- Page 1 VM10-K2 Multi-functional Smartphone Video Kit User Manual...
-
Page 3: Main Features
Foreword Thanks for purchasing CVM-VM10-K2 PRO Multi-functional Smartphone Video Kit. To ensure bring you a good using experience, please read this manual book carefully before using and correctly install and operate. Main Features . Support Horizontal and Vertical Shooting . 360°Adjustable Rotation, Stable and Convenient . -
Page 4: Components Introduction
Components Introduction 1. Mic Capsule 9. Height Adjustment Locking Plate 2. 3.5mm TRS Audio Output Port 10. Smartphone Holder Locking Plate 3. Cold Shoe Mount 11. Ball Head Locking Plate 4. Cold Shoe 12. 1/4 Threaded Hole 5. 1/4 Male Screw 13. - Page 5 Installation and Operation 1. Put the ball head into the tripod through the 1/4 threaded hole and tighten it Install the smartphone holder on the ball head through the 1/4 threaded hole, then tighten it through the smartphone holder locking plate and ball head locking plate Insert the microphone’s cold shoe mount into the cold shoe, and then tighten the microphone locking plate to fix it...
- Page 6 2. Adjust the phone holder to an appropriate height through the height adjustment locking plate, then install the phone and fix it Height Adjustment Locking Plate...
- Page 7 3. Connect the microphone to the smartphone through the 3.5mm TRS-TRRS audio cable. TRS connector is for microphone, TRRS connector is for smartphone TRS connector TRRS connector TRS connector TRRS connector...
- Page 8 4. You can adjust the use angle of smartphone holder by lever of the ball head Lever...
-
Page 9: Specification
Specification Microphone 1. Frequency Response 2. Polar Pattern 3. Technology Parameters Polar Pattern Cardioid Frequency Response 60Hz~20kHz >75dB Maximum SPL >105dB Sensitivity Range -33dB±2dB Operating Voltage 1V~10V DC Output Interface 3.5mm Dimensions Φ21mm x 85mm Net Weight 34.2g Operating temperature 0~50℃... - Page 11 VM10-K2 多功能手机拍摄套装 产品使用说明书...
- Page 13 前 言 感谢您购买科唛CVM-VM10-K2 PRO多功能手机拍摄套装。 使用前请认真阅读此使用说明书，本产品在出厂时已进行精密校准，请勿自行组 装拆卸零部件，否则不予保修！ 产品主要功能 .支持手机横竖拍任意模式 .云台可360度旋转，稳固牢靠 .心型指向专业麦克风音视频套装 .内置冷靴接口多功能手机夹，延展性强 .全金属CNC加工而成，稳固耐用 注意事项 使用时请远离热源或干扰源 使用时请避免掉落，碰撞或重击 请勿在下雨或潮湿环境中使用，否则会有短路的危险 包装清单 1. 麦克风 2. 手机夹 3. 云台 4. 三角架 5. 3.5mm TRS-TRRS音频线 6. 防风毛 7. 便携包 8. 说明书 9. 保修卡 ① ② ③ ④...
- Page 14 部件介绍及说明 1. 拾音头 8. 麦克风锁紧螺盘 2. 3.5mm TRS音频输出插口 9. 手机夹高度调整螺盘 3. 冷靴座 10. 手机夹锁紧螺盘 4. 冷靴 11. 云台锁紧螺盘 5. 1/4螺纹接头 12. 1/4螺纹孔 6. 方向锁紧旋钮 13. 1/4螺纹孔 7. 1/4螺纹接头 14. 1/4螺纹孔 ① ② ⑧ ③ ④ ⑫ ⑨ ⑩ ⑤ ⑬ ⑪...
- Page 15 安装方法 1.把云台通过1/4螺纹孔装入三角架并拧紧； 把手机夹通过1/4螺纹孔装入云台，再通过手机夹锁紧螺盘与云台锁紧 螺盘拧紧固定； 把麦克风冷靴座插入手机夹冷靴，再通过麦克风锁紧螺盘拧紧固定...
- Page 16 2.通过手机夹高度调整螺盘调整手机夹到适当的高度；装入手机并固定 手机夹高度调整螺盘...
- Page 17 3.通过3.5mm TRS-TRRS音频线连接麦克风与手机，注意连接麦克风的一 头为TRS接头，连接手机的另一头为TRRS接头 TRS接头 TRRS接头 TRS接头 TRRS接头...
- Page 18 4.通过云台的方向紧锁旋钮可调整手机夹的使用角度 方向锁紧旋钮...
- Page 19 规格参数 麦克风 1.频率响应 2.指向性图 3.性能参数 指向性 心型 频响 60Hz~20kHz 信噪比 >75dB >105dB 最大声压级 灵敏度 -33dB±2dB 工作电压 1V~10V DC 输出接口 3.5mm 尺寸 Φ21mm x 85mm 净重 34.2g 工作温度 0~50℃...
