5. Connecting with optional remote sensor:
CN7 (white)
Remote sensor
CN8 (black)
cable
- 21 -
Cable tie (small)
(accessory)
Zone control interface
connecting cable
Cable tie (small)
(accessory)
Cable tie (small)
(accessory)
Indoor unit
Remote
sensor
Remote
sensor
