Winmate Windy Plus User Manual

Box pc for vehicle producing examination
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Windy Plus Box PC
Windy Plus
Box PC
for
Vehicle Producing Examination
USER MANUAL
Version: 1.0
Attention!!!
This product is designed for vehicle producing examination only. It should be used in vehicle
production line and required to be away from operator >30cm when operating.
User Manual
Windy Plus

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Windy Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate Windy Plus

Summary of Contents for Winmate Windy Plus

  • Page 1 Windy Plus Box PC Windy Plus Box PC Vehicle Producing Examination USER MANUAL Version: 1.0 Attention!!! This product is designed for vehicle producing examination only. It should be used in vehicle production line and required to be away from operator >30cm when operating.

  • Page 2: Table Of Contents

    Windy Plus Box PC TABLE OF CONTENTS CHAPTER 1 READ ME FIRST ........3 IMPORTANT SAFETY INSTRUCTIONS ................ 4 Copyright Notice ......................... 5 Warranty ............................ 5 Customer Service ........................6 Notice ............................6 Safety Precautions ........................6 CHAPTER 2 GETTING STARTED ........7 AC P ..................

  • Page 3: Chapter 1 Read Me First

    Windy Plus Box PC CHAPTER 1 Read Me First User Manual Windy Plus...

  • Page 4: Important Safety Instructions

    Windy Plus Box PC Attention!!! This product is designed for vehicle producing examination only. It should be used in vehicle production line and required to be away from operator >30cm when operating. IMPORTANT SAFETY INSTRUCTIONS Please read these instructions carefully before using the product and save for later reference.

  • Page 5: Copyright Notice

    If the customer discovers a defect, Winmate will, at its option, repair or replace the defective product at no charge to the customer, provided it is returned during the warranty period of one year, with transportation charges prepaid.

  • Page 6: Customer Service

    Windy Plus Box PC Customer Service We provide service guide for any problem as follow steps：First, visit the website to find the update information about the product. Second, http://www.winmate.com.tw contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.

  • Page 7: Chapter 2 Getting Started

    Windy Plus Box PC CHAPTER 2 Getting started User Manual Windy Plus...

  • Page 8: Connecting The Ac Power

    Windy Plus Box PC CHAPTER 2 GETTING STARTED Congratulations for you to purchase this rugged box computer. This chapter tells you step by step how to boot up the box computer. You can find instructions for the following procedures: Connecting the AC Power Our box PC can operate either on the external AC power adapter or internal battery power.

  • Page 9: Boot Up And Shut Down The Windy

    Windy Plus Box PC when is fully charged. Boot up and shut down the Windy Boot up the Windy 1. Put your Windy on a flat and stable surface or holding the Windy on your hand. 2. Make sure that the Windy is either connected to AC power or the battery pack with power.

  • Page 10: How To Wake Up Windy By Tx Box

    Windy Plus Box PC How to wake up Windy by TX box When the Windy is in S3 or S5 mode, you can wake it up with a TX box (optional). Please follow the steps list below to apply this function.

  • Page 11: Product Overview

    Windy Plus Box PC DIP switch Product Overview User Manual Windy Plus...
  • Page 12 Windy Plus Box PC Diagram of front view LED Indicator (Defined & Controlled by customer) IR receiver I/O protect cover Suction cup Diagram of Side view OBD connector (VGA type) Diagram of Rear view Epaper Didplay LED Indicator Battery cover (Defined &...

  • Page 13: Nstruction Of Osd & Led Status Ndication

    Windy Plus Box PC Diagram of I/O view IR receiver 19V DC in RJ45 USB 3.0 VGA output Instruction of OSD & LED Status Indication LED Status Indication Power button LED Status Indication Description LED Term LED Indicator Indicator Status Description Green light：Power On...
  • Page 14 Windy Plus Box PC Green light：Wi-Fi operating Wi-Fi Status No light : Wi-Fi suspend User Manual Windy Plus...

  • Page 15: Product Specification

    Windy Plus Box PC Product Specification The product specification(default) as the following table description: System Main board Spec Processor Intel® Pentium® Processor N4200 1. 1GHz, turbo up to 2.5GHz BIOS Insyde System BIOS System Memory 1 x 8GB SODIMM DDR3L-1866 (Max 8GB)
  • Page 16 Windy Plus Box PC Product Specification (continue) Mechanical and Environment Weight 1.3 Kg (w/o accessories) Operating -10℃~50℃ Temperature Operating Humidity 10% to 95% (non condensing) Mounting Suction cup with handle Shock MIL-STD-810G M516.6 (By request) Vibration MIL-STD-810G M514.6 (By request)

  • Page 17: Chapter 3 Useful Information

    Windy Plus Box PC CHAPTER 3 Useful Information User Manual Windy Plus...

