10260A Series Actuators Installation, Operations, and Maintenance Manual

1.4 Honeywell Linkage Kits

Honeywell turnbuckle and pipe linkage kits are available and are recommended to provide optimal
positioning performance. The rod-end bearing connections eliminate all linkage hysteresis giving accurate
and repeatable positioning of the final control element. Honeywell has designed a linkage analysis program
(HAL) that is used to deign linkage set-up.
Crank Arm and
Rod End
4 10260A Series Actuators – Installation, Operations, and Maintenance

Figure 1-1 10260A Actuator

Non-Contact Sensor
& Switch Cover
Terminal Cover
Hand -
whee l
Auto/M anual
Swi tc h
2/03
