INSTALLATION
INSTRUCTIONS
MODELS 3014-3020
WARNING: INSTALLATION OF THIS PRODUCT NEAR
POWER LINES IS DANGEROUS. FOR YOUR SAFETY,
READ THE ENCLOSED "DANGER" BOOKLET BEFORE
BEGINNING YOUR INSTALLATION.
ADVANTAGE
"DIGITAL READY"
UHF/VHF/FM TV ANTENNAS
AIM
TOWARDS
TRANSMITTING
STATION
AIM
TOWARDS
TRANSMITTING
STATION
Advertisement
Table of Contents
Related Manuals for Channel Master Advantage 3014
Summary of Contents for Channel Master Advantage 3014
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS MODELS 3014-3020 WARNING: INSTALLATION OF THIS PRODUCT NEAR POWER LINES IS DANGEROUS. FOR YOUR SAFETY, READ THE ENCLOSED “DANGER” BOOKLET BEFORE BEGINNING YOUR INSTALLATION. ADVANTAGE "DIGITAL READY" UHF/VHF/FM TV ANTENNAS TOWARDS TRANSMITTING STATION TOWARDS TRANSMITTING STATION... -
Page 2: Lightning Protection
8’ ground rod. Keep the line at a respectable distance from your transmission wire to prevent signal interference. A coaxial grounding block (Channel Master Model 3274), should be connected to the antenna transmission wire at the point where it enters the house. - Page 3 Using a roof mount, attach a short piece of mast to a conven- ient roof rafter. Attach and aim the antenna in the same man- ner as outlined for outdoor installations. NOTE: Antennas should not be installed in an attic if the roof or walls are metal or are lined with foil backed insulation.
- Page 4 1. If antenna has a 2 or 3-section crossarm (boom), assemble the sections with screws and wing nuts. (See Fig. 1). On 3-section antennas, assemble with the short elements to the front of antenna and the long elements to the rear of antenna.
