Thermon Caloritech EX Series Installation, Operation & Maintenance Instructions Manual

Circulation Heaters
EX Series
Installation, Operation, & Maintenance Instructions
For CE/ATEX and IECEx Models. Models with
Increased Safety (Type eb) Protection Method
Special Notes
CAUTION. This document presents the minimum requirement pertaining
to the installation, operation, and maintenance of the respective
equipment as required by the manufacturer only. Any additional
CAUTION
considerations, including but not limited to any design consideration,
in-service inspection, and fitness-for-service assessment for all pressure
boundary components to meet any safety principles and local jurisdictional
regulatory requirements, shall be the responsibility of the user.
ELECTRIC SHOCK HAZARD. All electric heating equipment installations
must be performed by qualified personnel in accordance with the local
electrical codes and standards and must be effectively grounded to
CAUTION
eliminate shock hazard.
FIRE/EXPLOSION HAZARD FOR EXPLOSIVE ATMOSPHERE HEATERS.
This heater shall be used with protection controls as follows:
WARNING
Liquid Immersion Applications
a. Liquid level control to maintain all the heating elements totally
immersed at all times, in conjunction with temperature controls to limit
the liquid temperature below the maximum allowable process design
temperature.
b. Terminal box internal surface temperature control to limit the surface
temperature of the terminal box
c. Heater flange surface temperature control to limit the surface
temperature of the flange.
d. Heating elements sheath temperature controls to limit to the maximum
allowable sheath design temperature
e. Earth fault or earth leakage current protection device to protect against
arcing and sparking during an earth fault.
Gaseous and/or vapour phase immersion applications
a. Heating elements sheath temperature controls to limit to the maximum
allowable sheath design temperature.
b. Terminal box internal surface temperature control to limit the surface
temperature of the terminal box
c. Heater flange surface temperature control to limit the surface
temperature of the flange.
d. Earth fault or earth leakage current protection device to protect against
arcing and sparking during an earth fault. THS3002-1220 Printed in Canada
