BTL -07p Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
operating manual
&
user's guide
v2.10z6BJ24/03/2004EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTL-07p and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BTL BTL-07p

Summary of Contents for BTL BTL-07p

  • Page 1 operating manual & user’s guide v2.10z6BJ24/03/2004EN...

  • Page 2: Table Of Contents

    BTL – 07p operating manual & user's guide DIRECTIONS FOR USE........................... 4 Outer appearance Controls and dipslays Connection to the mains Choosing the ultrasound frequency Choosing and connecting emitter head Choosing PPR (pulse-to-period ratio) Choosing pulse frequency Choosing intensity of acoustic output...
  • Page 3 BTL – 07p operating manual & user's guide Ultrasound + TENS (transcutaneous electrostimulation) Mechanism of action Application time Intensity Total number of treatments Frequency of treatment Procedure prescription A therapeutic example III. LIST OF PROGRAM NUMBERS FOR ULTRASOUND THERAPY ............19 LIST OF PROGRAM NUMBERS FOR COMBINED ULTRASOUND THERAPY/ELECTROTHERAPY..

  • Page 4: Directions For Use

    DIRECTIONS FOR USE FRONT PANEL OF BTL-07p Outer appearance Front panel features: pilot-lights, displays, push-buttons, input for emitter head, input for BTL-06, input for electrical cable, mains switch, fuses, serial and model number are located on the rear panel. Controls and dipslays Display indicating power absorbed by patient (in kilojoules).

  • Page 5: Connection To The Mains

    The pulse ultrasound (1:2 - 1:16 PPR) allows the user to choose one of the pulse frequencies and the time duration. The BTL-07p uses 50 Hz and 100 Hz pulse frequencies. Press the PULSE FREQUENCY button (16) to switch between the two frequencies. The activated pulse frequency is indicated by the diode next to the PULSE FREQUENCY button (14).

  • Page 6: Time Setting

    There is an increased local temperature in these areas. BTL-07p emitter heads have a very low BNR. Further more, the BTL-07p features an optic indicator to signal stationary waves, placed on the Bar-graph (10) (the orange LED diode). Respond to this signal by immediately removing the emitter head from the application site in order to eliminate any risk of soft tissue damage.

  • Page 7: Starting The Combined Therapy

    Never use the connectors for anything else but the electrotherapeutic instrument and the emitter head. The user should not use the instrument, if it does not work as described in this manual. Contact your BTL service technician. The user is responsible for all damages resulting from using such an instrument.

  • Page 8: Useful Addresses

    BTL – 07p operating manual & user's guide Useful addresses The product is manufactured in accordance with the EU Medical Devices Directive by : BTL Industries Ltd. Suite 401 Albany House 324-326 Regents Street London, W1B 3BL United Kingdom E-mail: sales@btlnet.com...

  • Page 9: Technical Specifications Of Probe

    BTL – 07p operating manual & user's guide If this signal persists, try to calibrate the emitter head. The 07p calibration procedure should be done as follows: • Prepare yourself some water container for app. 0.5 liter (water temperature should be around 30 °C) with a sponge (or some swab or cotton wool) at the bottom.

  • Page 10: Pulse Width

    Each BTL-07p instrument has its own specific ultrasonic emitter heads that are produced and set only for that particular unit. Do not use emitter heads from a different BTL-07p unit or an ultrasound unit made by another producer. Protect the emitter heads from shock or intense cold. Do not bend the cable. Be especially careful with the emitter head connection area.

  • Page 11: User's Guide

    It is necessary to move the emitter head continuously (see below) to prevent tissue lesions at peaks of intensity. The BTL-07p signals when there are stationary waves and stops ultrasonic power generation until stationary waves are eliminated through more rapid movement of the emitter head.

  • Page 12: Methods Of Application

    BTL – 07p operating manual & user's guide Increases in local temperature and micromassage have several physiological effects: 1. Improvement in local circulation resulting in metabolic improvement. Vasodilatation increase follows the increasing temperature (more evident in continuous ultrasound). 2. Increased permeability of capillaries resulting in quick extravasation humour absorption.

  • Page 13: Ultrasound Frequency

    With a PPR smaller than 1:8, an athermic effect can be expected. The BTL-07p’s impulse time is shown by a proportional number. This number actually represents a fraction, which expresses a certain part of the ultrasonic emission period. With a pulse frequency of 100 Hz, the period time is 10 ms.

  • Page 14: Specific Contraindications Of Ultrasonic Therapy

    BTL – 07p operating manual & user's guide Specific contraindications of ultrasonic therapy A) Absolute Epiphysis of growing bones Ultrasound patients risk irreversible growth zone damage, deformity and/or permanent disablement. Since older types of ultrasound instruments operate at low intensities (displayed data does not correspond with the actual amount of the energy applied), their use does not lead, in most cases, to growth zone damage.

