- Page 1 User & Installation Manual MODEL: Solway Small BS EN 13240:2001 + A2:2004 Solway Medium Tested as intermittent appliances burning wood logs Solway Large www.mi-fires.com Version 2 2020.02.22...
-
Page 2: Table Of Contents
Solway Multifuel Stove CONTENTS SECTION CONTENTS PAGE The clean air act 1993 and smoke control areas ..3 Product Specification ....... .4 Important information about installing and using the stove . -
Page 3: The Clean Air Act 1993 And Smoke Control Areas
(59 kgs Small, 76 kgs Medium, 89 kgs Large). This steel body with cast iron door stove MI-Fires Solway have been recommended as suitable for use in smoke control areas when burning wood and authorised smokeless fuel. -
Page 4: Product Specification
2. PRODUCT SPECIFICATIONS SOLWAY SMALL Item No. MI-Fires Solway Small Weight 59KGS Dimensions 350mm (max footprint/exc handle) x 230mm (max footprint/exc (WxDxH mm) handle) x 487mm (exc flue) Flue size 125mm SOLWAY MEDIUM Item No. MI-Fires Solway Medium Weight 76KGS... -
Page 5: Important Information About
SMOKELESS ANTHRACITE RESULTS PARAMETER SMALL MEDIUM LARGE MEAN MEAN MEAN Total efficiency 79.2 86.5% 79.6% Nominal heat output 4.5 kW 4.9 kW 8.0 kW Mean CO emission 9.14 11.81% 11.20% Mean CO emission 0.12 0.17% 0.13% Mean CO emission (at 13 % O 0.09% 0.10% 0.08%... -
Page 6: Unpacking & Assembly
For your safety it is very important that your stove is correctly installed. Our Stoves cannot accept any responsibility for any fault arising through incorrect installation or use. MATERIAL CLEARANCES The stove must have a minimum clearance to a combustible below. SOLWAY SMALL Floor Protector Minimum Size (mm) Minimum distance to combustible wall... - Page 7 SOLWAY MEDIUM Floor Protector Minimum Size (mm) Minimum distance to combustible wall SOLWAY LARGE Floor Protector Minimum Size (mm) Minimum distance to combustible wall See diagrams above for the recommended products from an open-flued appliance. This distance from combustible materials. can occur even if the appliance and the fan are in different rooms.
-
Page 8: Operating Instructions
Flue pipes with a smaller cross-sectional area ashing and refueling may occur. Persistent than that of the stove outlet should never fume emission must not be tolerated. If fume be used. Flue pipes must not project into emission persists, the following immediate the chimney connector, such as to cause a action should be taken: restriction to the gas flow. - Page 9 BEFORE LIGHTING ■ Under normal chimney draft conditions expect to refuel the stove every 45 to 60 If using for the first time, or following a long minutes. period out of use check that the flue is clear REFUELLING PROCEDURE and unobstructed.
-
Page 10: Guidance On Safe Operation
The maximum amount of fuel specified has cool down, then use a brush let the ash in this manual should not be exceeded, fall from bed of the fire into the ash pan overloading can cause excess smoke. underneath. Then take out of the ashpan. If you have the vacuum cleaner, suck the ash Operation with the door open can cause into the vacuum cleaner directly. -
Page 11: Maintenance
8. MAINTENANCE CLEANING During prolonged periods out of use, the air inlets should be left open and the door The inside of the stove may require regular left slightly ajar in order to circulate fresh air cleaning, especially during periods of peak and discourage condensation from forming use, the frequency of this being indicated by which could encourage corrosion. -
Page 12: Fault Finding
CHIMNEY Note: All parts that are in direct contact with the fire (grate, Baffle, back or side air boxes) It is important to have the chimney cleaned are considered as normal wear parts. at least once a year. Their life will be depend on how vigorously the Regular inspection and cleaning of the stove is operated and they must be inspected internal components of the stove can indicate... -
Page 13: Ce Data Plates
Hearth temp >100°C FOLLOW THE USER’S INSTRUCTIONS USE ONLY RECOMMENDED FUELS APPLIANCE IS CAPABLE OF INTERMITTENT OPERATION APPLIANCE SHOULD NOT BE INSTALLED IN A SHARED FLUE Mi-Fires is part of the Mi-Flues Ltd group of companies. Tel: +44 (1253) 600060. - Page 14 Hearth temp >100°C FOLLOW THE USER’S INSTRUCTIONS USE ONLY RECOMMENDED FUELS APPLIANCE IS CAPABLE OF INTERMITTENT OPERATION APPLIANCE SHOULD NOT BE INSTALLED IN A SHARED FLUE Mi-Fires is part of the Mi-Flues Ltd group of companies. Tel: +44 (1253) 600060.
- Page 15 Hearth temp >100°C FOLLOW THE USER’S INSTRUCTIONS USE ONLY RECOMMENDED FUELS APPLIANCE IS CAPABLE OF INTERMITTENT OPERATION APPLIANCE SHOULD NOT BE INSTALLED IN A SHARED FLUE Mi-Fires is part of the Mi-Flues Ltd group of companies. Tel: +44 (1253) 600060.
- Page 16 MI-Flues Ltd Taymin Business Park Mitcham Road sales@mi-flues.com Blackpool, Lancashire sales@mi-fires.com FY4 4QN www.mi-fires.com...
