12 en | Remote Control
4

Remote Control

This section details the functions and the usage of the Bosch remote control.
Button Function
POWER Turns the power ON and OFF.
SOURCE Selects the PC or Video source.
Numbers Numerals 0-9.
AUTO Auto adjusts to the graphics adaptor.
MUTE Mutes the sound.
MENU Displays the OSD. Pressing the MENU button returns you to the Main
menu from anywhere in the OSD menus.
EXIT Exits the OSD.
UP Moves the cursor up in an OSD menu.
DOWN Moves the cursor down in an OSD menu.
ENTER Accepts your selection or displays the current mode when in the OSD
menu.
Moves the cursor left, decreases item values in an OSD menu, or
decreases sound.
VOL
Moves the cursor right, increases item values in an OSD menu, or
decreases sound.
VOL
PIP Activates/deactivates Picture-In-Picture mode.
P. INPUT Selects the PC or Video source for the PIP. Continuously press this but-
ton to change the selection.
P. POS Moves the position of the sub picture for the PIP mode. Continuously
press this button to change the selection.
P. SIZE Changes the size of the sub and main picture for the PIP mode. Contin-
uously press this button to change the selection.
SWAP Alternates between the main and sub picture for the PIP mode. Continu-
ously press this button to change the selection.
ARC (Aspect Selects the screen ratio when in Video mode. Continuously press this
Ratio Control) button to change the selection.
APC (Auto Pic- Selects the picture mode. Continuously press this button to change the
ture Control) selection.
ACC (Auto Selects the color mode. Continuously press this button to change the
Color Control) selection.
S. SET Selects the sound mode main input or sub input (only available when
PIP is enabled).
PC Selects the PC mode (HDMI, DVI, PC). Continuously press this button to
change the selection.
AV Selects the AV mode (AV1, AV2, S-Video). Continuously press this but-
ton to change the selection.
COMP Selects the COMPONENT mode.
