2) UTY-CDPXZC
1. Connecting with indoor unit
2. Connecting with wireless LAN adapter
CN6
Cable tie
(small)
(accessory)
Wireless
LAN adapter
cable
- 46 -
Cable tie (small)
(accessory)
Zone control interface
connecting cable (accessory)
Cable tie (small)
(accessory)
Indoor unit
Cable tie (small)
(accessory)
Functional
earth (ground)
wire
Red
White
Black
