Summary of Contents for Crestron CNMK
- Page 1 Crestron CNMK Mouse/Keyboard Controller Operations Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron CNMK Contents Mouse/Keyboard Controller: CNMK Introduction ... 1 Features and Functions ... 1 Specifications ... 2 Physical Description... 2 Industry Compliance ... 5 Setup ... 6 Network Wiring... 6 Identity Code ... 7 Hardware Hookup ... 8 Power Up Sequence... 9 Programming Software ... -
Page 5: Mouse/Keyboard Controller: Cnmk
The CNMK is also available in an international version, the CNMKI. All features are identical with the exception of the international AC power requirements. -
Page 6: Specifications
.exe files containing the .cuz or .upz file. All can be obtained from the Downloads section of the Crestron website. To avoid program problems, make sure you are using the update file with the correct suffix letter (e.g., S, V, W, X). - Page 7 Crestron CNMK CNMK Physical Views CNMK Overall Dimensions Operations Guide – DOC. 5699A Mouse/Keyboard Controller Mouse/Keyboard Controller: CNMK • 3...
- Page 8 NOTE: Most 4-conductor phone cables are wired in a crisscross fashion and are not compatible with Crestron equipment. If the power pack is attached when the CNMK is part of the Cresnet system, power is drawn from the power pack. The CNMK does not load the network power, but the network power remains chained for additional network devices that are connected.
-
Page 9: Industry Compliance
Crestron CNMK CNMK Indicators There are four LED indicators located on the front panel of the CNMK. Refer to the following illustration and descriptions. CNMK Indicators PWR (Power) This LED illuminates when 12 volts (from the power pack) or 24 volts DC (from network) is supplied to the CNMK. -
Page 10: Setup
Cresnet power usage of the entire chain. If the unit is a home-run from a Crestron system power supply network port, the Cresnet power usage of that unit is the Cresnet power usage of the entire run. -
Page 11: Identity Code
SIMPL Windows procedure. Refer to the note on page 13 for a The Net ID of the CNMK has been factory set to 28. The Net IDs of multiple definition of Viewport. CNMKs in the same system must be unique. Net IDs are changed from a personal computer (PC) via the Crestron Viewport. -
Page 12: Hardware Hookup
NOTE: Verify that you have sufficient Cresnet power to support your net devices. The following diagram shows a portion of a Cresnet configuration that includes the CNMK. The supplied Y-mouse Adapter and cables enable transmission of mouse and keyboard commands from the control system to the PC. A more complete... -
Page 13: Power Up Sequence
The CNMK initializes with the PC during the power up sequence. To ensure proper initialization and operation, avoid doing any of the following: To prevent damage to the CNMK mouse and keyboard ports, do not plug or unplug any of the mouse and keyboard connectors to the CNMK while power is applied. -
Page 14: C2Net-Device Slot In Configuration Manager
Net ID of 28 as shown in the following illustration. NOTE: The first CNMK in a system is preset with a net ID of 28 when its symbol is dragged into the upper pane of System Views. Additional units are assigned different numbers as they are added. -
Page 15: Setting The Net Id In Device Settings
C2Net Device, Slot 9 Setting the Net ID in Device Settings Double-click the CNMK icon in the upper pane to open the “Device Settings” window. This window displays CNMK device information. Select the Net ID tab to change the Net ID, as shown in the following figure. -
Page 16: Uploading And Upgrading
CNMK Input Signal Descriptions Uploading and Upgrading NOTE: Crestron recommends that you use the latest software and that each device contains the latest firmware to take advantage of the most recently released features. Please check the Crestron website (http://www.crestron.com/updates) for the latest versions of software and firmware. -
Page 17: Communication Settings
Crestron Viewport may be preferred over development tools when uploading programs and projects. The following sections define how one would upload a SIMPL Windows program or upgrade the firmware of the CNMK. However, before attempting to upgrade, it is necessary to establish communications. Communication Settings NOTE: For laptops and other PCs without a built-in RS-232 port, Crestron recommends the use of PCMCIA cards, rather than USB-to-serial adapters. - Page 18 Mouse/Keyboard Controller Typical Connection Diagram when Uploading Accessing the “Port Settings” Window 14 • Mouse/Keyboard Controller: CNMK 1. Open the Crestron Viewport. Either launch the stand-alone version of Viewport, or start SIMPL Windows and from the menu bar, select Tools | Viewport.
-
Page 19: Uploading A Simpl Windows Program
A control system source file has The SIMPL Windows file can be uploaded to the control system using SIMPL the extension .smw. A compiled Windows or via the Crestron Viewport. SIMPL Windows file has the extension .spz for a 2-Series Upload via SIMPL Windows control system, .bin for CNX... -
Page 20: Firmware Upgrade
To take advantage of all the available features, it is important that the unit contains extension .upg the latest firmware. Please check the Crestron website for the latest version of firmware. Not every product has a firmware upgrade, but as Crestron improves functions, adds new features, and extends the capabilities of its products, firmware upgrades are posted. - Page 21 2. As shown after this step, select File Transfer | Update Network Device Firmware from the Viewport menu. 3. As shown in the following figure, select the Net ID of the CNMK and then click OK. 4. As shown below, select the firmware (UPG) file and click Open. The transfer will complete automatically.
-
Page 22: Problem Solving
For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 23: Appendix: At Scan Codes
“break” scan code of “\xF0\x1B”. Although typical “break” scan code is simply the “make” code preceded by hex F0, there are exceptions. Therefore, refer to the enclosed table for accurate scan codes. PC Keyboard with Find #s Operations Guide – DOC. 5699A Mouse/Keyboard Controller Mouse/Keyboard Controller: CNMK • 19... - Page 24 \x4C \x52 Enter \x5A Shift (left-most) \x12 \x1A \x22 \x21 \x2A \x32 \x31 \x3A \x41 \x49 20 • Mouse/Keyboard Controller: CNMK "BREAK" FIND DESCRIPTION/ SCAN CODE SYMBOL \xF0\x0E \xF0\x16 Shift (right-most) \xF0\x1E Ctrl (left-most) \xF0\x26 Alt (left-most) \xF0\x25 Space Bar...
-
Page 25: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 26 Mouse/Keyboard Controller Crestron CNMK This page intentionally left blank. 22 • Mouse/Keyboard Controller: CNMK Operations Guide - DOC. 5699A...
- Page 27 Crestron CNMK Mouse/Keyboard Controller This page intentionally left blank. Keyboard/Mouse Controller: CNMK • 23 Operations Guide – DOC. 5699A...
- Page 28 Crestron Electronics, Inc. Operations Guide - DOC. 5699A 15 Volvo Drive Rockleigh, NJ 07647 (2001975) Tel: 888.CRESTRON 05.05 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
