Page 1
WARRANTY CERTIFICATE CLIENT’S COPY) TECHNICAL DELIVERY DATE: INVOICE NUMBER: DEALERSHIP INFORMATION NAME: STAMP AND SIGNATURE: CLIENT INFORMATION NAME PHONE: ADDRESS PURCHASED UNIT INFORMATION MODEL: MANUFACTURED DATE: SERIAL NUMBER: IMPORTANT! Warranty issues will only be address if this certificate is properly filled-out at the time of delivery by technician.
Page 3
TECHNICAL DELIVERY TERMS (this form must be completed by the technician and sent to stara) INVOICE No.: DELIVERY DATE TECHNICIAN/DELIVERY AGENT: CUSTOMER DATA NAME: PHONE No.: OPERATOR(S) NAME(S): ADDRESS: PURCHASED PRODUCT DATA MODEL: MANUFACTURED DATE INSTRUCTIONS AND DIRECTIONS TECHNICIAN FUNCTIONS:...
Page 5
Stara's judgment all warranty claims. Conditions of the Warranty A) Stara guarantees its product “only to” the DEALERSHIP, and for the period of six months, starting on the day of delivery to the CLIENT, along with the original invoice and warranty certificate, which must be presented at the time of claim.
Page 6
Not included are such items as: hydraulic oils and lubricants, filters, greases and the like,charges for roadside assistance or help, on-site assistance and any equipment maintenance or help by Stara personnel; all these are the responsibility of the purchaser. Also not inclusive are: tires, inner tubes, electrical and electronic equipment,...
Page 7
Rights or Civil Codes; as specified in the country of purchase or sale. TECHNICAL ASSISTANCE Besides the instruction manual, the users of Stara products can call the nearest authorized dealership to obtain any needed assistance. The dealership, by its own merit, can seek information and assistance from the After-Sales Department at Stara, whenever a difficult situation presents itself, or the need arises to resolve any problems.
Page 8
REPLACEMENT PARTS Parts replacement should only be done using original parts from Stara, the which , besides preserving the warranty rights as a consumer, will not compromise the operation and the maintenance of the equipment. PROJECT MODIFICATIONS Stara S/A reserves the right to introduce project modifications of its products for the end of its improvements or refinement, regardless of any obligations to upgrade any previously manufactured equipment.
Page 9
Constant Evolution 14000 TRAILER INSTRUCTION AND PARTS MANUAL STARA S.A. - Agricultural Machinery and Implements Industry AV. STARA, 519 Não-Me-Toque,RS - Brazil CEP 99470-000 Phone/Fax:+55 54 3332-2800 e-mail: stara@stara.com.br Home page: www.stara.com.br August 2009 - Rev.:A...
TABLE OF CONTENTS INTRODUCTION ....................06 MAIN COMPONENTS..................08 IDENTIFICATION PLATE................09 TECHNICAL SPECIFICATIONS ..............09 SAFETY MEASURES ...................12 MAINTENANCE ..................12 5.1 - Caring for the Reservoir.................12 5.2 - Tightening and Lubrication..............13 5.3 - Caring for the Paint Job and Clean-up............13 5.4 - Tire Pressure..................13 6 - FIELD ASSEMBLY..................14 6.1 - Mounting Wheels onto the Wheel Axle...........14...
Page 12
10.5 - Using the Chute for Grains and the Telescopic Tube for Fertilizers ..33 10.6 - Field Loading Planters and Spreaders..........33 10.7 - Shadowing the Harvesters in the Field ..........34 10.8 - Use and Adjustments................35 10.8.1 - Adjusting ...
The 14000 Trailer, besides its primary function, which is to fill the planters with fertilizers, can also be used to transport and store grain during the harvest, since the 250mm conveyor screw is sized to this end, thus reducing damages to the grain.
MAIN COMPONENTS The 14000 Trailer is made up of some basic components A - Front Road Wheel Axle J - Telescopic Tube f/ Fertilizer B - Rear Road Wheel Axle K - Protective Screen C - Chassis Ladder Hitch/Goose-neck M - Tarp Arches Reservoir N - Support Stands F - Steering Axle...
2 - ID PLATE The ID plate (Figure 02) shows the model no. of the machine, weight, serial no., and also the date manufactured. This information is fundamental in the traceability of the machine during its life cycle. The ID plate is placed on the chassis of the implement.
Page 18
- Wheel Axles: - Rear - With rigid dis-mountable spindles. - Front - With spinning dis-mountable spindles. - With an irregular pantog. steering system. - With a balancing beam type system. Grain Reservoir: - Reservoir made of polyethylene, with orange pigmentation, with storage capacity of 5m³...
Page 19
Dimensions: 6650 mm 6060 mm 2360 mm 3420 mm Figure 03...
