10260A Series Actuators Installation, Operations, and Maintenance Manual

9.2.7 Actuator Up/Down action does not operate correctly.

Table 9-8 explains how to troubleshoot the Up/Down Actuator action.
Step
1 Check motor by driving directly.
2 Check motor by driving directly.
3 Check Limit Switch operation.
4 Check Limit Switch operation.
76 10260A Series Actuators – Installation, Operations, and Maintenance

Table 9-8 Troubleshooting the Up/Down Actuator Action

What to Do How To Do it or Where to Find the Instructions
Apply the AC Main supply voltage to TB-5.
Actuator should drive in the Up direction. If not
replace motor.
Apply the AC Main supply voltage to TB-6.
Actuator should drive in the Down direction. If not
replace motor.
Apply the AC Main supply voltage to TB-9.
Actuator should drive in the Up direction. If not
check adjustment of Limit Switches and replace
SW2 if necessary.
Apply the AC Main supply voltage to TB-8.
Actuator should drive in the Down direction. If not
check adjustment of Limit Switches and replace
SW1 if necessary.
2/03
