Summary of Contents for PROTEA SVG 500
- Page 1 SVG 500 OPERATION INSTRUCTIONS & SPARES MANUALS...
- Page 2 011 828 9935 082 458 7257 Mobile: Postal Address Physical Address P.O.BOX 1673 32 Shaft Road BEDFORDVIEW Knights 2008 GAUTENG Germiston SOUTH AFRICA Gauteng South Africa Email: sales@proturf.co.za Email: sean@proturf.co.za For further information on any Protea products, please visit our website www.proteamachines.com...
- Page 3 POWER LAWNMOWER SAFETY PRECAUTIONS Know your controls. Read the owner's manual 13 Stop the engine whenever you leave the carefully. Learn how to stop engine quickly in an mower, even for a moment. emergency. 14 Stop the engine before pushing mower Make sure the lawn is clear of sticks, stones, across gravel drives, walks or roads.
- Page 4 SPECIFICATIONS SVG500 SCARIFIER – VERTICUTTER – GROOMER MOTOR WHEELS 4/5HP Petrol Driven or 220V 1.5kW Steel split rims fitted with heavy duty electric ball bearings, rubber tyres and wheel scrapers MASS HEIGHT ADJUSTMENT 51kg - 62kg Variable sliding adjustment on all (depending on the Reel used) four wheels CUTTING WIDTH...
- Page 5 SPECIFICATIONS SVG500 SCARIFIER – VERTICUTTER – GROOMER 460103 Blade-Type Scarifying Reel: 18 Offset Blades with 25.4mm Spacing 460200 Verticutting Reel: 18 Straight Blades with 25.4mm Spacing 460197 Grooming Reel: 41 Star Shaped Blades with 10mm Spacing 460198 Pin-Type Scarifying Reel: 120 Hardened Concrete Nails OPERATING INSTRUCTIONS Before starting engine, clutch lever should be in upward or release position.To start engine, follow procedure outlined in engine manufacture’s instruction book.
- Page 6 ELECTRIC PAGE 1...
- Page 7 ELECTRIC Refer Figure ILLUS NO DESCRIPTION PART NO Handle 461953 Cord Carrier 305445 Cord Grip 173024 Lever 305470 Cord Hanger Shaft 461952 Woodruf Key 3802051 Switch 1662067 2.2kw Single Phase. 1671610 Flange Adaptor Plate 461950 Foot Adaptor Plate 461951 Plug Base 1661150 Cord Extention Plug 1661235...
- Page 8 PETROL FIG 1 PAGE 3...
- Page 9 SECTION 1 REFER FIGURE 1 ILLUS. PART DESCRIPTION Engine 5HP 6200302 V Belt - 13x770 - For EY20 3601297 Drive Shaft Pulley 461464 Drive Shaft (Petrol) 461878 Drive Shaft Bearing Ext. 461843 5/16 UNF x 1" Screw & Spring Washer Standard Belt Guard 461368...
- Page 10 FIGURE 2 PAGE 5...
- Page 11 SECTION 2 REFER FIGURE 2 ILLUS. PART DESCRIPTION Handle 461536 Control Lever with M10 Flat Washer & M3 Split Pin 305470 Control Rod with M8 Flat Washer & M3 Split Pin 461180 Inter Lever Bracket with 3/8" x 2" UNF Bolt & Nut 461181 Inter Control Lever 461552...
- Page 12 FIGURE 3 PAGE 7...
- Page 13 SECTION 3 REFER FIGURE 3 ILLUS. PART DESCRIPTION Body 461018 RH Adjusting Lever 461974 LH Adjusting Lever 461982 Wheel Quadrant 461026 Quadrant Bolt/Nut/Spring Washer M8 x 35 Standard Mud Scraper 461704 INT Circlip M35 Standard Jockey Arm Assy. with M8 x 25 Screw & Nyloc Nut 461229 Jockey Pulley Bearing 1126226...
- Page 14 ACCESSORIES PAGE 9...
- Page 15 SVG ACCESSORIES ILLUS. PART DESCRIPTION Verticut Reel Assy (19 Straight Blades) 460200 Scarifier Reel Assy (19 Offset Blades) 460103 Groomer Reel Assy (41 Blades) 460197 Pin Type Reel Assy (120 Pins) 460198 Groomer Reel Shaft 461956 Scarifier/Verticut Reel Shaft 461149 Shaft Lock Nut 1/2"...
