6 Product Specifi cations

6.1 Bosch IDS BVA2.0

Cooling Capacity
Nominal Cooling (BTU/h)
Nominal Heating (BTU/h)
Blower
Diameter (mm)
Width (mm)
Fan Motor
Horsepower (HP)
Full Load Amps
Refrigeration System
Refrigerant Line Size¹
Liquid Line Size (O.D.)
Suction Line Size (O.D.)
Refrigerant Connection Size
Liquid Line Size (O.D.)
Suction Line Size (O.D.)
Expansion Device [TXV=Thermal Expansion Valve]
Decibels dB(A)
High Speed
Medium Speed
Low Speed
Electrical Data
Voltage-Phase-Hz
Minimum Circuit Ampacity ²
Max. Overcurrent Protection ³
Min / Max Volts
Air Filter
Air Filter Sizes
Weight
Net Weight (without packaging)(lbs)
Gross Weight (including packaging)(lbs) ⁴
Dimensions
Unit D x W x H (in.)
Unit D x W x H (in.)(with pallet and packaging)
Indoor Coil
Net face area-sq.ft.
Tube diameter
No.of rows
Fins per inch
Table 5
¹
Tested and rated in accordance with AHRI Standard 210/240.
² W ire size should be determined in accordance with National Electrical Codes;
extensive wire runs will require larger wire sizes.
³ Must use time-delay fuses or HACR-type circuit breakers of the same size as noted.
⁴ Weight shown includes packaging
Data subject to change
BVA024
24000
24000
10-5/8" (270) 10-63/64" (279)
8-5/32" (207) 10-43/64" (271)
1/3
2.6
3/8"
3/4"
3/8"
3/4"
63
59
55
208/230-1-60 208/230-1-60
3.3
15
18" x 20" 18" x 20"
119
132
21-5/8 x 19-5/8 x 46-1/2 21-5/8 x 19-5/8 x 46-1/2
25-3/8 x 22-5/16 x 52-9/16 25-3/8 x 22-5/16 x 52-9/16
4.02
9/32" (7 mm) 9/32" (7 mm)
4
17
BVA036 BVA048
34600 47500
34200 48000
10-63/64" (279)
10-43/64" (271)
1/2 3/4
3 4.5
3/8" 3/8"
3/4" 7/8"
3/8" 3/8"
3/4" 7/8"
TXV
65 67
62 63
58 59
208/230-1-60
3.8 5.7
15 15
172V/270V
20" x 22"
126 162
139 180
24 x 22 x 54-1/2
27-11/16 x 24-11/16 x 60-5/8
4.02 5.99
9/32" (7mm)
4 4
17 17
Service Manual
BVA060
54500
56000
10-63/64" (279)
10-43/64" (271)
3/4
4.5
3/8"
7/8"
3/8"
7/8"
68
64
60
208/230-1-60
5.7
15
20" x 22"
170
188
24 x 22 x 54-1/2
27-11/16 x 24-11/16 x 60-5/8
5.99
9/32" (7mm)
5
17
