Azur 840A/C Remote Control Commands
Commands can be received in three ways:
-
modulated IR from the remote control
-
modulated IR signals input to the IR In socket (on the rear panel)
-
unmodulated positive logic TTL level commands input to the Control
Bus In socket (on the rear panel)
The 840C responds to the IR commands shown in the table below:
ALL commands are NEC format with a System Code of A0 A0
Key
1
2
3
4
5
6
7
8
9
0
1+
Prog
Play
Pause
Stop
Random
Remain
Skip left
Skip right
Repeat
AB
<<
>>
Intro
Space
Open
Power toggle
Power On
Power Off
Bright toggle
Menu
Select
Mute
Mute on
Mute off
Gallery Court, Hankey Place, London SE1 4BB England
Tel: +44 (0)20 7940 2200 Fax: +44 (0)20 7940 2233 Web: www.cambridge-audio.com
Command Code (hex)
01
09
11
19
02
0A
12
1A
03
0B
13
1B
15
1D
1C
0E
0F
04
0C
16
17
05
0D
06
1E
07
44
46
45
47
48
49
4A
4B
4C
