Safavieh PAT6749 Assembly Instructions

CARE AND MAINTENANCE
Spot clean using a mild water-free solvent. Only a professional cleaner should
undertake a complete overall cleaning.
The use of steam or water-based cleaners may cause excessive shrinking or staining.
NOTICE
* Please make sure all parts are included before you begin assembly of this item.
* This item should be assembled on a soft surface to prevent scratching the finish during
assembly
* This item may require periodic tightening
Parts List and Hardware List
ID PICTURE & DESCRIPTION
Table top
A
Table legs
B
Cross bar
C
of table
Left bench leg
D
Right bench leg
E
Backrest
F
Seat
G
Pillow
H
Q.tys ID PICTURE & DESCRIPTION
I
1X Cushion seat
M1
2X
Ø 7x120 mm
1X
M2
Ø 7x60 mm
2X M3
Ø 6x13 mm
2X
M4
Ø 6x30 mm
M5
2X
Ø 4x15 mm
wooden dowel
M6
2X
Ø 10x30 mm
4X
M7 Allen key
Product dimension:
THE DESIGN OF LARDNER LIVING IN THE DRAWINGS MAY VARY
FROM ACTUAL, BUT ASSEMBLY CAN BE APPLIED
Q.tys
4X
Screw
12X
Screw
10X
Nuts
8X
Bolts
8X
Screw
4X
8X Weight Capacity: 550 lbs per bench & 88 lbs per table
WARNING: DO NOT STAND ON BENCH & TABLE
2X
WARNING: DO NOT OVER TORQUE BOLTS/SCREWS
O U T D O O R
PAT6749
Item#
Table : 23,62"W x 23,62"D x 21,65"H
Bench: 52,76"W x 24,6"D x 29,53"H
ASSEMBLY INSTRUCTIONS FOR SAFAVIEH
LARDNER LIVING
FOR THIS ITEM
