Introduction
Output Board
N o n - C o n t a c t
P o s i t i o n S e n s o r
L i m i t S w i t c h es
a n d
A u x i l l i a r y S w i t ches
H a n d w h e e l
F i e l d R e v e r sible Switch
C u s t o m e r
C o n n e c t i o n s
A u t o / M a n u al
S w i t c h

Figure 1-2 10260A Internal View

2/03 10260A Series Actuators – Installation, Operations, and Maintenance 5
