- Page 1 SWIMMING POOL HEAT PUMP UNIT Installation & Instruction Manual...
-
Page 3: Table Of Contents
CONTENTS 1. Preface 2. Specifications 2.1 Performance data of Swimming Pool Heat Pump Unit 2.2 The dimensions for Swimmi ool He t a ump Unit 3. Installation and Connection Installation illustration Swimming Pool Heat Pumps Location 3.3 How Close to Your Pool? 3.4 Swimming Pool Heat Pumps Plumbing 3.5 Swimming Pool Heat Pumps Electrical Wiring 3.6 Initial start-up o f the Unit... -
Page 4: Preface
1. PREFACE In order to provide our customers with quality, reliability and versatility, this product has been made to strict production standards. This manual includes all the necessary information about installation, debugging, discharging and maintenance. Please read this manual carefully before you open or maintain the unit. The manufacture of this product will not be held responsible if someone is injured or the unit is damaged, as a result of improper installation, debugging, or unnecessary maintenance. - Page 5 1. PREFACE This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 6 1. PREFACE Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer. for Europe market 2. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 7: Specifications
2.SPECIFICATIONS 2.1 Performance data of Swimming Pool Heat Pump Unit *** REFRIGERANT : R32 PV 17 PV 13 UNIT 3.600-16.50 3.080-13.50 Heating capacity 12240-56100 (27/24.3 10472-45900 Btu/h 0.2600-2.740 0.2400-2.230 Heating Power Input 13.8-6.02 12.8-6.05 1.940-12.30 2.370-10.07 Heating capacity 6596-41820 8058-34238... - Page 8 2.SPECIFICATIONS 2.1 Performance data of Swimming Pool Heat Pump Unit *** REFRIGERANT : R32 PV 21 PV 24 UNIT 6.100-20.70 6.730-23.600 Heating capacity 20740-70380 22882-80240 (27/24.3 Btu/h 0.4800-3.160 0.4500-3.620 Heating Power Input 12.7-6.55 14.96-6.51 3.810-13.90 4.820-16.64 Heating capacity 12954-47260 16388-56576 (15/12 Btu/h 0.5600-3.250...
-
Page 9: The Dimensions For Swimmi N G P Ool He T A Ump Unit P
2.SPECIFICATIONS 2.2 The dimensions for Swimming Pool Heat Pump Unit el: PV 13/PV 17 unit mm water o tlet ter inlet 107.5 unit mm Model:PV 21/PV 24 water o tlet ter inlet 97.5... -
Page 10: Installation And Connection
3.INSTALLATION AND CONNECTION 3.1 Installation illustration Valve Chlorinator cell Water outlet Water supply Pool Water inlet Sand filter Water pump (or other type filter) Installation items: The factory only provides the main unit and the water unit; the other items in the illustration are necessary spare parts for the water system ,that provided by users or the installer. -
Page 11: Swimming Pool Heat Pumps Location
3.INSTALLATION AND CONNECTION 3.2 Swimming Pool Heat Pumps Location The unit will perform well in any outdoor location provided that the following three factors are presented: 1. Fresh Air - 2. Electricity - 3. Pool filter piping The unit may be installed virtually anywhere outdoors. For indoor pools please consult the supplier. -
Page 12: Swimming Pool Heat Pumps Plumbing
3.INSTALLATION AND CONNECTION 3.4 Swimming Pool Heat Pumps Plumbing The Swimming Pool Heat Pumps exclusive rated flow titanium heat exchanger requires no special plumbing arrangements except bypass(please set the flow rate according to the nameplate). The water pressure drop is less than 10kPa at max. Flow rate. Since there is no residual heat or flame Temperatures, The unit does not need copper heat sink piping. -
Page 13: Swimming Pool Heat Pumps Electrical Wiring
3.INSTALLATION AND CONNECTION 3.5 Swimming Pool Heat Pumps Electrical Wiring NOTE: Although the unit heat exchanger is electrically isolated from the rest of the unit, it simply prevents the flow of electricity to or from the pool water. Grounding the unit is still required to protect you against short circuits inside the unit. -
Page 14: Operation And Use
4.OPERATION AND USE 4.1.Interface display 4.2.Key and icon function instruction 2.1 Key function instruction Key symbols Function Designation When the unit runs heating under the heating mode or the automatic mode, the silent key operation is effective Slient key and used to enter or exit the silent mode with one click. It is used to switch the unit mode, temperature setting, Mode key and parameter setting. - Page 15 4.OPERATION AND USE 4.2.2 Icon function instruction Function Icon symbol Designation It will display during cooling (there is no limit to startup & Cooling shutdown, and it is optional when the unit is cooling-only symbol unit or heating-and-cooling unit). It will display during heating (there is no limit to startup & Heating shutdown, and it is optional when the unit is heating-only symbol...
