Micromeritics Gemini VII 2390 Confirm Installation Instructions And Checklist page 51

Gemini VII 2390 Confirm
4. Ensure that Report after test is selected and that Screen is chosen as the destination.
Be sure Report after
test is selected and
Preview is the
destination.
5. Click
Next
series of messages is displayed. These messages are of the following types:
• Informative; for example, advising how long the test will take or how long before you
will be required to open or close a valve. Read the message and click
• Operator response; for example, you will be asked to open and close regulator and
gas bottle valves. Perform the task first, then click
6. After the test is finished, a dialog stating the test is complete is displayed; click
close the dialog.
Feb 09
; the second view of the Service Test dialog is displayed. On this dialog a
Low-pressure gauge
Regulator Shut-Off valve
Gemini VII 2390 Confirm Installation Instructions and Checklist
Connecting Gases
OK
.
OK
Gas Bottle Shut-Off valve
Pressure Control knob
to proceed.
to
OK
45
