3 – SYSTEM2 BOARD
3.1
Jumpers, switches and buttons
3.1.1
Jumpers
This section describes the jumper settings. It is recommended to shut down the power of the card before configuration of the jumpers.
The following figure shows the layout of the jumpers on the component side.
32
Figure 3-2: Jumpers layout.
