inlet must be provided for combustion Storm Collar and must remain clear of leaves, debris, ice and/or snow.

  • Page 41: Reference Materials

    Heatilator EcoChoice WS18 Reference Materials A. Service & Maintenance Log Date of Service Performed By Description of Service www.heatilatorecochoice.com 7056-138L • August 23, 2019...
  • Page 42 Heatilator EcoChoice WS18 Date of Service Performed By Description of Service www.heatilatorecochoice.com 7056-138L • August 23, 2019...

  • Page 43: Exploded View

    Heatilator EcoChoice WS18 B. Exploded View ECO-ADV-WS18 Service Parts Beginning Manufacturing Date: Mar 2010 Free Standing Wood Stove Ending Manufacturing Date: Active 08/18 Part number list on following page. www.heatilatorecochoice.com 7056-138L • August 23, 2019...

  • Page 44: Service Parts

    Heatilator EcoChoice WS18 C. Service Parts ECO-ADV-WS18 Service Parts Beginning Manufacturing Date: Mar 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.

  • Page 45: Accessories

    Heatilator EcoChoice WS18 D. Accessories ECO-ADV-WS18 Service Parts Beginning Manufacturing Date: Mar 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.
  • Page 46 CONTACT INFORMATION Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Heatilator Eco-Choice dealer with any questions or concerns. For the number of your nearest Heatilator Eco-Choice dealer log onto www.heatilatorecochoice.com CAUTION DO NOT DISCARD THIS MANUAL •...
