Summary of Contents for DriSteem RTS SDU-I-RX
- Page 1 READ AND SAVE THESE INSTRUCTIONS SDU-I-RX AND SDU-E-RX For RTS Hu mi di fier Installation, Operation, and Maintenance Manual...
- Page 2 Steam 3.13” (80 mm) outlet OM-8111 Table 2-1: SDU dimension SDU model SDU-I-RX 24.7 16.0 17.9 11.4 Ø1.5 Ø38 SDU-E-RX (SM) 24.7 16.0 16.1 11.4 Ø1.5 Ø38 SDU-E-RX (MD) 26.2 20.0 16.1 11.9 Ø2.0 Ø51 DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS...
-
Page 3: Specifications
SDU-E-RX (SM) is available for all RX-XX-1 models. SDU-E-RX (MD) is available for all RX-XX-2 models up to 102 lbs/hr. RX-XX-3 and RX-XX-4 models cannot be used with an SDU. SDU's ship separate from the RX humidifier. DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS... - Page 4 Mounting MOUNTING SDU-I-RX AND SDU-E-RX SDUs can be mounted on a wall directly above a RTS humidifier cabinet, 18" above any other DriSteem humidifier, or mounted on a wall remote from the humidifier. • Installation must comply with governing codes.
- Page 5 SDU chassis an assembly. 16" (406 mm) Keyhole for 3/8" dia. (M10) fasteners RTS chassis OM-8112 FIGURE 5-2: STACKING A WALL-MOUNTED RTS AND SDU-I-RX OR SDU-E-RX Air intake vents Steam outlet OM-8113 DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS...
- Page 6 • Spread: The minimum nonwetting width from the steam outlet of the SDU-E-RX. • Throw: The minimum nonwetting horizontal distance from the steam outlet of the SDU-E-RX. FIGURE 6-1: SDU-E-RX RISE, SPREAD, AND THROW Air intake Steam outlet grille Rise Throw Spread OM-8114 DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS...
- Page 7 TRANSFORMER 600V TO 120V 500VA GE 408996-009 TRANSFORMER 230/400V TO 120V 500VA CE 408996-011 TRANSFORMER 208/277/380 V TO 115V 500VA. 408996-012 RELAY 24V DPDT FINDER 407900-016 SOCKET RELAY DPDT W/OUT TIME DELAY 407900-019 DISPERSION, SDU-I-RX ASSEMBLY 180005 DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS...
-
Page 8: Replacement Parts
TRANSFORMER 208/277/380V TO 115/95V 300V 408996-004 TRANSFORMER 230/400V TO 120V 500VA CE 408996-011 SOCKET RELAY DPDT W/OUT TIME DELAY 407900-019 RELAY 24V DPDT FINDER 407900-016 DISPERSION CHAMBER 1-1/2" RTS SDU-E-RX 160445-915 DISPERSION CHAMBER 2" RTS SDU-E-RX 160445-902 DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS... - Page 9 Notes DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS...
- Page 10 Notes DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS...
- Page 11 Notes DRISTEEM RTS HUMIDIFIER SDU INSTRUCTIONS...
- Page 12 Expect quality from the industry leader Since 1965, DriSteem has led the industry with innovative methods for humidifying and cooling air with precise control. Our focus on ease of ownership is evident in the design of our humidifiers. DriSteem also leads the industry with a Two-year Limited Warranty and optional extended warranty.
