4 - MAINTENANCE SPDM CONTROL BOX
When the installation completes the download process will start again
for the next module, repeating these steps for each module you have
selected in your firmware setup. When all is finished a message will
pop-up displaying "Installation performed." message and the Next
button gets enabled. Click on it to go to the next step.
Fig. 4.4-13 - Download Firmware. Installation performed
Drive Check
The next page automatically connects to the drive, reads all the
software versions that are installed and compares them with the
software version that has just been downloaded.
If all the versions match, the firmware is updated successfully, then the
Next button is enabled and you can go to the next step by clicking on it.
If some version mismatch occurs the Next button is disabled. If you
want to go on anyway you will have to click on Continue anyway ...
button (Not Recommended!).
Fig. 4.4-14 - Version Check
Drive parameter values restore
If you previously saved the drive parameter values A new message will
prompt you. Click on Yes to restore values or No to skip an go on to the
next step (Changing the IP Address section).
Fig. 4.4-15 - Restore drive parameter values
When the update process starts you will have to wait for it to complete.
The Next button will be enabled when restore process is complete.
Fig. 4.4-16 - Restoring drive parameter values process started
