Summary of Contents for Buell S3T Thunderbolt 2002
- Page 1 2002 BUELL S3T SERVICE MANUAL Part Number 99489-02Y Section 1: Maintenance Section 2: Chassis Section 3: Engine Section 4: Fuel System Section 5: Starter Section 6: Drive/Transmission Section 7: Electrical Appendix...
- Page 2 HOME APPENDIX B - ELECTRICAL CONNECTORS GENERAL The following table provides a brief description of the connec- tors found on the S3T Thunderbolt. Connector numbers are listed in [brackets] in this manual. Table B-1. Electrical Connectors Connector Component(s) Description [10] Electronic Control Module (Black) 12-place Deutsch [11]...
- Page 3 HOME DEUTSCH ELECTRICAL CONNECTORS GENERAL b0070x7x The Deutsch Connector features a superior seal to protect electrical contacts from dirt and moisture in harsh environ- ments. Three and eight pin connectors are of similar construction with one exception: eight pin connectors use two external latches on the socket side.
- Page 4 HOME face straight upward. When correctly positioned, the x0014a7x locking bar fits snugly in the space between the contact band and the core crimp tails. Strip lead removing 5/32 in. (4.0 mm) of insulation. Insert Housing wires between crimp tails until ends make contact with locking bar.
- Page 5 Thank you very much for your reading. Please click here and go back to the website. Then, download the complete manual instantly. No waiting.
