- Page 1 Manual Inverter Welder Work Cycle Applies for: Code Model 29961 SOIN-101MP Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Parts using the tool. Installation (SMAW) Keep this manual for future references. Start Up The illustrations in this manual are for reference Maintenance only. They might be different from the real tool. Troubleshooting Authorized Service Centers Warranty Policy SOIN-101MP ENGLISH... -
Page 3: Technical Specifications
Technical specifications SOIN-101MP Code 29961 Description Inverter Welder Input Voltage 127 V / 60 Hz Rated Input Capacity 3.8 kVA Open Circuit Voltage 69 V c.c. Power Factor Cos 0.73 Current Range 20 A - 100 A Rated Duty Cycle 6 minutes’... -
Page 4: General Power Tools Safety Warnings
General Power Tools Safety Warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Inverter Welders
Safety Warnings for Inverter Welders Protection Equipment for Welding Prevent Injuries and Accidents WARNING WARNING • Wear a welding mask to protect eyes • Risks of electric shock: and face when soldering. Assure the mask protective glass An electric shock coming from the soldering electrode may shade is adequate for the soldering process to carry out. -
Page 6: Parts
Parts Power Adjustment Control Positive Connection ( + ) Strap Work Piece Slots Grounding Clamp Negative Connection ( - ) Switch Electrode Holder Power Cord Ventilation Slots Ventilation Inlet Carrying Strap Protective Mask To get better results use a Brand Hammer-Brush cable set with soldering clamp CAB-200 for Slag Removal... -
Page 7: Installation (Smaw)
Installation (SMAW) Connections CAUTION To prevent electric shock please consult information in the “Electrical Requirements” section in Inverse Polarity pages 3 and 5. • The fast connections in the electrode holder and the grounding clamp are inserted and turned one quarter of a turn in a clockwise direction in the outlets found iin the front panel to be secured. -
Page 8: Start Up
Start Up Preparation • Only experience, practice and care can guarantee a good welding job. • The factor intervening in the welding process are many: required current, distance between the electrode and the 45° 45° work piece, soldering speed and direction, thickness and type of the material, the work piece position, electrode angle and also gauge, type of material and electrode covering. - Page 9 Start Up Examples of welding Correctly Applied Welding Electrode movement too fast and / or very low current. Electrode movement too slow and / or very high current. Electrode too separated from the work piece. Spiral movement. Half-Moon movement. Bevel Zigzag Movement.
-
Page 10: Maintenance
Maintenance • The correct use and regular cleansing extend the useful life of the welder. CAUTION • Only qualified personnel shall carry out repairs. We recommend visiting a Authorized Service Center to repair your welder, get supplies or accessories. Regular Maintenance Storage •... -
Page 11: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 0187-8737 to get information about the nearest Service Center. -
Page 12: Warranty Policy
Model Brand 29961 SOIN-101MP This product is guaranteed for 1 year. To make the warranty valid or purchase parts and components you must present the product in Corregidora 22, Col. Centro, Alc. Cuauhtémoc, CDMX C.P. 06060 or at the establishment where you purchased it, or at any Truper Service Center listed in the annex to the warranty ®...