SECURITY MEASURES The 14000 Trailer is a piece of equipment relatively simple to use, but, like any other implement or agricultural machinery, it is necessary to take precautionary safety measures, to avoid accidents: Verify that the trailer and tractor are in good working conditions. - Scan the area around the implement and tractor, before performing any maneuvers, so as to not hurt or damage personnel, animals or obstacles.
• Bathe metallic parts with oil immediately after using the implement. • Touch-up the paint job, thus avoiding corrosion on metallic parts. NOTE: The 14000 Trailer was designed in such a way the its components will not impregnate with product residue, for all its parameters are bent outward or downward.
6 - FIELD ASSEMBLY The 14000 Trailer leaves the factory with some of its sub-assemblies already assembled, but, to facilitate transporting, the larger sub-assemblies are assembled at the dealership or directly at the customer’s site. To facilitate assembly, a logical order should be followed, as shown below: 6.1 - Mounting the Wheels to the Wheel Axle...
Support Stands CHASSIS Rear Wheel Axle Front Wheel Steering Axle Figure 05 Note: When dealing with mounting tires 9.00”x20.00” or 10.00x20.00, it is required that they be mounted first to the road-wheel axles and also the support stands to adjust the chassis height. 6.3 - Mounting the Hitch/Goose-neck When mounting the...
6.4 - Mounting Auxiliary Accessories After installing the axles and road-wheels onto the chassis, you are now ready to mount a set of auxiliary components which are: A - Reservoir Braces D - Reservoir Central Supports B - Ladder E - Telescopic Support C - Central Brace Figure 07...
6.5 - Reservoir Installation Install and fit the polyethylene reservoirs, as shown on figure 08. ATTENTION! The reservoirs should be installed with care, to avoid scratches or cracking, these tanks will not endure violent shocks or hard knocks. These reservoirs are only fitted into the chassis, without any bolting or any hold-downs.
6.6 - Mounting the Protective Screens, Above-box and the Enclosure Center Joint Before mounting the above-box it is necessary to install the protective screens. This way you will have greater accessibility while moving on the screens, and also when installing the above-box and the enclosure center joint. Initially, install the screen hold-downs onto the protective screens, then mount them onto the reservoir upper edges, do so in a manner which the screen hold-down tubes will lodge into the reservoir’s edges, with the screen slightly...
ENCLOSURE POLYETHYLENE CENTER JOINT ABOVE-BOX DRILL USING A Ø11mm DRILL BIT Figure 10 6.7 - Mounting the Universal Conveyor Screw System ø250mm 6.7.1- Mounting the Funnel When mounting the ø250mm system, first install the funnel assembly, leaving its mounting hardware loose, see figure 11. 6.7.2 - Mounting the Conveyor Screw Supports and Rests Install the front and rear supports and rest brackets, see figure 12.
6.7.3 - Mounting the Conveyor Screw Install the conveyor screw assembly onto the supports, next mount to the funnel, adjust as needed and tighten all funnel hardware as per figures 13 and 14. Figure 13 Figure 14 6.8 - Mounting the Conv. Screw, Tension Cable and Telescopic Tube The Conv.
6.9 - Mounting the Hydraulic System Normally, the conveyor screw’s hydraulic motor is driven by the tractor’s hydraulic system. In this case, the circuit is mounted on the 14000 Trailer as shown on fig.16, thus leaving the quick-disconnects, pressure connections and the return ready to hook-up to the tractor’s hydraulic controls.
6.10 - Installing the Independent Hydraulic System The installation of the independent hydraulic system components is done on the front side of the chassis, above the hitch, as shown on fig. 17. Begin by mounting the hydraulic tank (A), along with the hydraulic pump, on the support fixed on the frontal side of the chassis.
Figure 18 6.12 - Installation of the Rear Hydraulic Braking System (optional) To install the braking system of the 14000 TRAILER, you must remove the rear wheels, and mount the left and right brake drums along with its components. Re-mount the wheels and hook-up the hydraulic hoses, next mount the hydraulic controls next to the tractor’s seat, usually to the right of the operator.
BRAKE HOSES Figure 19 7 - TRACTOR HOOK-UP The 14000 TRAILER is attached to the tractor by the traction bar and the locking-pin. IMPORTANT! Do not forget to install the locking-pin on the hook-up pin, see figure 20. To finalize the hook-up, connect the tractor’s hydraulic system circuit hoses.
Figure 22 8 - Convoy Hook-up As an option on the 14000 TRAILER additional trailers of the same family can be hooked-up as a convoy, likewise on the other TRAILERS like the 14000 TS and the 6000 TS. To apply this option, it is required to have a Convoy Hook-up Kit, which matches your hitch type and all applicable hydraulic hose extensions, which will connect the trailer’s hydraulic system with the tractor’s hydraulic controls.
