3.3.3 Projecting Scale Option

The projecting scale option is available for customers whose actuators are direct coupled that it would be
impossible to read the standard scale on the actuator. The projecting scale sits above the actuator and is
readable from a distance. See Figure 3-10 Projecting Scale Option.
20 10260A Series Actuators – Installation, Operations, and Maintenance

Figure 3-10 Projecting Scale Option
