Page 1: User Manual
COLORstrip™ Foot Controller LED-FS1 USER MANUAL 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com Snapshot OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle... -
Page 2: Table Of Contents
Speed Switch (2)... 6 Function Switch (3) ... 6 Blackout Switch (4) ... 6 ... 7 ENERAL ROUBLESHOOTING ... 8 ECHNICAL UPPORT ... 8 ENERAL AINTENANCE ... 8 ETURNS ROCEDURE ... 8 LAIMS ... 9 ECHNICAL PECIFICATIONS LED-FS1 10/17/2007 1:02 PM... -
Page 3: Before You Begin
Power The LED-FS1 unit receives power from the COLORstrip™ through the supplied 6-pin linking cable. You should treat this cable as a power cable and a signal cable, as it carries voltage, yet is susceptible to damage if it becomes bent or crimped by being placed under something heavy, under a sharp corner, or otherwise mutilated. -
Page 4: Safety Instructions
Never disconnect the linking cable by pulling or tugging on the cord. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. LED-FS1 10/17/2007 1:02 PM... -
Page 5: Introduction
Designed for COLORstrip™ LED • Control of: blackout, static colors, chase programs, strobe speed • 10ft., 6-pin cable included Product Overview Power Indication Light Scene Button Speed Button LED-FS1 Linking Cable Connection (rear) Function Button Blackout Button 10/17/2007 1:02 PM... -
Page 6: Operating Instructions
Blackout Switch (4) This button allows users to blackout the fixture, disabling all output from the unit. If the button is clicked with the unit already in blackout mode, it will immediately resume the last running program. LED-FS1 NSTRUCTIONS Additional Functions... -
Page 7: General Troubleshooting
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. LED-FS1... -
Page 8: Technical Support
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 9: Technical Specifications
Length... 16 in (406 mm) Width ...7 in (178 mm) Height ...3 in (76 mm) Weight ... 5 lbs (2.3 kg) THERMAL Maximum ambient temperature...104°F (40°C) ORDERING INFORMATION COLORstrip™ Footswitch Controller ... LED-FS1 WARRANTY INFORMATION Warranty ... 1-year limited warranty LED-FS1 10/17/2007 1:02 PM...