  • Page 15: Procedure

    BTL – 07p operating manual & user's guide Procedure Prescription Name, surname, date of birth, insurance company Name and number of diagnosis and stage of disease Name of procedure - ultrasound + the form. PPR (if pulse ultrasound is used)

  • Page 16: Combined Therapy

    Ultrasound and low frequency currents Can be used with one unit or by connecting two separate units (BTL-06 + BTL-07p). The desired current with an adjustable intensity should be brought to the emitter head. The other electrode is placed opposite the emitter head so that the ultrasound field and the low frequency current are both located in the treatment area.

  • Page 17: A Therapeutic Example

    Use a 1 MHz ultrasound frequency when treating deeply underlying muscles. The combination of the BTL-06 and BTL-07p offers a selection of ultrasound parameters and amplitude modulations Hence these currents can be used for surface muscles (at a 3 MHz frequency) as well as deep...
  • Page 18 Large haematoma in m.quadriceps femoris after contusion, more than 24 hours after injury, very painful. Haematoma gravis reg.m.quadricipitis fem. l. sin.,S 70.1, acutus Combined therapy ultrasound + TENS burst (BTL-06 + BTL-07p) Ultrasound: 1MHz, 1:16 PPR, 1 W/cm , emitter head 4 cm...
  • Page 19 BTL – 07p operating manual & user's guide III. LIST OF PROGRAM NUMBERS FOR ULTRASOUND THERAPY List of diagnoses Arthritis rheumatoides Arthritis rheumatoides (subaqualis) Arthrosis chronica Arthrosis chronica (inactiva) Arthrosis subchronica Bursitis acuta Bursitis chronica Bursitis subacuta Cicatrix acuta Cicatrix cheloidum...
  • Page 20 BTL – 07p operating manual & user's guide Arthritis rheumatoides Emitter head: 1 cm . Frequency: 3 MHz, 1:4 PPR. Intensity: 0.8 - 1.2 W/cm , step 0.1 W/cm . Semistatic application. Application time: 5 minutes, 2 - 3x a week. Total number of treatments: 6 - 10.
  • Page 21 BTL – 07p operating manual & user's guide 11. Cicatrix subacuta Emitter head: 1 cm . Frequency: 3 MHz, 1:2 PPR. Intensity: 0.5 - 1.0 W/cm , step 0.1 W/cm Application time: 4 minutes, 3 - 5x a week. Total number of treatments: 3 - 5.
  • Page 22 BTL – 07p operating manual & user's guide Application time: 3 - 5 minutes, 1 minute steps, 3 - 5x a week. Total number of treatments: 6 - 9. Apply to fibres with inner incoordination or to previously diagnosed trigger points.
  • Page 23 BTL – 07p operating manual & user's guide 31. Spondylarthrosis ancylopoetica (M. Bechterevi) Emitter head: 4 cm . Frequency: 1 MHz, 1:1 PPR. Intensity: 1.0 - 2.0 W/cm , step 0.1 W/cm . Dynamic application. Application time: 15 minutes, 3x a week. Total number of treatments: 9 - 12.
  • Page 24 BTL – 07p operating manual & user's guide Application time: 5 minutes, 2 - 3x a week. Total number of treatments: 5 - 15. Physiotherapy must follow. 41. Tendovaginitis subacuta Emitter head: 4 cm . Frequency: 3 MHz, 1:4 PPR. Intensity: 1.0 - 1.5 W/cm , step 0.1 W/cm...
  • Page 25 BTL – 07p operating manual & user's guide LIST OF PROGRAM NUMBERS FOR COMBINED ULTRASOUND THERAPY/ELECTROTHERAPY Lumbalgie Myalgia mm. superficiales Myalgia mm. profundi Relaxatio mm. superficiales Relaxatio mm. profundi Trigger points mm. superficiales Trigger points mm. profundi Zona hyperalgesica page 25...
  • Page 26 BTL – 07p operating manual & user's guide List of program numbers for combined ultrasound therapy/electrotherapy 51. Lumbalgie Emitter head: 4 cm . Frequency: 3 MHz, 1:4 PPR. Intensity: 0.5 W/cm Electrotherapy: TENS cont., f = 100 Hz constant (program 1625).
  • Page 27 BTL – 07p operating manual & user's guide Note the current intensity in mA, causing the reaction. B/ TP treatment Without moving the head, change the PPR to 1:2, maintaining the original intensity and using either a semi- stationary or a stationary method to apply the combined therapy directly to the TP for 1 - 3 minutes. There must be no standing waving - acoustic and optical indication.
  • Page 28 The contents of this document is provided "as is". Except as required by applicable law, no warranties of any kind, either expressed or implied, are made in relation to the accuracy, reliability or contents of this document. BTL Industries Limited reserves the right to revise this document or withdraw it at any time without prior notice.
