Summary of Contents for Miller Cool Runner 3CS OM-230 161 F

  • Page 1 OM-230 161 F 2012−08 Processes TIG (GTAW) Welding MIG (GMAW) Welding Description Cool Runner 3CSt File: TIG (GTAW) Visit our website at www.MillerWelds.com...
  • Page 2 We know you don’t have time to do it any other way. That’s why when Niels Miller first started building arc welders in 1929, he made sure his products offered long-lasting value and superior quality.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION 1 − SAFETY PRECAUTIONS - READ BEFORE USING ....... . . 1-1.
  • Page 5: Section 1 − Safety Precautions - Read Before Using

    SECTION 1 − SAFETY PRECAUTIONS - READ BEFORE USING coolers 2011−10 Protect yourself and others from injury — read, follow, and save these important safety precautions and operating instructions. 1-1. Symbol Usage DANGER! − Indicates a hazardous situation which, if Indicates special instructions.
  • Page 6: California Proposition 65 Warnings

    1-4. California Proposition 65 Warnings Welding or cutting equipment produces fumes or gases This product contains chemicals, including lead, known to which contain chemicals known to the State of California to the state of California to cause cancer, birth defects, or other cause birth defects and, in some cases, cancer.
  • Page 7: Section 2 − Consignes De Sécurité − Lire Avant Utilisation

    SECTION 2 − CONSIGNES DE SÉCURITÉ − LIRE AVANT UTILISATION Cooler 2011−03fre Pour écarter les risques de blessure pour vous−même et pour autrui — lire, appliquer et ranger en lieu sûr ces consignes relatives aux précautions de sécurité et au mode opératoire. 2-1.
  • Page 8: Proposition Californienne 65 Avertissements

    Les PIÈCES MOBILES peuvent LIRE LES INSTRUCTIONS. causer des blessures. D Lire et appliquer les instructions sur les D S’abstenir de toucher des organes mobiles tels étiquettes et le Mode d’emploi avant l’instal- que des ventilateurs. lation, l’utilisation ou l’entretien de l’appareil. Lire les informations de sécurité...
  • Page 9: Section 3 − Definitions

    SECTION 3 − DEFINITIONS 3-1. Additional Safety Symbols And Definitions Some symbols are found only on CE products. Warning! Watch Out! There are possible hazards as shown by the symbols. Safe1 2012−05 Do not remove or paint over (cover) the label. Safe20 2012−05 Disconnect input plug or power before working on machine.
  • Page 10: Miscellaneous Symbols And Definitions

    3-2. Miscellaneous Symbols And Definitions Water (Coolant) Hertz Input Power Power On Indicator Output Single-Phase Water (Coolant) In- Line Connection Alternating Primary Voltage Current Rated Maximum Degree Of Rated maximum Power liters per 1max Supply Current Protection power minute SECTION 4 − SPECIFICATIONS 4-1.
  • Page 11: Section 5 − Installation

    SECTION 5 − INSTALLATION 5-1. Installation Base Secure base to power source. Bottle Support Chain Secure bottle support to power source. Connect chain to bottle support. Universal Handle Secure handles to power source. Tools Needed: 3/8 in. 805 139-C 9/16 in. SECTION 6 −...
  • Page 12: Optional Cooler Connections

    6-2. Optional Cooler Connections Disconnect cooler plug from welding power source re- ceptacle before filling. Remove cap and fill tank with three gallons of coolant (see Section 4-3). Gas Out Connection Connect TIG torch gas hose to gas out fitting. Electrode Weld Output Terminal TIG Block (Customer Sup-...
  • Page 13: Section 7 − Maintenance & Troubleshooting

    Every Months ZChange coolant if using water. nl Labels nlHoses Every Months ZChange coolant (if using Miller coolant). 7-2. Coolant Maintenance Disconnect cooler plug from welding power source re- ceptacle before maintaining. Coolant Filter Unscrew housing to clean filter. Changing coolant: Drain coolant by tipping unit forward.
  • Page 14: Troubleshooting

    7-3. Troubleshooting Trouble Remedy Coolant system does not work. Be sure input power cord is plugged in to energized receptacle. Check line fuses or circuit breaker, and replace or reset if necessary. Motor overheated. Unit starts running when motor has cooled. Have Factory Authorized Service Agent check motor.
  • Page 15: Section 9 − Parts List

    SECTION 9 − PARTS LIST Hardware is common and not available unless listed. 805 100-D Figure 9-1. Running Gear For Cool Runner 3CS Item Dia. Part Mkgs. Description Quantity Figure 9-1. Running Gear For Cool Runner 3CS Cooler ..
  • Page 16 Hardware is common and not available unless listed. 804 995-A Figure 9-2. Cooling Unit Main Assembly OM-230 161 Page 12...
  • Page 17 Item Part Description Quantity Figure 9-2. Cooling Unit Main Assembly ... . . 213072 Fan, Muffin 115 V 60 Hz 3400 RPM 6.378 Mtg Holes ....
  • Page 18 Notes TM-216 869 Page 14 Dynasty 350/700, Maxstar 350/700...
  • Page 19 Effective January 1, 2012 (Equipment with a serial number preface of MC or newer) This limited warranty supersedes all previous Miller warranties and is exclusive with no other Warranty Questions? guarantees or warranties expressed or implied. LIMITED WARRANTY − Subject to the terms and conditions 90 Days —...
  • Page 20 Contact the Delivering Carrier to: File a claim for loss or damage during shipment. For assistance in filing or settling claims, contact your distributor and/or equipment manufacturer’s Transportation Department.  ORIGINAL INSTRUCTIONS − PRINTED IN USA 2012 Miller Electric Mfg. Co. 2012−01...