350 mm conveyor screw. The 14000 TRAILER’s 250mm output tube can be placed in various positions, thus allowing for the loading of product stored in bulk (fertilizer and grains), located in front and rear tanks, starting from ground level.
Figure 24 9.3 - Use and Cautions of the Hydraulic System A) For proper operation and durability of the hydraulic motor, when working with the 250mm conveyor screw, and being hooked-up to the tractor, certain precautions should be adhered to, such as: - Use clean hydraulic oil;...
B) When using the ø250mm conveyor screw, always open or close the selection valve completely. The opening and closing valve lever should touch the valve body in both conditions, figure 25. OPENED CLOSED Figure 25 9.4 - Loading Planters and Spreaders in the Field using the ø250mm Conveyor Screw The14000 TRAILER can load QUICK-DISCONNECT...
The output tube rests on the support arm, using gravity to hold it in place. This facilitates its pIacement when hooking-up to the reservoir’s slide-gate. The engagement is done by two quick-disconnect latches (figure 26). ATTENTION! Do not forget to inspect daily the output chute for cleanliness, and to lubricate the screw’s bearings.
9.6 - Procedures for Maneuvering During Jobs Whenever you plan to maneuver the 14000 TRAILER from the barn to the field, and from the field to the barn, or be it still from one site to another, empty out the conveyor screw and place the output tube in its resting position ready for transporting, as shown on figure 28.
10 - INSTALLATION OF THE 350 mm CONVEYOR SCREW SYST.(OPT.) The 14000 TRAILER has an option to change-out the 250 mm output system for the 350mm output system. 10.1 - Installing the Conveyor Screw Chassis Supports The conveyor screw supports(A), are mounted on the central upper left side of the chassis.
10.3 - Installing the Second Stage of the Conveyor Screw When the installation of the 1st Stage of the Conveyor Screw is done, proceed installing the 2nd Stage, the upper portion, as shown on fig. 31. With the Conveyor Screw in its rest, install the hydraulic lift cylinder of the Conveyor Screw, and adjust the rest in such a way that Conveyor Screw will remain firmly supported in the rest, when the lift cylinder is totally retracted.
Page 41
10.6 - Field Loading Planters and Spreaders The 14000 TRAILER can load bulk fertilizer, directly from the planter’s tanks or spreaders. To bring the trailer to working conditions, hook-up the drive-shaft to the tractor’s PTO and install the slide-gate hydraulic cylinder hoses along with the...
Page 42
10.7 - Shadowing the Harvesters in the Field The 14000 TRAILER can be used to shadow the harvesters during harvest times, thus avoiding wasted time while returning to the truck to unload, and then return to its harvest shadowing posture.
Page 43
10.8 - USE and ADJUSTMENTS 10.8.1 - Adjusting the Slide-Gate When dealing with grains, the slide-gate (A) should be totally opened to obtain the maximum output rate of 3500 l/min. And when dealing with granular fertilizers, the opening should be limited to 120mm.
Page 44
11 - HYDRAULIC SYSTEM PROBLEMS, POSSIBLE CAUSES AND/OR SOLUTIONS PROBLEMS SOLUTIONS CAUSES Loose connections. Carefully re-tighten connections. Hoses with fixed connection leaking Use thread sealing tape and Lack of thread sealant. carefully re-tighten connection. Loose connections. Carefully re-tighten connections. Quick-disconnects Use thread sealing tape and Lack of thread sealant.
Page 45
12 - AVAILABLE OPTIONS FOR THE 14000 TRAILER 12.1 -P/N: 1073-0001 - 14000 Trailer with 6 Rims 1050-2128 - Rim, 7.5” x 20” - 02 units *1073-3087 - Kit, 14000 w/ø250mm Conv. Screw - 01 unit 1074-3036 - Support Stand, 14000 Plus Trailer - 01 unit 1074-3073 - Std Package,14000 Trailer - 01 unit 9100-0400 - Rim, 7.00”...
Page 46
1073-3087 - Kit ,14000 w/ø250mm Conv. Screw 1073-3004 - Funnel Package - 01 unit 1073-3005 - Auto-fill Package - 01 unit 1073-3082 - Decal Set, 14000 Trailer - 01 unit 1073-3090 - Motor Pkg, Conv.Screw-250mm/ 50 liters - 01 unit 1073-3094 - Support Pkg, Conv.Screw-250mm/14000 Trailer- 01 unit...
Page 47
13.4 - 1074-3090- Kit for 14000 Plus TRAILER- 1074-3013 - Door Frame Assy 1074-3033 - 2nd Stage Conv. Screw- 14000 Plus. 1074-3060 - Support, 1st Stage Conv. Screw -14000 Plus. 1078-3023 - Independent Hyd. System Pckg- 80l/min - 01 unit 13.5 - 1074-3080 - Kit w/SHS for 14000 Plus TRAILER- 1074-3013 - Door Frame Assy...
