1
13
/
16
A
B
18
16
5
/
8
C
D
E
1
2
3
17
1
/
2
16
5
/
8
Front View
2
3
4
1
3
/
8
12
7
/
14
1
/
4
8
13
/
16
Boston BT2 Dimension Sheet
All Dimensions in inches. It is recommended that at least
0.75-inches of extra depth is added to the compartment
for wiring and at 1-inch on either side to ease removal.
For more information on the BT or any other Boston
products, please contact Boston Technical Support at
1.978.538.5000 or by email at: support@bostona.com
4
5
6
Top View
5
6
A
B
C
D
E
