Altronix AL600UL3 Installation Manual page 7

Enclosure Dimensions (BC300):
AL600UL3
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
13.0"
(330mm)
5.10"
(130mm)
3.25"
(83mm)
1.0"
(25mm)
AL600UL3/AL600UL3X
1.40" 4.85"
(36mm) (123mm)
0.75"
(19mm)
1.0"
(25mm)
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
4.85"
(123mm)
12.5"
(318mm)
11.0"
(279mm)
10.5"
(267mm)
1.40"
(36mm)
1.20"
(31mm)
3.25"
(83mm)
1.20"
0.75"
(31mm)
(19mm)
0.9375"
(24mm)
0.9375"
(24mm)
3.25"
(83mm)
3.25"
(83mm)
1.0"
(25mm)
1.0"
(25mm)
1.40"
(36mm)
5.10"
(130mm)
6.5625"
(167mm)