-
Page 16: Startup & Shutdown
4.OPERATION AND USE 4. 3. Startup & shutdown Keep long press of " "for 0.5 s to enter ON/OFF interface When there is no operation within 1 minute, it will display with half screen off When there is no operation within 15 minutes, it will display with full screen off Notes:... -
Page 17: Temperature Setting
4.OPERATION AND USE Cooling mode Heating mode Short press" " for to switch the mode circularly, after no operation for 2s, the current mode will be saved. Automatic mode Operation descriptions: 1). Mode switch operation can only be conducted in the main interface. 2). -
Page 18: Clock Setting
4.OPERATION AND USE 4.6. Clock setting 4.6.1 S ystem time setting Long press " " for 2 s to enter into the system times Short press " " setting interface Hour digit flashing System time setting Press " " or "... - Page 19 4.OPERATION AND USE 4.6.2.3 Setting the Timer ON/OFF function While enter into the timer setting interface , set the Timer ON/OFF as below: " " " " " " " " * Take for example: Press " "or " " Short press "...
-
Page 20: Silent Setting
4.OPERATION AND USE 4.7. Silent setting 4.7 .1 One-click silent function short press " " Flashing Notes: 1). If one-click silent and timming silentaare stared at the same time, short press " " for canceling one-click silent and quitting the timing silent for this time. 2). -
Page 21: Keyboard Lock
4.OPERATION AND USE Notes: 1). When the silent icon" " is lighten:The timing mute has been set, but it's not under silent status. 2). When the silent icon" " flash:It's under the silent status. 3). When the silent icon" "disappear: The timingsilent is not set. 4.8.Keyboard lock To avoid others' misoperation, please lock the wire controller after completing the setting. -
Page 22: Parameter List And Breakdown Table
4.OPERATION AND USE 4.10 Parameter list and breakdown table (1) Electronic control fault table Can be judged according to the remote controller failure code and troubleshooting Fault Protect/fault Reason Elimination methods display The temp. Sensor is broken Inlet Temp. Sensor Fault Check or change the temp. - Page 23 4.OPERATION AND USE 1. Motor is in locked-rotor state 1.Change a new fan motor 2.The wire connection between 2.Check the wire connection and make sure Fan Motor2 Fault F032 DC-fan motor module and fan they are in good contact motor is in bad contact Frequency conversion board fault table: Fault Reason...
-
Page 24: Interface Drawin
4.23(5$7,21 $1' 86( (2) Parameter list Meaning Default Remarks Adjustable Adjustable Adjustable 4.11 Interface drawin (1) Wire control interface diagram and definition Sign Meaning 12V power + No use No use 485A 485B GND ( power - ) (2) Controller interface diagram and definition OUT1 AC-L AC-N... - Page 25 4.OPERATION AND USE Main board of the input and output interface instructions below Sign Meaning Number...
- Page 26 4.OPERATION AND USE...
- Page 27 4.OPERATION AND USE Main board of the input and output interface instructions below Number Sign Meaning P10-(U) P10-(V) ） Compressor ( output 220-230VAC P10-(W) CN18(PUMP) ） Water pump ( output 220-230VAC CN11(FOUR) 4-way valve ( output 220-230VAC ） CN97 DC Fan P1(AC-L) ）...
-
Page 28: Maintenance And Inspection
5. MAINTENANCE AND INSPECTION Check the water supply device and the release often. You should avoid the condition of no water or air entering into system, as this will influence unit's performance and reliability. You should clear the pool/spa filter regularly to avoid damage to the unit as a result of the dirty of clogged filter. -
Page 29: Appendix
6.APPENDIX 6.1 Caution & Warning 6.1 Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer(for Europe market). 2. This appliance can used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved(for Europe market). -
Page 30: Cable Specification
6.APPENDIX 6.2 Cable specification (1) Single phase unit Nameplate Creepage protector Signal line maximum Phase line Earth line current No more 2 1.5mm 1.5mm 30mA less than 0.1 sec than 10A 2 2.5mm 2.5mm 30mA less than 0.1 sec 10~16A 2 4mm 30mA less than 0.1 sec 16 ~25A... - Page 31 Note:...
- Page 32 Code...
