6.2 Bosch IDS BOVA2.0

Cooling Capacity
Nominal Cooling (BTU/h)
Nominal Heating (BTU/h)
Decibels([dB(A)]
Max @ 100% load
Min @ min load
Compressor
RLA
LRA
Condenser Fan Motor
Horsepower (HP)
FLA
Refrigeration System
Refrigerant Line Size¹
Liquid Line Size (OD)
Suction Line Size (OD)
Refrigerant Connection Size
Liquid Valve Size (OD)
Suction Valve Size (OD)
Refrigerant Charge (R410-A, oz)
Expansion Device
Maximum Line Length
Maximum Elevation Diff erence
Operating Range
Cooling
Heating
Electrical Data
Voltage-Phase-Hz
Minimum Circuit Ampacity²
Max. Overcurrent Protection³
Max Fuse Size
Min/Max Volts
Weight
Net Weight (without packaging)
Gross Weight (including packaging)⁴
Dimensions
Unit L x W x H (in.)
Outdoor Coil
Net face area - sq.ft. Outer Coil
Tube diameter-in.
No.of rows
Fins per inch
Table 6
¹ Tested and rated in accordance with AHRI Standard 210/240.
² Wire size should be determined in accordance with National Electrical Codes;
e xtensive wire runs will require larger wire sizes.
³ Must use time-delay fuses or HACR-type circuit breakers of the same size as
n oted.
⁴ Weight values are estimated.
Bosch Thermotechnology Corp. | 07.2021
BOVA 36
34,600
34,200
77
56
19
44
1/3
2.5
3/8"
3/4"
3/8"
3/4"
7 lbs. 9 oz.
EEV
150 FT
50 FT
15-125 ° F
-4~86 ° F
208/230-1-60
26.3
45
45
172V/270V
150
180
29-1/8 x 29-1/8 x 24-15/16
13.6
9/32" (7mm)
2
17
• Always check the rating plate for electrical data on the unit being
installed.
• Unit is factory charged with refrigerant for 15' of ⅜" liquid line.
System charge must be adjusted per Installation Instructions Final
Charge Procedure.
• TXV is required at indoor unit to match our outdoor unit.
Bosch IDS 2.0 | 13
BOVA 60
54,500
56,000
79
60
29
52
1/3
2.5
3/8"
7/8"
3/8"
7/8"
11 lbs. 5 oz.
EEV
150 FT
50 FT
208/230-1-60
38.8
60
60
220
253
29-1/8 x 29-1/8 x 33-3/16
18.4
9/32" (7mm)
2.8
19
Data subject to change
