3. Connecting with damper, power supply for dampers
PIN
PIN 1 and 2
PIN 3 and 4
PIN 5 and 6
Cable tie (small)
(accessory)
Tighten 2 cables
with a cable tie
(small).
4. Connecting with power supply
Power supply
cable
Descriptions
OPEN
COMMON
CLOSE
24 V AC
Damper cables
Cable clamp
- 47 -
24 V power supply
terminal block
Cable tie (small)
(accessory)
Transformer
240 V
Power supply cable for dampers
Protective
earth (ground) wire