  • Page 18: The Procedure To Test Connecting With Obd Box

    Windy Plus Box PC To implement the process of function test or BIOS update, you have to use VGA connector to show the Windy's output to a display (Resolution will be adjusted automatically). 1. The procedure to test connecting with OBD BOX 1.1 After running the program, please select the "P-Module VBat Test".
  • Page 19 Windy Plus Box PC 1.2 Click all the testing Item sequentially. It will show green when it Pass, but red when Fail. 1.3 After all the test has been done, please click the "EXIT” icon. User Manual Windy Plus...

  • Page 20: The Procedure To Update Bios Of Mcu

    Windy Plus Box PC 2. The procedure to update bios of MCU 2.1 Open “MCU AP” folder and run “SerialBootloaderDataSource.exe” 2.2. a. Click “Select Hex File(s)” b. Click .hex file c. Click “Open” d. Run the Hex file successfully as follow.
  • Page 21 Windy Plus Box PC 2.3 a. Click “COM Port” b. Click “Open COM Port” Please do not close the whole program window. 2.4 Run ”DaimlerMCUControl.exe” 2.5 Click “Enter Burn” User Manual Windy Plus...
  • Page 22 Windy Plus Box PC 2.6 If the program shows the notice “Click the ‘Update Application Firmware’ button to continue ” ,please click ”Update Application Firmware” . 2.7 When the message ”Bootload process completed successfully!” appears in the columm, it means update boot loader process was fully completed.

  • Page 23: The Procedure To Test All The Wake Up Function

    Windy Plus Box PC 3. The procedure to test all the Wake up function 3.1 IR Wake up a. Implement Daimler MCU Control and perform COM Port Connect to COM3 then set IR Enable. b. Click Get IR Wake and make sure IR Wake Status=Enable c.

  • Page 24: Obd In Wake Up

    Windy Plus Box PC 3.2 OBD In Wake up a. Implement Daimler MCU Control and perform COM Port connect to COM3 then set OBD In Enable. b. Click Get OBD In and make sure OBD In Wake Status=Enable。 c. Allow the system to enter the Sleep / Hibernate / Shout down Mode and plug in the OBD cable to wake up the Porty G3 S.

  • Page 25: Obd Out Wake Up

    Windy Plus Box PC 3.3 OBD Out Wake a. Implement Daimler MCU Control and perform COM Port connect to COM3 then set OBD out enable. b. Click Get OBD Out and make sure OBD Out Wake Status=Enable。 c. Allow the system to enter the Sleep / Hibernate / Shut down Mode and un-plug the OBD cable to wake up the Porty G3 S.

  • Page 26: Button Wake Up

    Windy Plus Box PC 3.4 Button Wake up a. Implement Daimler MCU Control and perform COM Port connect to COM3 then set Button out enable b. Click Get Button settings and make sure Button Wake Status=Enable。 c. Allow the system to...

  • Page 27: Rtc Wake Up

    Set Alarm Time in order to set the wake-up time. f. Allow the system to enter the Sleep / Hibernate / Shut down Mode and after a specified time to wake up Windy Plus. Click get Event to confirm whether wake up by RTC.

  • Page 28: Dc In Wake Up

    Click Get Docking In Wake and make sure Docking in Wake Status=Enable。 c. Allow the system to enter the Sleep / Hibernate / Shut down Mode and plug in the power adapter to wake up the Windy Plus, Click get Event to confirm whether wake up by DC Power In.

  • Page 29: Dc Out Wake Up

    Allow the system to enter the Sleep / Hibernate / Shut down Mode and motion the Windy Plus to wake up it. Click get Event to confirm whether wake up by G-Sensor. e. Click Get G-Sensor Table and make sure whether the count and time information are correct.
  • Page 30 Windy Plus Box PC User Manual Windy Plus...

  • Page 31: Chapter 4 Troubleshooting

    Windy Plus Box PC CHAPTER 4 Troubleshooting User Manual Windy Plus...

  • Page 32: Troubleshooting

    Windy Plus Box PC Troubleshooting Problem Solution The removable battery is not charging.  Make sure the AC adapter is properly connected, and that the removable battery is properly inserted. Nothing appears on the output display.  The Windy may be in sleep mode. Press the power button to wake it up.
  • Page 33 Windy Plus Box PC Winmate INC. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 241, Taiwan, R.O.C Web Site: http://www.winmate.com.tw User Manual Windy Plus...
  • Page 34 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
